Section 1 - General Information; Generator Identification - Generac Power Systems RV 45 SERIES Owner's Manual

1.1

GENERATOR IDENTIFICATION

Please record the following information from the generator DATA DECAL or information decal.
1. Model Number _____________________
3. kW Rating _________________________
5. Phase _____________________________
1. Generator Air Intake
2. Data Plate
3. Engine Start/Stop Switch
4. 7.5 amp Fuse
5. Circuit Breaker
6. Optional Remote Panel Receptacle
7. Generator AC Output Leads
8. Starter Contactor
9. Fuel Inlet
10. Fuel Pump
4
Section 1 – General Information
Recreational Vehicle Generators
18 8
10, 17 3 4 5
REFERENCE NUMBER IDENTIFICATION
2. Serial Number __________________
4. Rated Voltage __________________
6. Hertz __________________________
2
1 12 11 14
7
9, 17
11. Oil Filter
12. Oil Drain Plug
13. Oil Dipstick and Filler Tube
14. Air Filter (Behind access panel.)
15. Spark Plugs
16. Exhaust Outlet
17. Fuel Filter
18. Evaporative Port
15
13
16
6
10
