Page 4: Preface
Preface Ce rtific a tion FCC Verification Notice (USA only) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful int erference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 5 Preface Safety Information Do not disassemble the recorder except as instructed during optional HDD (Hard Disk Drive) installation. Disassembly may cause malfunction or fire or invalidate the warranty. Keep magnetic materials such as speakers and batteries away from the recorder to avoid accidental HDD data corruption.
-
Page 6: Table Of Contents
Preface T a ble of Cont e nt s USER’S MANUAL ................... I Preface ……………………………………………………………… …3 GETTING STARTED ..................6 Network HDD Recorder introduction ------------------------------------- 6 What’s in the box -------------------------------- ------------------------------- 6 Optional items -------------------------------- -------------------------------- -- 7 Network HDD Recorder Tour ---------------------------------------------- 7 Front View -------------------------------- -------------------------------- ------ 7 Power LED Behavior -------------------------------- -------------------------------- - 8 Rear View -------------------------------- -------------------------------- ------- 8... - Page 7 Recording Using Time-Shift -------------------------------- ----------------- 32 Using Scheduled Recording -------------------------------- ------------------ 32 Managing Movies and Video ----------------------------------------------34 Playing Movies and Video -------------------------------- ------------------- 34 Using AB_Repeat -------------------------------- -------------------------------- ---- 35 Renaming Movie and Video Files -------------------------------- ----------- 35 Deleting Movies and Video Files -------------------------------- ------------ 36 Managing Music -------------------------------------------------------------- 37 Playing Music -------------------------------- -------------------------------- - 37 Creating a Playlist -------------------------------- ---------------------------- 38...
- Page 8 Menu Language -------------------------------- -------------------------------- ------- 52 Time -------------------------------- -------------------------------- -------------------- 52 HDD Format -------------------------------- -------------------------------- ---------- 52 Restore Default -------------------------------- -------------------------------- ------- 52 Photo Options -------------------------------- -------------------------------- - 53 Slide Show Timing -------------------------------- -------------------------------- --- 53 Transition Effect -------------------------------- -------------------------------- ------ 53 Background Music -------------------------------- -------------------------------- --- 53 Browsing All Media ---------------------------------------------------------- 53 APPENDIX A ....................
-
Page 9: Getting Started
Network HDD Recorder User Manual Getting started Network HDD Recorder introduction The Network HDD Recorder is designed for a s imple, trouble-free installation combining a feature rich media management package with versatile recording capabilities. The compact design and connection flexibility make it ideal for home or office use, supporting wired and WiFi connectivity for simple, secure access to your media content. -
Page 10: Optional Items
Optional items 3.5” Hard Disk Drive WiFi Dongle PowerLine Ethernet bridge For more information see Installing the optional hard disk drive on page 12 and Wireless LAN Setup on page 47. Network HDD Recorder Tour Front View Item Description Power LED Shows power status and errors (green/orange) (see below for more details) -
Page 11: Power Led Behavior
Network HDD Recorder User Manual Power LED Behavior LED state System condition Solid green Power on and operation normal Solid orange Standby Alternating: System starting up – approximately 7 seconds Green (0.5 secs) Orange (1.5 secs) System shutting down – 10 to 13 seconds Start up and shutdown times depend on HDD size Alternating: Green (0.5 secs) -
Page 12: Remote Control
Remote control Item Description Power Power on/off the recorder TV System Cycle through NTSC Interlace, NTSC Progressive, PAL Interlaced and PAL Progressive output Video In Display input source Record Begin/resume recording Time-Shift Pauses live TV and begins recording for later viewing Access USB content Schedule- Display and edit the recording schedule... - Page 13 Network HDD Recorder User Manual Item Description Home Display the main menu Source Cycle through input sources (see note below) Display Displays media information during playback and recording Menu Quick access to the media menu hotkeys Access HDD content Network Access network content CM skip Forward the current media for 30...
