SERVICE
PORTABLE DIGITAL AUDIO PLAYER
Model : YP-W3L
PORTABLE DIGITAL AUDIO PLAYER
Basic Model : YP-W3L
* Application : YP-W3LV[256MB]
- MP3, WMA, Audio ASF and Ogg
Playback
- Removable Storage Device
- FM Reception and Recording
- SRS WOW Surround Sound
- USB 2.0 High Speed Data Transfe
- Upgradable
- Built-in Rechargeable Li-Ion Battery
- Voice Recording Function
YP-W3LX[512MB]
YP-W3LZ[1GB]
Manual
Features
- Confidential -
Advertisement
Table of Contents
Related Manuals for Samsung YP-W3L
Summary of Contents for Samsung YP-W3L
- Page 1 PORTABLE DIGITAL AUDIO PLAYER Basic Model : YP-W3L * Application : YP-W3LV[256MB] YP-W3LX[512MB] YP-W3LZ[1GB] SERVICE Manual PORTABLE DIGITAL AUDIO PLAYER Features - MP3, WMA, Audio ASF and Ogg Playback - Removable Storage Device - FM Reception and Recording - SRS WOW Surround Sound - USB 2.0 High Speed Data Transfe...
- Page 2 ELECTRONICS © Samsung Electronics Co.,Ltd. May. 2005 Printed in Korea Code no. AH68-01654J...
-
Page 3: Table Of Contents
INDEX Exploded View & Parts List Precautions 1. Total Exploded View 2. Parts List 1-1. Safety Precautions 1-2. Servicing Precautions 1-3. Precautions for Electrostatically Electrical Parts List Sensitive Device (ESDs) Electrical Parts List 1-4. Special Precations and Waring Lables for Laser Products 1-5. -
Page 4: Safety Precautions
Examples: Handle brackets, Metal Part metal cabinets, screwheads and control shafts. The current measured should not Ohmmeter exceed 0.5 milliamp. Reverse the power- plug prongs in the AC outlet and repeat. Fig. 1-2 Insulation Resistance Test Samsung Electronics... -
Page 5: Servicing Precautions
Make sure that the 8. Always connect a test instrument's ground portion around the serviced part has not lead to the instrument chassis ground been damaged. before connecting the positive lead; always remove the instrument's ground lead last. Samsung Electronics... -
Page 6: Precautions For Electrostatically
SCAN : Manufactured for Scandinavian KATSO SATEESEEN! Market. VARNING: OSYNLIG LASERSTRÅLNING NAR DENNA DEL AR OPPNAD OCH SPARREN AR URKOPPLAD BETRAKTA EJSTRÅLEN! Fig. 1-4 Warning Labels (Location: Disc Clamper, Inner Side of Unit Door or Nearby Unit Chassis ) Samsung Electronics... -
Page 7: Special Precautions For Hdd
2. In order to safe keep the data on the HDD, back up the data before the repair or make sure not to place the HDD near any electrical appliance that generates a strong magnetic field. Samsung Electronics... -
Page 8: Product Feature
Maximum data speed transfer of 70 Mbps Data Transfer Upgradable You can upgrade the built-in programs when available. Please check the home page (www.samsung.com) for upgrades. Built-In Rechargeable The built-in rechargeable lithium battery provides up to 9 hours of play time. Li-Ion Battery Voice Recording Function You can make high quality voice recordings. -
Page 9: Specifications
2 . Specifications Model YP-W3L Built-in Memory capacity 256MB(YP-W3L V), 512MB( YP-W3L X), 1GB(YP-W3L Z) Voltage 3.7V (Li-ion) Playing time lasts up to 9hours (On the basis of measurement by the company) Dimensions/Weight 52.8 X 62 X 15mm / 68g... -
Page 10: Accessories
3. Accessories Name Code No. Accessories AH69-01525B Carrying case AH30-00081A Earphones AH61-01649C USB Cable AH80-00102A Installation CD AH68-01631A User manual AH39-00731A Belt Chain AH39-00731A Necklace Samsung Electronics... -
Page 11: Basic Functions
Installation User manual USB Cable Necklace Earphones Belt Chain Model YP-W3L V YP-W3L X YP-W3L Z Built-in memory 256MB 512MB The capacity of the useable built-in memory is less than indicated as the internal firmware uses part of the memory as well. -
Page 12: To Search For Specific Parts During Play
- Loop Repeat is automatically released if you Speed Search with ˇ ˇ , ˆ ˆ . Note - The files are recorded in the order of V001,V002..,and saved as MP3 files in the VOICE folder after recording. - If the Memory is full, Voice Recording will be disabled automatically. Samsung Electronics... - Page 13 The selected frequency will be saved. Note - To save frequencies to the preset numbers automatically,select [Settings] [Environment] [FM Setting] [Auto Preset]. - You can store up to 20 frequencies. - Mono (MO) or Stereo (ST) is automatically selected. Samsung Electronics...
