SERVICE MANUAL
CD/DVD player
Laser
Semiconductor laser
Signal format system
NTSC
Audio characteristics
Frequency response
DVD (PCM 96 kHz): 2 Hz to 44 kHz
(±1 dB)*
DVD (PCM 48 kHz): 2 Hz to 22 kHz
(±0.5 dB)
CD: 2 Hz to 20 kHz (±0.5 dB)
Signal-to-noise ratio
More than 115 dB (LINE OUT (AUDIO 1,
2) connectors only)
Harmonic distortion
Less than 0.0025%
Dynamic range
More than 100 dB (DVD)
More than 97 dB (CD)
Wow and flutter
Less than detected value
(±0.001% W PEAK)
Outputs and inputs
Jack
Output
type
level
LINE OUT
Phono
2 Vrms
(AUDIO 1, 2)
jacks
(at 50 kilohms)
DIGITAL OUT
Optical
–18 dBm
(OPTICAL)
output
connector
DIGITAL OUT
Phono
0.5 Vp-p
(COAXIAL)
jack
LINE OUT
Phono
1.0 Vp-p
(VIDEO 1, 2)
jacks
S VIDEO OUT
4-pin
Y: 1.0 Vp-p
(1, 2)
mini DIN
C: 0.286 Vp-p
COMPONENT
phono
Y: 1.0 Vp-p
VIDEO OUT
jacks
(Y, P
/B-Y,
P
B
P
/R-Y)
P
R
0.7 Vp-p
PHONES
Phone
12 mW
jack
5.1CH
Phono
2 Vrms
OUTPUT
jacks
(at 50 kilohms)
MICROFILM
SPECIFICATIONS
Load impedance
Over 10 kilohms
Wave length: 660 nm
75 ohms terminated
75 ohms,
sync negative
75 ohms,
sync negative
75 ohms terminated
75 ohms,
sync negative
/B-Y,
B
/R-Y:
R
75 ohms
32 ohms
Over 10 kilohms
DVP-S533D
General
Power requirements
110 to 240 V AC, 50/60 Hz
Power consumption
16 W
430 × 95 × 305 mm
Dimensions (approx.)
(17 × 3
incl. projecting parts
Mass (approx.)
3.4 kg (7 lb 8 oz)
Operating temperature
41°F to 95°F (5°C to 35°C)
Operating humidity
5% to 90%
Supplied accessories
• Audio/Video/S-link connecting cord (1)
• S video cable (1)
• Plug adaptor (1)
• Remote commander (remote) RMT-D108A (1)
• Size AA (R6) batteries (2)
* The signals from LINE OUT (AUDIO 1, 2) connectors and 5.1 ch L, R
connectors are measured. When you play the PCM sound tracks with
96 kHz sampling frequency, the output signals from the DIGITAL OUT
(OPTICAL, COAXIAL) are converted to 48 kHz (sampling fre-
quency).
Design and specifications are subject to change without notice.
RMT-D108A
PX Model
× 12 in.) (w/h/d)
3
/
4
CD/DVD PLAYER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVP-S533 and is the answer not in the manual?

Questions and answers

Related Manuals for Sony DVP-S533

Summary of Contents for Sony DVP-S533

  • Page 1 DVP-S533D RMT-D108A SERVICE MANUAL PX Model SPECIFICATIONS CD/DVD player General Laser Power requirements Semiconductor laser 110 to 240 V AC, 50/60 Hz Signal format system NTSC Power consumption 16 W 430 × 95 × 305 mm Dimensions (approx.) (17 × 3 ×...
  • Page 2 LINE WITH MARK ! ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB- LISHED BY SONY.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Section Title Page Section Title Page Service Note ................4 SW-317 (SURROUND SWITCH), FR-150 (IR/POWER SWITCH) Printed Wiring Boards ....4-52 GENERAL SW-317 (SURROUND SWITCH), FR-150 (IR/POWER SWITCH) Schematic Diagram ....4-53 HS-030SF (SWITCHING REGULATOR) This Player Can Play the Following Discs ....1-1 Printed Wiring Board .............

  • Page 4: Service Note

    SERVICE NOTE 1. DISASSEMBLY • This set can be disassembled in the order shown below. Case (Page 2-1) Power Tray Cover MB-85 Board AU-212 Board Block (Page 2-2) (Page 2-1) (Page 2-1) (Page 2-1) Mechanism Front Panel Deck (Page 2-2) (Page 2-2) Tray (Page 2-2)
  • Page 5 2. NOTE ON REMOVE THE CASE 4. HOW TO SERVICE MB-85 BOARD 1) Remove seven screws. (See Fig. 1) 1) Remove the case from the set. (Refer to 2-1) 2) Open the side of case. (See Fig. 1) 2) Remove the MB-85 board. (Refer to 2-2) 3) Remove the case as lift straight.