-
Page 14: Installation
Installation Installing the remote batteries The remote control unit does not contain batteries when shipped. To insert the batteries, perform the following steps: Remove the battery compartment cover by pushing the locking catch and lifting the cover in the direction of the arrow. -
Page 15: Installing The Optional Hard Disk Drive
Network HDD Recorder User Manual Installing the optional hard disk drive The recorder does not include an HDD as standard. To install the optional 3.5” SATA HDD, perform the following steps: Remove the nine (9) screws from the rear of the recorder as shown. Carefully remove the back panel and disconnect the fan cable as shown. - Page 16 Lift the HDD tray off as shown. Insert the HDD into the HDD tray and secure the four (4) screws to hold the HDD in its place. Ensure that the HDD is inserted the correct way (up, label is visible). Place the HDD tray back onto its place as shown.
- Page 17 Network HDD Recorder User Manual Connect the two (2) HDD cables to the HDD and to the board as shown. Slide the casing back onto its place as shown. You may need to apply pressure to the front panel as shown when locating the casing.
-
Page 18: Making Connections
Making connections Your Network HDD Recorder has a full set of Input and Output ports for maximum connection versatility. Input connection The following diagram demonstrates the ports used for input connections. Input devices include DVD players, TV Component to DVD Box/Set-Top-Box and VHS recorders AV to VCR (SDTV only). -
Page 19: Peripheral Connection
Network HDD Recorder User Manual Peripheral Connection The following diagram demonstrates the ports used for connecting peripheral Mini USB to PC devices. Peripherals include external HDDs and USB devices such as the optional WiFi Dongle. USB host to external HDD or pen drive Connecting to a Network Your Network HDD Recorder supports the connection to an existing Local Area Network (LAN) with or without Dynamic Host Configuration Protocol... -
Page 20: Powering On The Recorder
Powering on the recorder After creating the desired connections, perform the following steps to power on the recorder: Connect the power cable and DC power adapter. Plug the power cable into a power outlet. Plug the DC adapter into the power jack on the rear panel of the recorder. The Power LED lights green and the startup splash screen displays. -
Page 21: Using The Standby Mode
Network HDD Recorder User Manual Using the remote control or navigation buttons on the front panel of the recorder, select the desired Menu Language from the submenu and press The Time menu is highlighted. Select Manual from the submenu. Enter the date and time as directed then press to confirm. -
Page 22: Formatting The Hard Disk Disk
Formatting the Hard Disk Disk The optional 3.5” Hard Disk Drive (HDD) must be formatted before use. To format your HDD, perform the following steps: Using the remote control or navigation buttons on the front panel of the recorder, select Setup from the Main menu and press The Setup menu displays. - Page 23 Network HDD Recorder User Manual Select OK to continue. The Partitioning screen displays. Using navigation buttons, select the partitioning ratio. Changes made are shown on the screen. The FAT32 partition is named HDD1 and the NTFS partition is named HDD2 on the media screens.
- Page 24 The Congratulations screen displays once the formatting process has been completed. Select OK to complete the process.
-
Page 25: Installing The Transcode Server
Network HDD Recorder User Manual Installing the Transcode Server The Network HDD Recorder requires the Transcode Server software to run .rm, .rmvb, H.264, and .mkv format files. You must install the Transcode Server on all computers that are included in the file share scheme. To install the Transcode Server, perform the following steps: Insert the supplied software CD into... - Page 26 The Transcode Setup Wizard screen displays. Click Next. The Select Installation Folder screen displays. Click Next to use the default installation folder or Browse to a specific location. The Ready to Install screen displays.
- Page 27 Network HDD Recorder User Manual Click Install to begin the installation. A successful installation will be displayed by the Completion screen. Click Finish and reboot your computer to complete the installation. After rebooting, the Transcode Server program starts automatically and the main menu displays.
-
Page 28: Adding Content To Transcode Server
Adding Content to Transc ode Server After installing Transcode Server on all network computers, you must add the folders containing the .rm, .rmvb, H.264, and .mkv format files. Adding the folders to Transcode Server allows the recorder to read the specialized format files. - Page 29 Network HDD Recorder User Manual Click OK and follow the instructions to share a folder manually using Windows. Refer to Windows Help in Start Help and Support for more information on sharing folders. Net Share Dialog displays the manually shared folder. Click Add to display the browser screen.
- Page 30 Browse to the location of the content folder and click OK. You must add each folder individually. The new folder is added to the Net Share Dialog box.