-
Page 14: New Functions
Select Playlist from the menu. The playlist you set will be displayed. Move to the file you want to play and press the ˆ ¨ button. " " mark appears and the selected file will be played. Playlist Playlist Return Samsung Electronics... -
Page 15: Bass Booster
Press and hold the “M” Button. Select [Settings] Clock Type Clock Type [Time] [Clock Type Set]. Analog to select Analog type or Digital type Digital for the clock display . Return When turning on the player, only analog clock type is supported. Samsung Electronics... -
Page 16: Pc Connection
3. PC Connection Upon installation of the USB driver "SAMSUNG YP-W3L USB Device" will appear in the [System Properties] [Device Manager]. Connecting the player to your PC How to check if USB driver is properly installed Windows 98/ME: For Windows 98SE, install the USB dri- System Requirements. -
Page 17: How To Recover The Device
(3) While the LLF is in progress, nothing will appear in the Explorer. (4) On the LCD, "USB transferring" message appears. (5) When the LLF is complete, the message changes to "USB Connected", and the player appears on the Explorer as a Removable Disk. Samsung Electronics... - Page 18 6. Downloading Font File (1) When the initializing process is complete, you have to disconnect the player from the PC. (2) Reconnect the player to the PC, then the player will be recognized as YP-W3L. (3) Copy ypw3font.sys on to the removable disk.
- Page 19 (1) Short R6 / R53 and connect the unit to the PC. (2) Use the TCC7xx_FW_DN program. At this time, TCC72X_Non_UMS_Driver should be installed in advance. (You can identify whether the driver has been installed in Device Manager) Samsung Electronics ªÔº∫ ¿¸¿⁄...
- Page 20 (4) Click the Write NOR button to start the download. (5) When FW_DN is complete, reconnect the player to the PC using USB interface and then run AP-Program of Step 5.(2). (6) Follow the procedures of Step 5.(3) and the following steps. Samsung Electronics...
-
Page 21: How To Upgrade Firmware
5. Confirming Upgrade Press the MENU button and select Settings System Information to confirm the updated Upgrading to the Latest Firmware in its Assembled Status Press and hold the MENU button until the Upgrade message appears. firmware version. Samsung Electronics... -
Page 22: How To Disassemble
5. How to disassemble Samsung Electronics... -
Page 23: It Keeps Being Turned Off
6. Troubleshooting 1. It keeps being turned off Samsung Electronics... -
Page 24: No Sound Can Be Heard
2. No Sound can be heard Samsung Electronics... -
Page 25: It Can Not Record Voice
3. It can not record voice Samsung Electronics ªÔº∫ ¿¸¿⁄... -
Page 26: The Buttons Does Not Work
4. The buttons does not work Samsung Electronics... -
Page 27: File Can Not Be Download
