LevelOne HVE-9211T Quick Installation Manual page 3

Panel Description 1-port Transmitters
HVE-9211T / HVE-9211PT
5 4
10
HVE-9211PTL
2
1
6
1) Power Indicator 2) Rx Link Active
4) IR Cable In
7) HDMI Out
10) Power In
9
3
7
5) IR Cable Out
8) HDMI In
2 1
6
8
5
8 9
3) HDCP Link Port 1
6) RS-232 Port
9) RJ-45 Out
4
10
7
3