-
Page 31: Using The Network Hdd Recorder
Network HDD Recorder User Manual Using the Network HDD Recorder The main menu The Main menu is the default display after the initial setup is complete. Use the seven icons displayed to access all the features of the recorder. Icon Menu Description Video In... -
Page 32: Menu Elements
Menu elements The media menus consist of four panels disp laying information about the currently selected media type and location. See the following example screen. Item Description Menu name Displays the current menu name. Displays the media file location, name and file Navigation panel type. -
Page 33: The Video In Menu
Network HDD Recorder User Manual If Transcode Server is installed on the source computer, .rm, .rmvb, .wmv, H.264, and .mkv video formats are also supported. Transcode Server does not support playbac k for these formats from the internal HDD. You must play them from their original network location. -
Page 34: Recording Using Time-Shift
Recording using Time-Shift The Time-Shift feature allows you to pause live TV feed for viewing at a later date. To start Time-Shift recording, perform the following steps: Press Video In on the remote control to view the TV feed you intend to record. Press Time-Shift on the remote control. - Page 35 Network HDD Recorder User Manual Enter the desired schedule information and press Select Confirm to edit the schedule. The new entry is added to the Schedule screen.
-
Page 36: Managing Movies And Video
Managing Movies and Video Press the Movie button on the remote control or select Play Movies and Video Clips from the Main menu to access the Movies menu. The Movie menu only displays video content (.avi, .mpg, .vob, .asf, .ifo, .dat, .mp4, .ts, .DivX... -
Page 37: Using Ab_Repeat
Network HDD Recorder User Manual Using AB_Repeat AB_Repeat allows you to watch your favorite part of a movie on a continuous loop. To use AB_Repeat, perform the following steps: AB_Repeat is only available for DivX, Xvid (avi), VOB and TS file formats. -
Page 38: Deleting Movies And Video Files
Deleting Movies and Video files You can only delete content from a FA T32 partition. NTFS content is read-only. Using the remote control or navigation buttons on the front panel of the recorder, select the desired media in the Navigation panel and press on the remote. -
Page 39: Managing Music
Network HDD Recorder User Manual Managing Music Press the Music button on the remote control or select Play Music from the Main menu to access the Music menu. The Music menu only displays audio content ( .mp3, .wma, .wmv .pcm and .wav). Other types of media are hidden. Playing Music Using the remote control or navigation buttons on the front panel of the recorder, select the desired media in the Navigation panel and... -
Page 40: Creating A Playlist
Creating a Playlist The Playlist is used to store your favorite music media in a single, easy to access list. You can add music to the Playlist from HDD and USB without moving the content from the original location. To create a Playlist, perform the following steps: Using the remote control or navigation buttons on the front panel of the recorder, select the desired media in the Navigation panel and press Select. -
Page 41: Renaming Music Files
Network HDD Recorder User Manual Renaming Music files You can only rename content from a FAT32 partition. NTFS content is read-only. Using the remote control or navigation buttons on the front panel of the recorder, select the desired media in the Navigation panel and press on the remote. -
Page 42: Managing Photos
Managing Photos Press the Photo button on the remote control or select Display Photo and Slideshow from the Main menu to access the Photo menu. The Photo menu only displays image content ( .jpg and .bmp). Other types of media are hidden. Viewing Photos Using the remote control or navigation buttons on the front panel of the recorder, select the desired media in the Navigation panel... -
Page 43: Renaming Photo Files
Network HDD Recorder User Manual You can save slideshow content in your HDD, USB or network folders as long as all the desired photos are loc ated in the same folder. Press the Setup button on the remote control or select Enter Setup Menu from the Main menu. -
Page 44: Deleting Photos Files
Deleting Photos files You can only delete content from a FAT32 partition. NTFS content is read-only. Using the remote control or navigation buttons on the front panel of the recorder, select the desired media in the Navigation panel and press on the remote control. -
Page 45: Copying Files
Network HDD Recorder User Manual Copying Files Press the button on the remote control or select Copy Files Between Storage Media from the Main menu to access the File Copy menu. To copy files from one location to another, perform the following steps: In the Source panel, select the device containing the original content and press In the Destination panel, select the device to receive the copied... -
Page 46: Deleting Multiple Files