  • Page 6: General

    DVP-S533D SECTION 1 This section is extracted from in- GENERAL struction manual (3-867-038-11).
  • Page 15 1-10...
  • Page 16 1-11...
  • Page 17 1-12...
  • Page 18 1-13...
  • Page 19 1-14 E 1-14...

  • Page 20: Disassembly

    DVP-S533D SECTION 2 DISASSEMBLY Note: Follow the disassembly procedure in the numerical order given. 2-1. CASE REMOVAL 2-3. POWER BLOCK REMOVAL 4 Case 1 Connector 2 Three connectors (CN101) (CN201, 202, 203) 2 Two screws 1 Three screws 3 Four screws (B3) 3 Two screws 4 Power block...

  • Page 21: Tray Cover Removal

    2-5. TRAY COVER REMOVAL 2-7. MECHANISM DECK REMOVAL 4 Tray cover 3 Screw 3 Two claws (B3) 4 Mechanism deck 2 Two flat cables (CN003, 004) 2 Pull the tray in the direction of the arrow B. 1 Connector (CN001) 1 Insert a tapering driver into the aperture of the unit bottom, and move the lever of chuck cam in the direction of the arrow A.

  • Page 22: Optical Pick-Up Removal

    2-9. OPTICAL PICK-UP REMOVAL 2-10. BELT, LOADING MOTOR (M001), MS-46, TK-51 BOARD REMOVAL 1 Belt 5 Optical pick-up 4 Three step 2 Two screws screws (B2.6 × 4) 3 Remove the base unit holder in the direction of the arrow A. 9 TK-51 board 6 Flexible board (CN001)

  • Page 23: Internal View

    2-11. INTERNAL VIEW DC motor (loading) Optical pick-up (KHM-220AAA/J1RP) 1-541-632-11 8-820-081-03...

  • Page 24: Circuit Boards Location

    2-12. CIRCUIT BOARDS LOCATION TK-51 Power Block (HS-030SF) (RF/SERVO) (SWITCHING REGULATOR) FR-150 AU-212 (IR/POWER SWITCH) (AUDIO) HP-111 (HEADPHONE) MS-46 (LOADING) SW-317 MB-85 (SURROUND SWITCH) (SIGNAL PROCESS/SERVO) FL-101 (FUNCTION SWITCH) 2-5 E...

  • Page 25: Block Diagrams

    DVP-S533D SECTION 3 BLOCK DIAGRAMS 3-1. OVERALL BLOCK DIAGRAM MB-85 BOARD (SEE PAGE 4-19 to 37) IC304 IC402, 403 16M DRAM 16M SDRAM BASE UNIT TK-51 BOARD AU-212 BOARD KHM-220AAA (SEE PAGE 4-11) (SEE PAGE 4-41, 43) VIDEO V, OPTICAL DEVICE VIDEO Y, IC321 VIDEO 1, 2...

  • Page 26: Rf/Servo Block Diagram

    DVP-S533D 3-2. RF/SERVO BLOCK DIAGRAM IC001%¢(DVD play) BASE UNIT TK-51 BOARD MB-85 BOARD(1/6) (SEE PAGE 4-23, 25) (SEE PAGE 4-11) 500mV/DIV 100ns/DIV KHM-220AAA IC0011(DVD play) IC001$º(CD play) IC001$º(DVD play) 200mV/DIV 100ns/DIV IC701^•(DVD play) 500mV/DIV 50ms/DIV 100mV/DIV 50ms/DIV IC701^ª(DVD play) 100mV/DIV 5ms/DIV 500mV/DIV 50ms/DIV 1.5Vp-p IC001%¢(CD play)

  • Page 27: Signal Process/Video Block Diagram

    DVP-S533D 3-3. SIGNAL PROCESS/VIDEO BLOCK DIAGRAM MB-85 BOARD(2/6) (SEE PAGE 4-19, 21, 27, 35) IC303!¶(DVD play) 500mV/DIV 100ns/DIV IC304 IC402, 403 16M DRAM 16M SDRAM IC401%¢  1.6Vp-p IC401%•  IC303!ª(CD play) 500mV/DIV 200ns/DIV 720mVp-p(H) 1.0Vp-p(H) AU-212 BOARD(1/3) 1.6Vp-p (SEE PAGE 4-41, 43) 136-139 154-157 105-108...

