ROOF-MOUNT
POWERED ATTIC VENTILATOR
READ AND SAVE THESE INSTRUCTIONS
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR
INJURY TO PERSONS, OBSERVE THE FOLLOWING:
1. Use this unit only in the manner intended by the manufacturer.
If you have questions, contact the manufacturer at the address
or telephone number listed in the warranty.
2. Before servicing or cleaning unit, switch power off at service
panel and lock the service disconnecting means to prevent
power from being switched on accidentally. When the service
disconnecting means cannot be locked, securely fasten a
prominent warning device, such as a tag, to the service panel.
3. Installation work and electrical wiring must be done by a
qualified person(s) in accordance with all applicable codes and
standards, including fire-rated construction codes and stan-
dards.
4. Sufficient air is needed for proper combustion and exhausting
of gases through the flue (chimney) of fuel burning equipment
to prevent backdrafting. Follow the heating equipment
manufacturer's guidelines and safety standards such as those
published by the National Fire Protection Association (NFPA),
and the American Society for Heating, Refrigeration and Air
Conditioning Engineers (ASHRAE), and the local code authori-
ties.
5. When cutting or drilling into wall or ceiling, do not damage
electrical wiring and other hidden utilities.
6. The wiring must be permanent. DO NOT USE AN EXTENSION
CORD! Use 14 GA. MINIMUM copper wire. Although the
Powered Attic Ventilator may be wired directly to power, we
advise that some type of shut off switch be installed in the line.
Please see the section on electrical wiring for suggested wiring
diagrams and instructions.
7. This unit must be grounded.
8. Do not use this unit with any solid state speed control device
(Models 356 and 358 only).

TOOLS AND MATERIALS REQUIRED

K
Slotted Screwdriver
K
Drill
K
1/4" Drill Bit
K
Sabre Saw or Keyhole Saw
K
Hammer
K
Ruler
Pencil
K
K
Utility Knife
K
Pry Bar (to remover roofing nails)
K
Roofing Cement
K
Galvanized Roofing Nails (1¾" min.)
K
Electrical Supplies (to comply with codes)
MODELS 350 •• 355 •• 356 •• 358
!
CAUTION
1. For general ventilating use only. Do not use to exhaust hazard-
ous or explosive materials and vapors.
2. To avoid motor bearing damage and noisy and/or unbalanced
impellers, keep drywall spray, construction dust, etc. off power
unit.
3. This unit has an unguarded impeller. Do not use in locations
readily accessible to people or animals.
4. Fan is equipped with a thermostat which may start fan auto-
matically. To reduce risk of injury or electric shock while
servicing or cleaning unit, switch power off at service panel and
lock service panel to prevent power from being switched on
accidentally. When the service disconnecting means cannot
be locked, securely fasten a prominent warning device, such
as a tag, to the service panel.
5. Home Ventilating Institute (HVI) recommends one square foot
of open air inlet per 300 cfm of fan capacity. The best location
for these air intake vents are under the eaves with direct access
to the attic. Failure to provide these intakes could cause
natural-draft gas appliances to backdraft.
6. Your attic fan installation will create a screened opening into
your attic space. During a heavy rain storm there could be a
light spray of rain into this attic space. This is a normal condition
with all attic ventilators and will not cause any damage to the
structure. We recommend that you do not store any valuable
articles directly under the fan opening in the roof. During
extreme rain and wind storms you may want to turn on your attic
ventilator to prevent excess moisture accumulation in your
attic.
7. Records show, under ideal conditions, exposed galvanized
steel can remain rust free up to 100 years. For best protection,
the exposed portion of the roof sheet should be painted,
especially in areas of unusually high industrial air pollution.
Follow paint manufacturer's instructions for good adhesion.
8. This ventilator is intended for roof installation. The Broan Model
353 Gable Mount Ventilator is available for side wall applica-
tions.
9. The dome may be painted with a high-quality paint. Follow the
paint manufacturer's recommendations for PVC plastic or
aluminum, as appropriate.
10. Please read specification label on product for further informa-
tion and requirements.
Page 1

Advertisement

loading

Summary of Contents for Broan 350

  • Page 1: Tools And Materials Required

    8. Do not use this unit with any solid state speed control device (Models 356 and 358 only). 8. This ventilator is intended for roof installation. The Broan Model 353 Gable Mount Ventilator is available for side wall applica- tions.
  • Page 2 MODELS 350 •• 355 •• 356 •• 358 Page 2 3. Drill a guide hole through the roof at this mark. 1. Locate the ventilator at the center of the rear slope of the roof. Place it as high on the roof as possible. The location should be free of obstacles (T.V.
  • Page 3 MODELS 350 •• 355 •• 356 •• 358 Page 3 6. Cut out the shingles inside of the circle. 9. Cut out the roof board(s) inside of the line. 10. For proper removal of roofing nails, draw a 22" square, 7.
  • Page 4 MODELS 350 •• 355 •• 356 •• 358 Page 4 12. Carefully lift shingles and nail flashing securely to the 13. Using a good grade of roofing cement material, seal all roof using galvanized roofing nails. of the shingles and heads of nails.
  • Page 5 MODELS 350 •• 355 •• 356 •• 358 Page 5 1. Remove the thermostat wiring box cover plate. Bring the BLACK THERMOSTAT power cable at least 6" into the ventilator wiring box. Fasten power cable to box with appropriate connector.
  • Page 6: Service Parts

    MODELS 350 •• 355 •• 356 •• 358 Page 6 SERVICE PARTS PART DESCRIPTION NUMBER 99150493 #8B-18 x 1/2 Sheet Metal Screw* (3 Required) 99110689 Plastic dome (Models 350, 355, 356) 98005419 Aluminum Dome (Model 358) 97006971 Fan Blade with Setscrew...
  • Page 7 MODELS 350 •• 355 •• 356 •• 358 Page 7 SERVICE PARTS Replacement parts can now be ordered on our website. Please visit us at www.Broan.com...
  • Page 8: Warranty

    WARRANTY ONE YEAR LIMITED WARRANTY Broan-NuTone warrants to the original consumer purchaser of its products that such products will be free from defects in materials or workmanship for a period of one year from the date of original purchase. THERE ARE NO OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
