Summary of Contents for GreenWorks 2200702
- Page 1 80V LITHIUM-ION CORDLESS HEDGE TRIMMER 2200702 Owner’s Manual TOLL-FREE HELPLINE: 1-855-345-3934 www.GreenWorksTools.com Read all safety rules and instructions carefully before operating this tool.
-
Page 2: Table Of Contents
CONTENTS Contents ..........................2 ........................2 Safety information ......................3-7 Symbols ..........................8-9 Know your 80v cordless hedge trimmer ................10 Assembly instruction ......................11-12 Operating instructions ....................13-14 Battery charger ......................15-16 Maintenance..........................17 Environmentally safe battery disposal..................18 Troubleshooting.........................19 Warranty ..........................20 Exploded View ........................ -
Page 3: Safety Information
SAFETY INFORMATION W A R N I N G READ AND UNDERSTAND ALL INSTRUCTIONS. Failure to follow all instructions listed injury. Save all warnings and instructions for future reference. The term "power tool"in all of the warnings listed below refers to your mains-operated battery-operated (cordless) power tool. WORK AREA •... - Page 4 SAFETY INFORMATION • Do not use tool if switch does not turn it on or off. A tool that can not be controlled with the switch is dangerous and must be repaired. • Disconnect battery pack from tool before making any adjustments, changing accessories or storing the tool.
- Page 5 SAFETY INFORMATION FOR HEDGE TRIMMERS D A N G E R If the hedge trimmer blade jams or gets caught on an electrical cord or wires, DO NOT TOUCH THE BLADE FOR ANY REASON! IT CAN BE ELECTRICALLY LIVE AND CAUSE SERIOUS OR FATAL INJURY! Release or drop the trimmer in the quickest, safest way.
- Page 6 SAFETY INFORMATION W A R N I N G If the battery gets in your eyes, immediately with clean water for at least 15 minutes. Get immediate medical attention. Do not charge the battery pack in rain or in wet conditions. Do not immerse the tool, battery pack, or charger in water or other liquid.
-
Page 7: Safety Information
SAFETY INFORMATION W A R N I N G READ AND UNDERSTAND ALL INSTRUCTIONS. Failure to follow safety rules listed below • Do not place the charger where the power cord might be stepped on, tripped on, or subjected to damage. •... -
Page 8: Symbols
SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOL NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz Frequency (cycles per second) -
Page 9: Symbols
SyMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. SyMBOL SIgNAL MEANINg DANgER Indicates an imminently hazardous situation, which, if not avoided, will result in death or serious injury. WARNINg Indicates a potentially hazardous situation, which, if not avoided, could result in death or serious injury. -
Page 10: Know Your 80V Cordless Hedge Trimmer
KNOW YOUR 80V CORDLESS HEDGE TRIMMER Anti-jamming button On/off power button Auxiliary handle Tip protector Guard Control panel Rear Handle Blade Battery pack Rotating handle Lock out Trigger release button switch Fig. 1 KNOW YOUR HEDGE TRIMMER (See Figure 1.) The safe use of this product requires an understanding of the information on the product and in this operator’s manual as well as a knowledge of the project you are attempting. -
Page 11: Assembly Instruction
ASSEMBLY INSTRUCTION BATTERY IMPORTANT! The battery pack (2901302 Rated 80VDC,144WH) is not charged when it is purchased. Before using the hedger for the first time, place the battery pack on the battery charger and charge. Make sure to read all safety precautions, and follow the instructions in the Battery Charger section. -
Page 12: Assembly Instruction
ASSEMBLY INSTRUCTION UNPACKING • This product requires no assembly. • Carefully remove the product and any accessories from the box. Make sure that all items listed in the packing list are included. • Inspect the product carefully to make sure no breakage or damage occurred during shipping. •... -
Page 13: Operating Instructions
OPERATING INSTRUCTIONS ON/Off SW ITCHES (See Figure 3.) The hedge trimmer has an electronic control panel with on/off button and an anti-jam function. It also has a lock-out button and switch trigger. 1. Push the power button (I/O) to turn the unit on. 2. - Page 14 OPERATING INSTRUCTIONS (See Figure 4.) USING THE ROTATING REAR HANDLE 1. Place the hedge trimmer on a and even surface. 2. Make sure that you released the trigger. 3. Pull the rotation lever and begin turning the rear handle. Release the rotation lever and turn the handle 90 degrees to either side until it clicks into place and the lever locks in.
-
Page 15: Battery Charger
BATTERY CHARGER SPECIFICATIONS 80V charger: 2901402 Input: 120VAC, 50/60Hz, Max. 5A Output: 80VDC. Max.4.5A (See Figure 6. ) CHARGING PROCEDURE The battery is not shipped fully charged. It is recommended to fully charge before first use NOTE: to ensure that maximum run time can be achieved. This lithium-ion battery will not develop a memory and may be charged at any time. - Page 16 BATTERY CHARGER CHECKING THE CHARGE If the battery pack does not charge properly: • Check the current at the power outlet with another tool . Make sure that the outlet is not turned off. • Check that the charger contacts have not been shorted by debris or foreign material. •...
-
Page 17: Maintenance
MAINTENANCE W A R N I N G To avoid risk of electric shock, or electrocution: • Do not use a damp cloth or detergent on the battery or battery charger. • Always remove the battery pack before cleaning, inspecting, or performing any maintenance on the hedge trimmer. -
Page 18: Environmentally Safe Battery Disposal
ENVIRONMENTALLy SAfE BATTERy DISPOSAL The following toxic and corrosive materials are in the batteries used in this hedge trimmer battery pack: Lithium-Ion, a toxic material. W A R N I N g All toxic materials must be disposed of in a specified manner to prevent contamination of the environment. Before disposing of damaged or worn out Lithium-Ion battery packs, contact your local waste disposal agency, or the local Environmental Protection Agency for information and specific instructions. Take the batteries to a local recycling and/or disposal centre, certified for lithium-ion disposal. -
Page 19: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Motor fails to start Battery is not secure. To secure the battery pack, make sure when switch trigger the latches on the top of the battery pack is depressed. snap into place. Battery is not charged. Charge the battery pack according to the instructions included with your model. -
Page 20: Warranty
4 year consumer warranty, 1 year commercial warranty against defects in materials, parts or workmanship. GREENWORKS™, at its own discretion will repair or replace any and all parts found to be defective, through normal use, free of charge to the customer. This warranty is... -
Page 21: Exploded View
EXPLODED VIEW... -
Page 22: Parts List
PARTS LIST ITEM NO. PART NO. DESCRIPTION 34104897 Right handle 34108897 Lock-out button 33202896 Lock-out spring 34107897 Trigger switch 36301815 Switch 33400897 Steel wire 32903897 Spring 34106897 Knob 34105897 Left handle 3220505D Screw ST4*16-F 36200897 PCB board 34114815-2 Button 36201897 Board 34201897 Shock pad... - Page 23 TOLL-FREE HELPLINE: 1-855-345-3934 Rev: 02 (07-03-12) Printed in China on 100% Recycled Paper...
