ACCESSORIES &
TROUBLESHOOTING
CALL CUSTOMER SERVICE HOT LINE
USA:1-800-989-3535 Canada: 1-888-676-7325
Whenever calling, please be sure to have your model from the
data plate.
Accessories (Sold Separately)
ITEM
1. Pre-Filter
2. Ionizer/Electronic Collector Cell
3. Charcoal Odor Absorber (Set of 4)
4. Wall Mounting Kit
5. Oreck Fresh Air ® Scent Cartridges
Spring Mulberries ® , 8pk.
Blooming Jasmine ® , 8pk.
USA: 1-800-989-3535
Canada: 1-888-676-7325
Outside the USA and Canada,
contact your local Oreck Distributor.

Troubleshooting Guide

Service problems that appear to be major can often be solved
easily. You can be your own troubleshooter by reviewing the
chart below. It pinpoints problems and how to correct them.
Remember, check the simple things first.
U
NIT DOES NOT TURN
ON
PART #
7780-8041
09-5510-7065
AT4PK7
I
NDICATOR LIGHT ON
8660-0201
UNIT IS FLASHING RED
OR HAS TURNED RED
FA2PK
R
FA3PK
ED INDICATOR LIGHT
WILL NOT TURN OFF
U
NIT DOES NOT
REMOVE POLLUTANTS
U
NIT SPARKS
CRACKLES AND POPS
D
OES NOT REMOVE
ODOR
U
NIT STILL DOES NOT
OPERATE PROPERLY
ALL OTHER SERVICING SHOULD BE DONE BY AN
ORECK AUTHORIZED SERVICE CENTER.
7
P C
ROBLEM HECK
1. Power Cord
2. Selector Switch
3. Front Grill
Ionizer/Electronic
Collector Cell
Ionizer/Electronic
Collector Cell
Ionizer/Electronic
Collector Cell
,
Ionizer/Electronic
Collector Cell
Old Charcoal Odor
Absorber
Check all the above
points
W T D
HAT O O
1. Plug in power cord
2. Set selector switch
for desired blower
speed.
3. Reinsert front grill
until it is flush with
cabinet front. Tap
grill lightly, if
necessary, to fully
insert.
Wash Collector Cell.
Make sure it is
thoroughly clean & dry
before re-installing it.
1. Collector Cell may
not be completely
dry.
2. Cell may be
damaged with a
broken wire.
3. The "Dirty Cell"
sensor may not be
working correctly.
4. If you believe the
Collector Cell is
damaged or the unit
is not working
correctly, return the
unit to the Service
Center.
Wash Collector Cell.
Make sure it is
thoroughly clean & dry
before re-installing it.
1. Sparking or
popping noise
occurs when a
large particle is
captured in the
Collector Cell.
2. If the unit is arcing
excessively, the
Cell may be dirty.
Try cleaning the
Collector Cell.
3. If excessive
arcing continues
after proper cleaning,
the Collector Cell
may be damaged
or wet. Return unit
to the Service
Center.
Replace Charcoal
Odor Absorber.
Return unit to the
Service Center.
