Page 1: User Manual
LevelOne User Manual HVE-6501T/6501R HDMI over IP PoE Transmitter/Receiver Ver 1.0... -
Page 2: Table Of Contents
Table of Contents HVE-650 series HDMI over IP PoE T/R ............3 GETTING THE BEST RESULTS ..............4 Device Appearance Description ..............5 System Components: ................... 6 Installation: ....................8 Link Utility ....................13 How to Download Bonjoursdksetup.exe ............17... -
Page 3: Hve-650 Series Hdmi Over Ip Poe T/R
Product Overview LevelOne HVE-650 series are high performance HDMI over IP PoE distribution system. Designed with transmitting units(HVE-6501T) and receiving units (HVE-6501R). it allows you to can simultaneously send out an HDMI to one or more HDMI display. The HVE-650 series is designed for everything from small domestic installations to large commercial applications. -
Page 4: Getting The Best Results
GETTING THE BEST RESULTS Many factors influence the quality and reliability of an HDMI® signal distribution installation. The following are the main factors to consider, and basic precautions that will ensure the best possible performance. 1. Dedicated network. The HVE-650/660 Series is designed to operate on a dedicated Gigabit Ethernet network, not to be combined with other network traffic or with access to the internet. -
Page 5: Device Appearance Description
Device Appearance Description LED Behavior Function Description Function LED Behavior Description DATA Blinking Blinking while data transmission Ethernet link, no data transfer Ethernet no link, no data transfer Link On/off/blinking Connect status for T or R On/off/blinking Power status Check List of LED State and action LED State DEVICE State Host... -
Page 6: System Components
System Components: HVE-6501 Transmitter Specifications: 1 GIGA LAN(802.3af PoE): UTP/STP 1000Mbps Ethernet Port 1 HDMI IN: 19-pin type A female 1 DB-F RS232 Port Power : DC5V/1A or 802.3af PoE GROUP ID: 4-pin DIP switch able to set up 16 groups ... -
Page 7: Specifications
HVE-6501 Receiver Specifications: 1 GIGA LAN(802.3af PoE) : UTP/STP 1000Mbps Ethernet 1 HDMI Out: 19-pin type A female 1 DB-M RS232 Port Power jack : DC5V/1A or 802.3af PoE 1 DATA LED 1 LINK LED ... -
Page 8: Installation
Installation: HVE-6501T Transmitter DC5V: Connect it to the external AC adapter which plugs into an electrical outlet. Or via 802.3af PoE PSE to GIGA LAN port. GIGA LAN: Connect directly to a Receiver or to a GIGA(1000Mbps) Ethernet Switch using CAT5e/6 cable. - Page 9 Receiver DC5V: Connect to the supplied AC adapter and plug into an electrical outlet. GIGA LAN: Connect directly to a Transmitter or to a GIGA(1000Mbps) Ethernet Switch using CAT6 cable. HDMI OUT: Connect to an HDMI display device with an HDMI M-M cable. Use an HDMI -->...
- Page 10 Configurations - Extend the Full HD source up to 100 meters over a single CAT6 cable. - Distribute the Full HD source to many of remote displays. - Connect up to 16 Transmitters with many of remote displays through the IGMP-enabling Gigabit Ethernet Switches to construct a right-sized matrix you need.
- Page 11 - Each Transmitter (source) requires 150Mbps bandwidth for broadcasting 1080p, so Fiber Optic connection between Ethernet Switches is recommended for many-to-many application. - Support cascading Ethernet Switches up to 3 layers. RESET Button Descriptions : Button State HVE6501T(Host) HVE-6501R(Client) Button Button 1 Button 2 Short Press...
- Page 12 EDID usage. During multicast setup, there maybe monitor/TV that has lower resolution. For example, 1 monitor/TV with 720p resolution with mostly 1080p solutions. Please select the monitor/TV with lowest resolution, to ensure all can be displayed correctly. For customer that are using 1 pair of Host/Client with Multicast mode, the end user must update EDID correctly.
-
Page 13: Link Utility
Link Utility The Link Utility is working with Widows XP Service Pack 2 or later O/S version. It is suggested to operate with O/S of ： Windows XP Service Pack 3 Windows Vista Service Pack 2 Windows 7 Either at the website of http://developer.apple.com/networking/bonjour/ or the CD in the package, you may download bonjoursdksetup.exe and execute the program. - Page 14 Reset Default : When click it, the device is reset to default, click Reboot to complete Reboot : click it for rebooting. TV Wall : when the firmware is for TV Wall mode,(Host Name prefix is HVE-6601), the webpage is showing below: Please refere to How to Setting TV Wall document.
- Page 15 Get Information : Click this to show all devices Mac address, IP address, Host Name, Baud rate, Group ID. And save for other configuration profile in .csv file sub-name. Notes: Please remove MAC ID used on other LAN card to prevent the MAC ID conflict. The device will automatically create the IP address of 169.254.x.x which is assigned to HDMI TX/RX LAN card IP.
- Page 16 You need to delete the routing information circled by red line. The instruction is: Referencing : route delete 157.0.0.0 MASK 255.0.0.0 157.55.80.1 destination^ ^mask ^gateway...
-
Page 17: How To Download Bonjoursdksetup.exe
How to Download Bonjoursdksetup.exe 1. Log-n the webpage of http://developer.apple.com/opensource/ 2. Drag down the web page and click “Bonjour SDK for Windows” 3. Apply ID or use the registered ID and password. - Page 18 4. You may see the page while click “Join now”. Click the red line circled and get the link. 5. Click “Get Started” 6. Select “Create Apple ID” and click “Continue”. Follow the steps to complete the registration procedure. 7. You may get your Apple ID and password after registration completion. File this Apple ID and password on Step 3 and click “Sign in”.
- Page 19 Click to execute the program or save for future installation.