  • Page 28: System Control Block Diagram

    DVP-S533D 3-4. SYSTEM CONTROL BLOCK DIAGRAM MB-85 BOARD(3/6) (SEE PAGE 4-29, 31, 33) IC204 IC206 1M SRAM 16M FLASH HA 0-21 SIGNAL PROCESS, VIDEO +3.3V IC207 AUDIO 1 (SEE PAGE 3-5) HD 0-15 IC201 POWER ON (SEE PAGE 3-9) 146-154 126-133 4K EEPROM RESET...

  • Page 29: Audio (1) Block Diagram

    DVP-S533D 3-5. AUDIO (1) BLOCK DIAGRAM MB-85 BOARD(4/6) (SEE PAGE 4-33, 35) SPDIF IC501 IC902 AUDIO DSP AUDIO 2CH DAC BCKO BCLKIN V OUT L AUDIOLT BCKI LRCK LRCKI LRCKO LRCIN V OUT R AUDIORT ACH12 CH78O D IN ZERO ZFLT CH12I ACH34...

  • Page 30: Audio (2) Block Diagram

    DVP-S533D 3-6. AUDIO (2) BLOCK DIAGRAM AU-212 BOARD(2/3) J502 MB-85 BOARD(5/6) (SEE PAGE 4-41, 43) (SEE PAGE 4-35) Q341 COAXIAL BUFFER INTERFACE DIGITAL IC505 A MUTE CONTROL D IN (SEE PAGE 3-14) OPTICAL MA MUTE J505 SYSTEM CONTROL (SEE PAGE 3-7,8) GAIN2 AUDIO OUT1 IC431...

  • Page 31: Interface Control Block Diagram

    DVP-S533D 3-7. INTERFACE CONTROL BLOCK DIAGRAM MB-85 BOARD(6/6) AU-212 BOARD(3/3) (SEE PAGE 4-29, 35) (SEE PAGE 4-41, 43) CN301 CN005 J501 SLINK S-LINK FL-101 BOARD CN202 CN006 (SEE PAGE 4-47, 49) SLINK IC203 FR-150 BOARD (SEE PAGE 4-53) S-LINK SCLK1 IFSC0 CONTROL STATUS IN...

  • Page 32: Power Block Diagram

    DVP-S533D 3-8. POWER BLOCK DIAGRAM HS-030SF BOARD AU-212 BOARD (SEE PAGE 4-57) (SEE PAGE 4-41, 43) B301 +12V IC301 IC401 CN201 CN101 D101 +9V REG P211 +12V +12V IC431 T101 F101 L101, 102 IC502 P311 Q101-103 LINE IC541 SWITCH +3.3V P611 +3.3V –12V...

  • Page 33: Printed Wiring Boards And Schematic Diagrams

    DVP-S533D SECTION 4 PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS THIS NOTE IS COMMON FOR PRINTED WIRING For schematic Diagram: • Caution when replacing chip parts. BOARDS AND SCHEMATIC DIAGRAMS. New parts must be attached after removal of chip. (In addition to this, the necessary mote is printed Be careful not to heat the minus side of tantalum capacitor, in each block.) because it is damaged by the heat.

  • Page 34: Frame Schematic Diagram

    DVP-S533D 4-1. FRAME SCHEMATIC DIAGRAM FRAME (1) SCHEMATIC DIAGRAM FRAME (1/2)
  • Page 35 DVP-S533D FRAME (2) SCHEMATIC DIAGRAM FRAME (2/2)

  • Page 36: Printed Wiring Boards And Schematic Diagrams

    DVP-S533D There are few cases that the part isn't mounted in this model is printed on this diagram. 4-2. PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS TK-51 TK-51 (RF/SERVO) PRINTED WIRING BOARD BOARD(SIDE A) – Ref. No.: TK-51 board; 2,000 series – TK-51 BOARD (SIDE A) CN001 CN002...
  • Page 37 DVP-S533D • Waveforms 6 IC001 #ª (CD play) 1 IC001 1 (DVD play) TK-51 200 mV/DIV 100 ns/DIV 500 mV/DIV 200 ms/DIV BOARD(SIDE B) 536 mVp-p 1.7 Vp-p 2 IC001 1 (CD play) 7 IC001 $º (DVD play) 100 mV/DIV 50 ms/DIV 500 mV/DIV 500 ns/DIV 880 mVp-p 180 mVp-p...

