RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS
Instructions
Retain these instructions for future reference
www.ringautomotive.co.uk
BATTERY
100%
0%
AMPS/A
0 2 5
1 0
1 5
2 0
WorkShopCharge
RCB306
6amp
WorkShopCharge
RCB308
8amp
WorkShopCharge
RCB312
12amp
WorkShopCharge
RCB320/RECB320
20amp
WorkShopCharge
RCB322/RECB322
22amp
BATTERY
BATTERY
100%
0%
100%
0%
AMPS/A
AMPS/A
0 2 5
1 0
1 5
2 0
0 2 5
1 0
1 5
2 0
6
8
12
6v
12v
12v
BATTERY
BATTERY
100%
0%
100%
0%
AMPS/A
AMPS/A
0 2 5
1 0
1 5
2 0
0 2 5
1 0
1 5
2 0
20
22
24v
BATTERY
100%
0%
AMPS/A
0 2 5
1 0
1 5
2 0
2
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ring WorkShopCharge22 RCB322
Summary of Contents for ring WorkShopCharge22 RCB322
- Page 1 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS WorkShopCharge RCB306 6amp WorkShopCharge RCB308 8amp WorkShopCharge RCB312 12amp WorkShopCharge RCB320/RECB320 20amp WorkShopCharge RCB322/RECB322 22amp Instructions Retain these instructions for future reference www.ringautomotive.co.uk BATTERY BATTERY BATTERY BATTERY BATTERY BATTERY 100% 100% 100% 100%...
- Page 2 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS Safety Sicurezza Säkerhet Sécurité Seguridad Veiligheid Sicherheit Segurança Sikkerhed RISK OF EXPLOSION! RISCHIO DI ESPLOSIONE! RISK FÖR EXPLOSION! Only connect the battery Staccare l’alimentazione di Anslut aldrig batterikablar leads when the mains rete prima di collegare i när strömmen är på...
- Page 3 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS INDOOR USE ONLY – PARA UTILIZAR APENAS EM ESPAÇOS FECHADOS – Keep away from liquids at BATTERY 100% Manter sempre afastado all times AMPS/A 0 2 5 de líquidos UTILISATION À L’INTÉRIEUR UNIQUEMENT –...
- Page 4 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS WorkShopCharge12 Caratteristiche di WorkShopCharge12 Features and WorkShopCharge12 – funktioner och Product Detail e descrizione del produktinformation prodotto Caractéristiques et Functies van Données du Produit Características y WorkShopCharge12 WorkShopCharge12 Datos del Producto del en productinformatie WorkShopCharge12 WorkShopCharge12...
- Page 5 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS Ammeter AMPS/A Ampèremètre 0 1 2 3 4 5 6 7 8 Amperemeter BATTERY Amperometro 100% Amperímetro Amperímetro Amperemeter Ampèremeter Amperemeter ‘Power’ indicating LED – Green LED indicateur de 'Alimentation’ – Vert Netz-LED –...
- Page 6 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS ‘Charge/Charged’ indicating LED – Amber/Green DEL signalisation 'En Charge/Chargé – Ambre/Vert Anzeigeleuchte „Laden/Geladen“ – Gelb/Grün LED di segnalazione “Sotto carica/Carica completata' (ambra/verde) LED indicador de 'Cargando/Cargado – Ámbar/Verde LED indicando se a carregar/carregado – Âmbar/Verde "Laddar/Laddad"-lampa –...
- Page 7 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS WorkShopCharge20 Caratteristiche di WorkShopCharge20 Features and Product WorkShopCharge20 – funktioner och Detail e descrizione del produktinformation prodotto Caractéristiques et Functies van Données du Produit Características y Datos WorkShopCharge20 WorkShopCharge20 del Producto del en productinformatie WorkShopCharge20 WorkShopCharge20...
- Page 8 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS Ammeter BATTERY Ampèremètre 100% Amperemeter Amperometro AMPS/A 5 7 9 Amperímetro Amperímetro Amperemeter Ampèremeter Amperemeter ‘Power’ indicating LED – Green LED indicateur de 'Alimentation’ – Vert Netz-LED – grün LED di ‘Alimentazione’ – Verde LED indicador de 'Energía' –...
- Page 9 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS ‘Charge/Charged’ indicating LED – Amber/Green DEL signalisation 'En Charge/Chargé – Ambre/Vert Anzeigeleuchte „Laden/Geladen“ – Gelb/Grün LED di segnalazione “Sotto carica/Carica completata' (ambra/verde) LED indicador de 'Cargando/Cargado – Ámbar/Verde LED indicando se a carregar/carregado – Âmbar/Verde "Laddar/Laddad"-lampa –...
- Page 10 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS WorkShopCharge22 Caratteristiche di WorkShopCharge22 Features and WorkShopCharge22 – funktioner och Product Detail e descrizione del produktinformation prodotto Caractéristiques et Functies van Données du Produit Características y WorkShopCharge22 WorkShopCharge22 Datos del Producto del en productinformatie WorkShopCharge22 WorkShopCharge22...
