Optional items

3.5" Hard Disk Drive
For more information see Installing the optional hard disk drive on
page 12 and Wireless LAN Setup on page 47.

Network HDD Recorder Tour

Front View

WiFi Dongle
No. Item
1
2 1. Power LED
3
(green/orange)
2. IR receiver
4
3. Read/Write
LED
5
4. Play mode
6
LEDs
5. Home
7 6. Play/Stop
7. Direction
buttons
8
8. SD/MMC/MS
card slot
9
9. Power button
10
10. USB port
PowerLine Ethernet bridge
Description
Shows power status and errors
(see below for more details)
Receives remote control IR
signal
Lights during HDD read/write
Displays the current play mode
Go to the main OSD menu
Play/Stop the current media
Navigate through OSD menus
Insert SD/MMC/MS memory
cards
Press to power on or off
Insert USB devices such as the
optional WiFi Dongle
7