  • Page 38: Rf/Servo) Schematic Diagram

    DVP-S533D TK-51 (RF/SERVO) SCHEMATIC DIAGRAM • See page 4-7 for printed wiring board and page 4-10 for waveforms. – Ref. No.: TK-51 board; 2,000 series – Note: The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified.

  • Page 39: Loading) Printed Wiring Board And Schematic Diagram

    DVP-S533D MS-46 (LOADING) PRINTED WIRING BOARD AND SCHEMATIC DIAGRAM – Ref. No.: MS-46 board; 3,000 series – There are few cases that the part isn't mounted in this model is printed on this diagram. MS-46 BOARD S001 (TRAY SENSOR) S001 CN001 LOADING MOTOR...

  • Page 40: Signal Process/Servo) Printed Wiring Board

    DVP-S533D MB-85 (SIGNAL PROCESS/SERVO) PRINTED WIRING BOARD There are few cases that the part isn't mounted in this model is printed on this diagram. – Ref. No.: MB-85 board; 1,000 series – MB-85 BOARD (SIDE A) CN001 CN002 CN003 CN004 CN005 CN006 CN007...
  • Page 41 DVP-S533D MB-85 BOARD (SIDE B) D701 D806 IC005 IC201 IC203 IC204 IC207 IC304 IC402 IC403 IC404 IC702 IC801 IC802 IC803 IC902 IC905 IC906 IC907 SIGNAL PROCESS/SERVO MB-85 4-17 4-18...

  • Page 42: Av Decoder) Schematic Diagram

    DVP-S533D MB-85 (AV DECODER) SCHEMATIC DIAGRAM • See page 4-15 for printed wiring board. – Ref. No.: MB-85 board; 1,000 series – AV DECODER MB-85 (1/10) 4-19 4-20...

  • Page 43: Sdram) Schematic Diagram

    DVP-S533D MB-85 (SDRAM) SCHEMATIC DIAGRAM • See page 4-15 for printed wiring board. – Ref. No.: MB-85 board; 1,000 series – • Waveforms 1 IC401 %¢ 5 IC401 ^™ 720 mVp-p (H) 816 mVp-p (H) 2 IC401 %¶ 6 IC401 ^∞ 728 mVp-p (H) 1.2 Vp-p (H) 3 IC401 %•...

  • Page 44: Servo Dsp) Schematic Diagram

    DVP-S533D MB-85 (SERVO DSP) SCHEMATIC DIAGRAM • See page 4-15 for printed wiring board. – Ref. No.: MB-85 board; 1,000 series – • Waveforms 1 IC701 ^ª (DVD play) 500 mV/DIV 50 ms/DIV 1.4 Vp-p 2 IC701 ^ª (CD play) 500 mV/DIV 200 mV/DIV 1.7 Vp-p 3 IC701 ^•...

  • Page 45: Drive) Schematic Diagram

    DVP-S533D MB-85 (DRIVE) SCHEMATIC DIAGRAM • See page 4-15 for printed wiring board. – Ref. No.: MB-85 board; 1,000 series – DRIVE MB-85 (4/10) 4-25 4-26...

  • Page 46: Arp) Schematic Diagram

    DVP-S533D MB-85 (ARP) SCHEMATIC DIAGRAM • See page 4-15 for printed wiring board. – Ref. No.: MB-85 board; 1,000 series – • Waveforms 1 IC303 !¶ (DVD play) 500 mV/DIV 100 ns/DIV 1.6 Vp-p 2 IC303 !ª (CD play) 500 mV/DIV 200 ns/DIV 1.6 Vp-p MB-85 (5/10) 4-27...

  • Page 47: System Control) Schematic Diagram

    DVP-S533D MB-85 (SYSTEM CONTROL) SCHEMATIC DIAGRAM • See page 4-15 for printed wiring board. – Ref. No.: MB-85 board; 1,000 series – • Waveforms 1 IC202 (™ 2.4 Vp-p (12.5 MHz) 2 IC202 5 4 Vp-p (25.3 MHz) SYSTEM CONTROL MB-85 (6/10) 4-29 4-30...

  • Page 48: Hga) Schematic Diagram

    DVP-S533D MB-85 (HGA) SCHEMATIC DIAGRAM • See page 4-15 for printed wiring board. – Ref. No.: MB-85 board; 1,000 series – MB-85 (7/10) 4-31 4-32...