- Page 11 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS Ammeter BATTERY Ampèremètre 100% Amperemeter AMPS/A Amperometro 0 2 5 Amperímetro Amperímetro Amperemeter Ampèremeter Amperemeter ‘Power’ indicating LED – Green LED indicateur de 'Alimentation’ – Vert Netz-LED – grün LED di ‘Alimentazione’ – Verde LED indicador de 'Energía' –...
- Page 12 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS ‘Charge/Charged’ indicating LED – Amber/Green DEL signalisation 'En Charge/Chargé – Ambre/Vert Anzeigeleuchte „Laden/Geladen“ – Gelb/Grün LED di segnalazione “Sotto carica/Carica completata' (ambra/verde) LED indicador de 'Cargando/Cargado – Ámbar/Verde LED indicando se a carregar/carregado – Âmbar/Verde "Laddar/Laddad"-lampa –...
- Page 13 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS Charging and engine start switch – switches between battery charging and engine start functions Commutateur de charge et démarrage du moteur - établi la commutation entre les fonctions de charge de la batterie et de démarrage du moteur Schalter „Laden und Starthilfe“...
- Page 14 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS Battery Charge Funzionamento Batteriladdnings- Operation carica batteria operation Opération de charge Operación de carga Bewerking Batterij de la batterie de la batería laden Batterieladebetrieb Operação de Batteriopladnings- carregamento da funktion bateria Operating conditions and Condizioni operative e linee...
- Page 15 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS Connexion Collegamento Brancher la cosse de Collegare il contatto rosso batterie rouge (+) sur la (+) al terminale rosso (+) borne rouge (+) de la sulla batteria batterie Fissare la pinza nera (-) al Attachez le connecteur noir telaio del veicolo, evitando (-) de la pile au châssis du...
- Page 16 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS Ligação Aansluiting Prenda o grampo vermelho Bevestig de rode (+) (+) de bateria ao terminal accuklem aan de rode (+) vermelho (+) na bateria klem op de accu Ligue o grampo preto (-) Bevestig de zwarte (-) da bateria ao chassis do accuklem aan het...
- Page 17 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS Voltage/Charge select Seleccionar Voltaje/Carga Charge rate Select the correct battery Seleccionar el voltaje voltage and required correcto de la batería y el charging rate. régimen de carga que se requiere 12v Slow 12v Fast Sélectionner...
- Page 18 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS AC Connection Ligação CA Connect plug to AC mains Seleccionar a função de power arranque do motor Branchement de CA AC-anslutning Brancher la fiche au réseau Anslut kontakt till de service de CA strömuttag Wechselstromanschluss Wisselstroomaansluiting...
- Page 19 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS alimentação CA Geladen Desligar o grampo Sobald der Ladevorgang vermelho (+) da bateria abgeschlossen ist, leuchtet die grüne Geladen-LED auf. Desligar o grampo preto negativo (-) da bateria Die WS-Netzversorgung ausschalten und den Laddad Stecker aus der Steckdose...
- Page 20 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS Engine Start Avviamento motore Motorstart Démarrage du Arranque del motor Motor starten moteur Arranque do motor Motorstart Starthilfe Operating conditions and Condizioni operative e linee Driftförhållanden och guide lines guida riktlinjer Conditions et instructions Condiciones y directrices de...
- Page 21 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS Polarität prüfen Connection Die LED „Polarität prüfen“ Attach the red (+) battery leuchtet auf, wenn das clip to the red (+) terminal Ladegerät falsch an die on the battery Batterie angeschlossen Attach the black (-) battery wurde, z.B.
- Page 22 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS Polarity Check Ligação (polariteitscontrole) Prenda o grampo vermelho de LED voor de (+) de bateria ao terminal polariteitscontrole gaat vermelho (+) na bateria branden wanneer de Prenda o grampo preto (-) acculader verkeerd op de de bateria ao terminal preto accu is aangesloten, d.w.z.
- Page 23 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS Seleccionar la función de Engine Start select arranque del motor Select the engine start function Ligação CA Virar o motor em explosões Sélectionner démarrage de 3 segundos du moteur RCB320/RECB320 Sélectionner la fonction de Motorstartsval démarrage du moteur...
- Page 24 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS Engine Start Amperímetro Crank the engine in 3 second Carregadores de bateria de bursts. elevada qualidade, ideais para utilização na garagem ou Démarrage du moteur oficina. Virer le moteur en explosions Motorstart de 3 secondes Dra igång motorn med tre...