Deleting multiple files The Recycle feature allows you to quickly delete multiple files from a specified location without deleting them individually through the media menus. To recycle files, perform the following steps: In the Source panel, select the device containing the desired content and press In the Destination panel, select Recycle and press In the Source panel, navigate to the desired content and press Select... -
Page 47: Managing System Settings
Network HDD Recorder User Manual Managing System Settings Press the Setup button on the remote control or select Enter Setup Menu from the Main menu to access the Setup menu. Video and Audio Options Video and Audio options are used to alter the appearance of the output signal and set the audio output mode. -
Page 48: Recording Options
Recording Options Recording options set the recording quality and where recorded content is saved. Quality Set the video recording quality. On a sliding scale from high to low quality, select from: Setting Quality Memory Used High Quality (HQ) Highest Most Short Play (SP) Extended Play (EP) Long Play (LP) -
Page 49: Network Options
Network HDD Recorder User Manual Network Options Network options define wired (LAN) and wireless (WLAN) connection information. Wireless connection is only available with having an optional WiFi Dongle accessory installed. Wired LAN Setup Your Network HDD Recorder supports conne ction to the LAN through DHCP IP or Fixed (Static) IP. -
Page 50: Wireless Lan Setup
Select Fixed IP (Manual) and press A submenu displays IP Address, Subnet Mask and Default Gateway. Enter a valid IP address from your LAN, typically 192.168.1. n (where n=1 to 254). The Subnet Mask is entered automatically and should not be changed. Enter a Default Gateway IP address if known, otherwise leave the default. - Page 51 Network HDD Recorder User Manual Select Infrastructure (AP) and press the navigation button. The Get SSID Name screen displays. Select Auto to scan for available Service Set Identifiers (SSIDs). A list of available SSIDs displays, showing security method and signal strength. Select the desired SSID from the list and press the navigation button.
-
Page 52: Using Ad Hoc (Peer-To-Peer) Mode
Using Ad Hoc (Peer-to-Peer) Mode The Ad Hoc (or Peer -to-Peer) mode allows the Network HDD Recorder to communicate directly with other wireless devices such as notebooks, without the need to connect to a wireless Access Point. Before proceeding, ensure that the optional WiFi Dongle is installed in the recorder and the peer wireless device (or notebook) is active. - Page 53 Network HDD Recorder User Manual The Ad Hoc Setup screen displays. Press the navigation button to display the Save and Startup screen. Select OK and press . Ad Hoc Testing begins. When the connection is verified, the Test OK screen displays the connection information.
-
Page 54: System Options
System Options System Options are used to configure device settings such as the OSD Menu Language and Time and to perform system maintenance. Menu Language To change the OSD language, perform the following steps: Using the remote control or navigation buttons on the front panel of the recorder, select Menu Language and press Select the desired language from the submenu and press The selected language change is applied immediately. -
Page 55: Photo Options
Network HDD Recorder User Manual Photo Options Photo options are used to configure photo display settings suc h as Slide Show Timing and Background Music. Slide Show Timing Set the interval between slides in a photo slideshow. Transition Effect Set the transition effect between slides in a photo slideshow. Background Music Set the source of musical background for slide shows. -
Page 56: Updating Firmware
Appendix A Updating Firmware Firmware describes any type of software that controls the internal workings of a device. Firmware updates are created for a number of reasons, most commonly to correct operational bugs or to introduce enhanced functions. From time-to-time, new versions of firmware become available and the recorder should be kept up-to-date with the latest firmware version. -
Page 57: Troubleshooting
Network HDD Recorder User Manual Appendix B Troubleshooting Connection Issues No image or a faulty image is displayed on my screen. If the display output settings are incorrect, the resulting image may be faulty. Check if all cable connections are secure and correctly assigned. Press TV System on the remote to cycle through the settings until a normal screen is displayed. -
Page 58: I Cannot Connect To The Network
I cannot connect to the network. Check if all cable connections are secure and correctly assigned. Check if the LAN/WLAN settings in the Setup menu are matching to the local network. Refer to your router or wireless access point User Manual for more information. -
Page 59: My Avi Caption File Doesn't Display
To resolve the issue, perform the following steps: Press Select on the remote to acknowledge the message. Reconnect the Wireless link. See Wireless LAN Setup on page 47 Replay the media file. The recorder does not support playback of .rmvb format files from the internal HDD. www.lc-power.com...