  • Page 49: Clock Generator, Audio Dsp) Schematic Diagram

    DVP-S533D MB-85 (CLOCK GENERATOR, AUDIO DSP) SCHEMATIC DIAGRAM • See page 4-15 for printed wiring board. – Ref. No.: MB-85 board; 1,000 series – • Waveforms 1 IC004 2, 5, 7 6IC001 !¢ (DVD play) 4.2 Vp-p (26.9 MHz) 4.2 Vp-p (25.3 MHz) 7 IC001 !¢...

  • Page 50: Dac) Schematic Diagram

    DVP-S533D MB-85 (DAC) SCHEMATIC DIAGRAM • See page 4-15 for printed wiring board. – Ref. No.: MB-85 board; 1,000 series – MB-85 (9/10) 4-35 4-36...

  • Page 51: Bias) Schematic Diagram

    DVP-S533D MB-85 (BIAS) SCHEMATIC DIAGRAM • See page 4-15 for printed wiring board. – Ref. No.: MB-85 board; 1,000 series – BIAS MB-85 (10/10) 4-37 4-38...

  • Page 52: Audio, Video Buffer) Printed Wiring Board

    DVP-S533D AU-212 (AUDIO, VIDEO BUFFER) PRINTED WIRING BOARD There are few cases that the part isn't mounted in this model is printed on this diagram. – Ref. No.: AU-212 board; 2,000 series – AU-212 BOARD CN301 CN302 CN303 CN401 D301 A-11 D304 D305...

  • Page 53: Au-212 (Audio) Schematic Diagram

    DVP-S533D AU-212 (AUDIO) SCHEMATIC DIAGRAM – Ref. No.: AU-212 board; 2,000 series – AUDIO AU-212 (1/2) 4-41 4-42...

  • Page 54: Video Buffer) Schematic Diagram

    DVP-S533D AU-212 (VIDEO BUFFER) SCHEMATIC DIAGRAM • See page 4-39 for printed wiring board. • Waveforms – Ref. No.: AU-212 board; 2,000 series – 1 IC321 2 6 IC321 !∞ 1.1 Vp-p (H) 2.0 Vp-p (H) 2 IC321 4 1.2 Vp-p (H) 3 IC321 7 860 mVp-p (H) 4 IC321 !º...

  • Page 55: Function Switch, If Con

    DVP-S533D FL-101 (FUNCTION SWITCH, IF CON) PRINTED WIRING BOARD There are few cases that the part isn't mounted in this model is printed on this diagram. – Ref. No.: FL-101 board; 2,000 series – FL-101 BOARD FL-101 BOARD CN201 PROGRAM CLEAR CN202 C-10...

  • Page 56: Fl-101 (Function Switch) Schematic Diagram

    DVP-S533D FL-101 (FUNCTION SWITCH) SCHEMATIC DIAGRAM • See pages 4-45 for printed wiring board. – Ref. No.: FL-101 board; 2,000 series – FUNCTION SWITCH FL-101 (1/2) 4-47 4-48...

  • Page 57: Fl-101 (If Con) Schematic Diagram

    DVP-S533D FL-101 (IF CON) SCHEMATIC DIAGRAM • See pages 4-45 for printed wiring board. – Ref. No.: FL-101 board; 2,000 series – • Waveform 1 IC201 !¢ 3.9 Vp-p (4 MHz) IF CON FL-101 (2/2) 4-49 4-50...

  • Page 58: Hp-111 (Headphone) Printed Wiring Board And Schematic Diagram

    DVP-S533D HP-111 (HEADPHONE) PRINTED WIRING BOARD AND SCHEMATIC DIAGRAM SW-317 (SURROUND SWITCH), FR-150 (IR/POWER SWITCH) PRINTED WIRING BOARDS – Ref. No.: HP-111 board; 2,000 series – – Ref. No.: SW-317 board and FR-150 board; 4,000 series – There are few cases that the part isn't mounted in this model is printed on this diagram. FR-150 BOARD FR-150 BOARD...

  • Page 59: Surround Switch), Fr-150 (Ir/Power Switch) Schematic Diagram

    DVP-S533D SW-317 (SURROUND SWITCH), FR-150 (IR/POWER SWITCH) SCHEMATIC DIAGRAM – Ref. No.: SW-317 board and FR-150 board; 4,000 series – SURROUND SWITCH, IR/POWER SWITCH SW-317, FR-150 4-53 4-54...