-
Page 25: Specifications
RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS Specifications Specifiche Specifikationer Spécifications Especificaciones Specificaties Technische Daten Especificações Specifikationer Input voltage 220 – 240VAC Charging current/ WorkShopCharge6: 12v: 6.0amp (RMS) / 4.0amp (DC) Output voltage WorkShopCharge8: 12v Slow: 3.75amp (RMS) /2.5A (DC) 12v Fast: 8.0amp (RMS) / 5.4A (DC) WorkShopCharge12: 6V: 9amp (RMS) / 6amp (DC) - Page 26 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS Specifications Specifiche Specifikationer Spécifications Especificaciones Specificaties Especificações Specifikationer Technische Daten Eingangsspannung 220 – 240VAC Ladestrom/ WorkShopCharge6: 12v: 6.0amp (RMS) / 4.0amp (DC) Ausgangsspannung WorkShopCharge8: 12v Langsam: 3.75amp (RMS) /2.5A (DC) 12v Schnell: 8.0amp (RMS) / 5.4A (DC) WorkShopCharge12: 6V: 9amp (RMS) / 6amp (DC)
- Page 27 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS Specifications Specifiche Specifikationer Spécifications Especificaciones Specificaties Especificações Specifikationer Technische Daten Voltaje de entrada 220 – 240VAC Corriente de carga/ WorkShopCharge6: 12v: 6.0amp (RMS) / 4.0amp (DC) Voltaje de salida WorkShopCharge8: 12v Slow: 3.75amp (RMS) /2.5A (DC) 12v Fast: 8.0amp (RMS) / 5.4A (DC) WorkShopCharge12:...
- Page 28 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS Specifications Specifiche Specifikationer Spécifications Especificaciones Specificaties Technische Daten Especificações Specifikationer Inspänning 220 – 240VAC Laddningsström/ WorkShopCharge6: 12v: 6.0amp (RMS) / 4.0amp (DC) Utspänning WorkShopCharge8: 12v Långsam hastighet: 3.75amp (RMS) /2.5A (DC) 12v Snabb hastighet: 8.0amp (RMS) / 5.4A (DC) WorkShopCharge12: 6V: 9amp (RMS) / 6amp (DC)
- Page 29 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS Specifications Specifiche Specifikationer Spécifications Especificaciones Specificaties Technische Daten Especificações Specifikationer Indgangsspænding 220 – 240VAC Ladestrøm/ WorkShopCharge6: 12v: 6.0amp (RMS) / 4.0amp (DC) Udgangsspænding WorkShopCharge8: 12v Langsom: 3.75amp (RMS) /2.5A (DC) 12v Hurtig: 8.0amp (RMS) / 5.4A (DC) WorkShopCharge12: 6V: 9amp (RMS) / 6amp (DC)
- Page 30 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS Avertissement: Ce chargeur ne Avvertenza: Non adatto per In addition to the battery doit pas être utilisé par des caricare batterie non types and capacity detailed in personnes (y compris enfants) ricaricabili the specifications (pages 25 –...
- Page 31 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS Nätkabeln kan inte bytas ut. Opladning af genopladelige Para além dos tipos de bateria Om den skadas ska laddaren blysyre- eller gelbatterier med e da capacidade descrita nas kasseras 6 celler especificações (páginas 25 –...
- Page 32 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS...
- Page 33 RCB 306&308 Metal Battery Charger instructions +2pg:3575_METAL BATTERY CHARGER INSTRUCTIONS...
- Page 34 La gama de WorkshopCharge está aprobada por la EMC: EN55014-1 / EN55014-2 / EN61000-3-2/ EN61000-3-3 LVD: EN60335-1 / EN60335-2-29 EMF: EN50366 Distributed by: Ring Automotive Limited, Gelderd Road, Leeds, England LS12 6NA +44 (0)113 213 2000 +44 (0)113 231 0266 autosales@ringautomotive.co.uk www.ringautomotive.co.uk...
Need help?
Do you have a question about the WorkShopCharge22 RCB322 and is the answer not in the manual?
Questions and answers
HOW DO i CHARGE THE POWERPACK
To charge the Ring WorkShopCharge22 RCB322 power pack:
1. Connect the plug to an AC mains power outlet.
2. Select the correct battery voltage (12V or 24V) and charging mode:
- For 12V batteries:
- Slow charge: 3A (RMS) / 2A (DC)
- Fast charge: 22A (RMS) / 15A (DC)
- For 24V batteries:
- Charge: 11A (RMS) / 7.5A (DC)
3. Make sure the battery type is lead-acid or gel.
4. Confirm the battery capacity is between 20Ah and 225Ah.
5. Ensure correct polarity when connecting to the battery (red clamp to +, black to -).
The unit also supports engine start with up to 150A (RMS) / 100A (DC).
This answer is automatically generated
Hi i dont seem to be getting power and green light not coming on when plugged in
The Ring WorkShopCharge22 RCB322 may not be powering on and the green light may not be coming on due to the following possible reasons:
1. Power Supply Issue – Ensure that the charger is plugged into a working power outlet and that the power source is functioning correctly.
2. Damaged Cables or Connections – Check if the power cord or charger cables are damaged, as faulty wiring can prevent the device from receiving power.
3. Internal Fault – If the charger has an internal defect, it may not function properly and require professional inspection or replacement.
4. Safety Feature Activation – The charger is fully automatic and may not activate if it detects an issue with the battery or connections.
If none of these resolve the issue, the charger may need servicing or replacement.
This answer is automatically generated
Can I order a printed version of the instructions?
