OWNER'S MANUAL

FOR YOUR SAFETY:

DO NOT STORE OR USE GASOLINE OR OTHER

FLAMMABLE VAPORS OR LIQUIDS IN THE VICINITY

OF THIS OR ANY OTHER APPLIANCE.

CAUTION:

INSTRICTIONS TO BE FOLLOWED IN THE EVENT

THE USER SMELLS GAS SHALL BE POSTED IN A

PROMINENT LOCATION. THIS INFORMATION

SHALL BE OBTAINED BY CONSULTING THE LOCAL

GAS SUPPLIER.

Form Number: S-6109

Printed in USA

Heavy Duty 2-Burner Hot Plate

Model:

09/13

Telephone (617) 387-4100, (866) 698-3188, Fax (617) 387-4456, (800) 227-2659

□

2-HPGR

WARNING:

IMPROPER INSTALLATION, ADJUSTMENT,

ALTERATION, SERVICE OR MAINTENANCE CAN

CAUSE PROPERTY DAMAGE, INJURY OR DEATH.

READ THESE INSTALLATION, OPERATION AND

MAINTENANCE INSTRUCTIONS THOROUGHLY

BEFORE INSTALLING OR SERVICING THIS

EQUIPMENT.

35 Garvey Street, Everett, MA 02149

custserv@mfii.com, www.mfii.com

Table of Contents

Summary of Contents for Market Forge Industries 2-HPGR

Page 1 OWNER’S MANUAL Heavy Duty 2-Burner Hot Plate □ Model: 2-HPGR FOR YOUR SAFETY: WARNING: DO NOT STORE OR USE GASOLINE OR OTHER IMPROPER INSTALLATION, ADJUSTMENT, FLAMMABLE VAPORS OR LIQUIDS IN THE VICINITY ALTERATION, SERVICE OR MAINTENANCE CAN OF THIS OR ANY OTHER APPLIANCE.
Page 2: Table Of Contents
Flexible Coupling, Connectors and Casters: ................4 Check for Gas Leaks: ........................5 Disclaimer: ........................... 5 MAINTENANCE Daily Cleaning: ......................... 6 Periodic Cleaning: ........................6 Cleaning Stainless Steel: ......................6 ILLUSTRATED PARTS Exploded View ......................... 7 Complete 2-HPGR Parts List ....................8...
Page 3: Size
18” Wide x 34” High x 31-1/8” Front-to-Back (457mm Wide x 863mm High x 791mm Front-to-Back) DESCRIPTION: The Market Forge 2-HPGR consists of two burner surface units mounted on a 34” high (863mm) cabinet base. A 10”Ø (254mm) pot or pan is the maximum capacity that may be used on burners. Burners are removable ring type and shall be provided with a removable drip pan.
Page 4: Read Before Installing
INSTALLATION READ BEFORE INSTALLING Clearance: When installing against combustible surfaces (side walls) is 3” (76mm) and (rear walls) is 6” (152mm) clearance is required. When installing against non-combustible surfaces (rear or side walls) 0” clearance is required. If equipment is to be installed where the elevation exceeds 2000’609.6 meters above sea level, specify installation altitude so that proper orifices can be provided.
Page 5: Manual Shut-Off Valve
Failure to install the pressure regulator will void the equipment warranty! The regulators supplied with MARKET FORGE INDUSTRIES, INC. Ovens, have 3/4” inlet /outlet openings and are adjusted at the factory for 5” WC (Natural gas) or 10” WC (Propane gas) depending on customer’s ordering instructions.
Page 6: Check For Gas Leaks
Disclaimer: All MARKET FORGE INDUSTRIES, INC. appliances are adjusted and tested before leaving the factory, effectively matching them to sea level conditions. Adjustments and calibrations to assure proper operation may be necessary on installation to meet local conditions;...
Page 7: Maintenance
MAINTENANCE Daily Cleaning: Clean top grate(s) with warm water, mild cleaner and wire brush. Clean and brush off debris from and around the burner area. Empty and clean grease pan. Griddle plates should be cleaned with warm water and scrubbed with cleaning abrasive such as a griddle brick of fine grit type. Top surface can also be ‘bleached’...
Page 8: Illustrated Parts
ILLUSTRATED PARTS...
Page 9: Complete 2-Hpgr Parts List
ILLUSTRATED PARTS Complete 2-HPGR Parts List ITEM PART DESCRIPTION 93-5118 Top Grate 12" x 12" ( No Logo ) 93-5205 Burner Head, Removable ( No Logo ) 93-5206 18" - Long Venturi, Open Burner ( REAR ) ( No Logo ) 93-5208 6"...