  • Page 60: Hs-030Sf (Switching Regulator) Printed Wiring Board

    DVP-S533D HS-030SF (SWITCHING REGULATOR) PRINTED WIRING BOARD – Ref. No.: HS-030SF board; 6,000 series – There are few cases that the part isn't mounted in this model is printed on this diagram. HS-030SF BOARD CN101 CN102 CN201 CN202 CN203 D101 D102 D104 D105...

  • Page 61: Hs-030Sf (Switching Regulator) Schematic Diagram

    DVP-S533D HS-030SF (SWITCHING REGULATOR) SCHEMATIC DIAGRAM – Ref. No.: HS-030SF board; 6,000 series – HS-030SF BOARD T101 L211 P211 D211 10uH CN201 8P 500mA 60V S2L20U +3.3V C112 0.047uF 630V Q103 C211 C213 2SK2333 47uF 330uF AU-212 BOARD B301 R152 +12V L150 SWITCH...
  • Page 62 DVP-S533D SECTION 5 INTERFACE, IC PIN FUNCTION DESCRIPTION 5-1 E...

  • Page 63: Test Mode

    DVP-S533D SECTION 6 TEST MODE 6-1. GENERAL DESCRIPTION ### Syscon Diagnosis ### Diag All Check The Test Mode allows you to make diagnosis and adjustment eas- No. 2 Version ily using the remote commander and monitor TV. The instructions, diagnostic results, etc. are given on the on-screen display (OSD). 2-3.
  • Page 64 4. Servo Selecting 2 and subsequent items executes respective menus and outputs the results. For the contents of each submenu, see “Check Items List”. (4-2) Servo DSP Check Data write → read, and accord check General Description of Checking Method Error 12: Read data discord Data 0x9249, 0x2942, 0x4294 are written to the address 2.
  • Page 65 6. AV Decoder (5-4) ARP to RAM Address Bus Data write → other address read discord check (6-2) 1930 RAM Error 10: ARP → RAM address bus error Data write → read, and accord check Caution: Address and data display in case of an error is Error 13: AVD RAM read data discord different from the display of other diagnosis (de- The program code data stored in ROM (IC206) are copied...
  • Page 66 Check Items List Error Codes List 2) Version 00: Error not detected (2-2) Revision 01: RAM write/read data discord (2-3) ROM Check Sum 02: Gate array NG (2-4) Model Type 03: EEPROM NG (2-5) Region 08: ARP register read data discord 09: ARP ←→...

  • Page 67: Drive Auto Adjustment

    6-4. DRIVE AUTO ADJUSTMENT 1. DVD-SL (single layer) [ENTER] Select , insert DVD single layer disc, and press key, and the adjustment will be made through the following steps, then On the Test Mode Menu screen, press key on the remote com- adjusted values will be written to the EEPROM.
  • Page 68 2. CD 3. DVD-DL (dual layer) [ENTER] [ENTER] Select , insert CD disc, and press key, and the adjust- Select , insert DVD dual layer disc, and press key, ment will be made through the following steps, then adjusted val- and the adjustment will be made through the following steps, then ues will be written to the EEPROM.

  • Page 69: Drive Manual Operation

    4. SACD 6-5. DRIVE MANUAL OPERATION [ENTER] Select , insert SACD disc, and press key, and the adjustment will be made through the following steps, then adjusted On the Test Mode Menu screen, select , and the manual opera- values will be written to the EEPROM. However, if SACD disc is tion menu will be displayed.
  • Page 70 0. Disc Check Memory Disc Type 1. Disc Type Auto Check Disc Check 2. DVD SL 12 cm 3. DVD DL 12 cm 4. CD 12cm 5. SACD 12 cm 1. SL Disc Check 6. DVD SL 8 cm 2. CD Disc Check 7.

  • Page 71: Mecha Aging

    6-6. MECHA AGING Reset SLED TILT Reset the Sled and Tilt to initial posi- tion. ### Mecha Aging ### Turn ON/OFF the laser. Turn ON/OFF the spindle. Press OPEN key Focus Search the focus and turn on the focus. Turn ON/OFF the tracking servo. Sled Turn ON/OFF the sled servo.

  • Page 72: Version Information

    How to see Emergency History 6-8. VERSION INFORMATION ## Version Information ## IF con. Ver. x. xxx (xxxx) Group SYScon. Ver. x. xxx (xxxx) Model Region 1 : Emergency Code 2 : Don’t Care These codes are used for verification of software designing. 3 : Historical order 1 to 9 Exit: RETURN Emergency Codes List...

  • Page 73: Electrical Adjustments

    DVP-S533D SECTION 7 ELECTRICAL ADJUSTMENTS 7-1. POWER SUPPLY ADJUSTMENT In making adjustment, refer to 7-3. Adjustment Related Parts Arrangement. 1. Power Supply Check (HS-030SF BOARD) Note: During diagnostic check, the characters and color bars can Mode be seen only with the NTSC monitor. Therefore, for diag- nostic check, use the monitor that supports both NTSC and Instrument Digital voltmeter...

  • Page 74: Adjustment Of Video System

    7-2. ADJUSTMENT OF VIDEO SYSTEM 3. Checking Component Video Output B-Y (MB-85 BOARD) <Purpose> 1. Video Level Adjustment (MB-85 BOARD) This checks component video output B-Y. If it is incorrect, cor- <Purpose> rect colors will not be displayed when connected to, for instance, This adjustment is made to satisfy the NTSC standard, and if not projector.

  • Page 75: Checking Component Video Output Y (Mb-85 Board)

    5. Checking Component Video Output Y 7-3. ADJUSTMENT RELATED PARTS ARRANGEMENT (MB-85 BOARD) <Purpose> MB-85 BOARD (SIDE A) This checks component video output Y. If it is incorrect, correct brightness will not be attained when connected to, for instance, projector. CN005 Mode Video level adjustment in test mode...

  • Page 76: Repair Parts List

    DVP-S533D SECTION 8 REPAIR PARTS LIST 8-1. EXPLODED VIEWS NOTE: • -XX and -X mean standardized parts, so they may • The mechanical parts with no reference number in The components identified by mark have some difference from the original one. the exploded views are not supplied.

  • Page 77: Front Panel Assembly

    X-3949-908-1 PANEL ASSY, FRONT 3-054-218-01 BUTTON, JOG 3-054-221-01 WINDOW (FL) 3-054-224-31 STICK, CURSOR 3-974-997-31 WINDOW, REMOTE CONTROL 1-418-097-11 ENCODER, ROTARY 4-963-404-21 EMBLEM (5-A), SONY 4-951-620-01 SCREW (2.6X8), +BVTP 3-053-954-01 BUTTON, POWER 1-790-167-11 CABLE, FLEXIBLE FLAT (FMF-35) X-3949-836-1 BUTTON (VES) ASSY * 118...

  • Page 78: Chassis Assembly

    8-1-3. CHASSIS ASSEMBLY Mechanism deck supplied supplied supplied supplied supplied supplied supplied supplied The components identified by mark ! or dotted line with mark ! are criti- cal for safety. Replace only with part number speci- fied. Ref. No. Part No. Description Remark Ref.

  • Page 79: Mechanism Deck Assembly

    8-1-4. MECHANISM DECK ASSEMBLY M001 The components identified by mark ! or dotted line with mark ! are criti- cal for safety. Replace only with part number speci- fied. Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark * 201 A-6065-275-A TK-51 BOARD, COMPLETE...

  • Page 80: Electrical Parts List

    AU-212 8-2. ELECTRICAL PARTS LIST NOTE: The components identified by • Due to standardization, replacements in the • Items marked “*” are not stocked since they mark ! or dotted line with mark parts list may be different from the parts speci- are seldom required for routine service.
  • Page 81 AU-212 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C571 1-104-664-11 ELECT 47uF FB403 1-414-553-11 FERRITE C572 1-104-664-11 ELECT 47uF FB404 1-414-553-11 FERRITE C573 1-163-130-00 CERAMIC CHIP 360PF FB405 1-414-553-11 FERRITE C574 1-163-020-00 CERAMIC CHIP 0.0082uF 10% FB406 1-414-553-11 FERRITE C575...
  • Page 82 AU-212 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark JR431 1-216-295-91 SHORT R316 1-216-097-91 RES, CHIP 100K 1/10W JR432 1-216-295-91 SHORT R317 1-216-073-00 METAL CHIP 1/10W JR433 1-216-295-91 SHORT R318 1-216-097-91 RES, CHIP 100K 1/10W JR434 1-216-295-91 SHORT R319 1-216-097-91 RES, CHIP...
  • Page 83 AU-212 FL-101 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R458 1-216-041-00 METAL CHIP 1/10W R590 1-216-025-91 RES, CHIP 1/10W R459 1-216-041-00 METAL CHIP 1/10W R591 1-216-025-91 RES, CHIP 1/10W R460 1-216-041-00 METAL CHIP 1/10W R592 1-216-049-91 RES, CHIP 1/10W R461...
  • Page 84 FL-101 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark IC203 8-759-356-27 IC NJM2129M-TE2 R222 1-216-053-00 METAL CHIP 1.5K 1/10W R223 1-216-055-00 METAL CHIP 1.8K 1/10W < JUMPER RESISTOR > R224 1-216-059-00 METAL CHIP 2.7K 1/10W JR201 1-216-295-91 SHORT R225 1-216-061-00 METAL CHIP...
  • Page 85 FL-101 FR-150 HP-111 MB-85 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark S215 1-771-349-21 SWITCH, KEYBOARD (DVD MENU) S216 1-771-349-21 SWITCH, KEYBOARD (RETURN) < TRANSFORMER > S217 1-771-349-21 SWITCH, KEYBOARD (PREV =) S218 1-771-349-21 SWITCH, KEYBOARD (+ NEXT) T001 1-433-748-11 TRANSFORMER, DC-DC CONVERTER S221...
  • Page 86 MB-85 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C212 1-162-970-11 CERAMIC CHIP 0.01uF C443 1-162-970-11 CERAMIC CHIP 0.01uF C213 1-162-970-11 CERAMIC CHIP 0.01uF C505 1-162-970-11 CERAMIC CHIP 0.01uF C304 1-110-563-11 CERAMIC CHIP 0.068uF C506 1-162-970-11 CERAMIC CHIP 0.01uF C307 1-125-822-11 TANTALUM...
  • Page 87 MB-85 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C836 1-115-467-11 CERAMIC CHIP 0.22uF FB008 1-469-324-21 FERRITE FB010 1-469-116-21 FERRITE C837 1-115-467-11 CERAMIC CHIP 0.22uF FB011 1-469-116-21 FERRITE C904 1-163-021-91 CERAMIC CHIP 0.01uF C905 1-163-021-91 CERAMIC CHIP 0.01uF FB012 1-469-116-21 FERRITE...
  • Page 88 MB-85 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark FL005 1-234-177-21 FILTER, CHIP EMI < TRANSISTOR > FL006 1-234-177-21 FILTER, CHIP EMI Q801 8-729-015-74 TRANSISTOR UN5111-TX FL008 1-234-177-21 FILTER, CHIP EMI Q802 8-729-230-63 TRANSISTOR 2SC4116-YG FL009 1-234-177-21 FILTER, CHIP EMI Q803 8-729-230-63 TRANSISTOR 2SC4116-YG...
  • Page 89 MB-85 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R323 1-216-833-11 METAL CHIP 1/16W R701 1-216-805-11 METAL CHIP 1/16W R702 1-216-817-11 METAL CHIP 1/16W R324 1-216-833-11 METAL CHIP 1/16W R325 1-216-833-11 METAL CHIP 1/16W R703 1-216-817-11 METAL CHIP 1/16W R326 1-216-833-11 METAL CHIP...
  • Page 90 MB-85 MS-46 POWER BLOCK Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R842 1-216-844-11 METAL CHIP 1/16W S002 1-762-386-11 SWITCH, PUSH (CHUCK SENSOR) R843 1-216-844-11 METAL CHIP 1/16W R844 1-216-843-11 METAL CHIP 1/16W 1-468-359-21 POWER BLOCK (HS-030SF) R845 1-216-843-11 METAL CHIP 1/16W...
  • Page 91 POWER BLOCK SW-317 TK-51 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark < PHOTO COUPLER > C018 1-164-739-11 CERAMIC CHIP 560PF ! PC101 8-749-010-59 PHOTO COUPLER TLP721F C019 1-164-172-11 CERAMIC CHIP 0.0056uF 10% ! PC102 8-749-010-59 PHOTO COUPLER TLP721F C020 1-107-826-91 CERAMIC CHIP 0.1uF...
  • Page 92 TK-51 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R014 1-216-864-11 METAL CHIP 1/16W R015 1-216-833-11 METAL CHIP 1/16W R016 1-216-833-11 METAL CHIP 1/16W R017 1-216-829-11 METAL CHIP 4.7K 1/16W R018 1-216-833-11 METAL CHIP 1/16W R022 1-216-811-11 METAL CHIP 1/16W R023...
  • Page 93 DVP-S533D Sony Corporation 99G05009-1D 9-921-727-11 Home Video Company Printed in Japan © 1999. 7 – 138 – Published by Quality Assurance Dept.