5. File can not be download Samsung Electronics... -
Page 28: Total Exploded View
7.Exploded View & Parts List 1. Total Exploded View AA165 AC020 AA164 AA167 AD230 AC320 AC080 AA211 AH425 AK420 Samsung Electronics... -
Page 29: Parts List
AH64-03380A KNOB-HOLD ASS’Y AA165 AH64-03381A KNOB-MENU ASS’Y AA167 AH64-03383A KNOB-REC ASS’Y AA211 AH64-03392A DECO-RING ASS’Y YP-W3 AH64-03373B CABINET-BOTTOM YP-W3 AC020 AH64-03373C CABINET-BOTTOM YP-W3L AH64-03372B CABINET-TOP YP-W3 AA080 AH64-03372C CABINET-TOP YP-W3L AH63-00934B COVER-USB ABS+URETHANE YP-W3 AA320 AH63-00934C COVER-USB ABS+URETHANE YP-W3L AH64-03374B... -
Page 30: Electrical Parts List
2007-000140 R-CHIP 1Kohm,5%,1/16W,TP,1005 2203-002709 C-CER,CHIP 100nF,+80-20%,16V,Y5V,-,1005 2404-001348 C-TA,CHIP 100uF,##20%,6.3V,-,TP,3.2X1.6X R105 2007-000162 R-CHIP 100Kohm,5%,1/16W,DA,TP,1005 R106 2007-001338 R-CHIP 160KOHM,5%,1/16W,TP,1005 2203-000254 C-CER,CHIP 10nF,10%,16V,X7R,1005 R107 2007-000140 R-CHIP 1Kohm,5%,1/16W,TP,1005 2203-005900 C-CER,CHIP 1000NF,+80-20%,10V,Y5V,1005 R108 2007-000162 R-CHIP 100Kohm,5%,1/16W,DA,TP,1005 2203-005089 C-CER,CHIP 0.002nF,0.25pF,50V,TH,TP,1005 R109 2007-000157 R-CHIP 47Kohm,5%,1/16W,TP,1005 Samsung Electronics... - Page 31 RESONATOR-CERAMIC 12MHz,0.1%,TP,3.2x1.3x 2007-000162 R-CHIP 100Kohm,5%,1/16W,DA,TP,1005 2801-004318 CRYSTAL-SMD 12MHz,20ppm,-,12PF,80ohm,TP 2007-000148 R-CHIP 10Kohm,5%,1/16W,DA,TP,1005 AH41-00825A PCB (FR 4) 6L(SNPB) YP-W3,FR,6,-,0.6T,-, 2007-000148 R-CHIP 10Kohm,5%,1/16W,DA,TP,1005 AH97-01473B ASSY MACHINERY-OPTION YP-W3L,YP-W3L 2007-000162 R-CHIP 100Kohm,5%,1/16W,DA,TP,1005 AH63-00934C COVER-USB YP-W3,ABS+URETHNAE,-,-,-,-,-,C 2007-000138 R-CHIP 100ohm,5%,1/16W,TP,1005 AH64-03372C CABINET-TOP YP-W3,Zn,-,-,-,-,-,Cr PLATIN 2007-000157 R-CHIP 47Kohm,5%,1/16W,TP,1005 AH64-03373C...
- Page 32 KNOB-REC ASS'Y YP-W3,ABS,-,-,-,-,-,-,-\ AH63-00933A CUSHION-REC YP-W3,SILICON,-,-,-,-,- AH64-03378B KNOB-PLAY YP-W3,ABS,-,-,-,-,Rh PLATING,- AH64-03379B KNOB-REC YP-W3,ABS,-,-,-,-,Rh PLATING,- AH64-03384C KNOB-VOLUME YP-W3,PC,1,-,-,-,-,-,INMOLD AH64-03392B DECORATION-RING ASSY YP-W3L,BRASS,-,-,-, AH64-03375B DECORATION-RING YP-W3,BRASS,-,-,-,-,Rh P AH64-03393B WINDOW-LCD YP-W3,GLASS,-,-,-,-,-,- AH97-01474A ASSY MACHINERY-COMMON YP-W3L,YP-W3L 6001-001528 SCREW-MACHINE PH,+,M1.4,L2.0,NI PLT,SWRC 6001-001739 SCREW-MACHINE CH,+,M1.4,L3.5,CR PLT...
-
Page 33: Block Diagram
9. Block Diagram Samsung Electronics... -
Page 34: Wiring Diagram
10. Wiring Diagram Ear Jack 10-1 Samsung Electronics... - Page 35 10-2 Samsung Electronics...
-
Page 36: Top Side
- This Document can be used without Samsung’s authorization - 11. PCB Diagram 1. TOP SIDE 11-1 Samsung Electronics... -
Page 37: Bottom Side
2. Bottom SIDE - This Document can be used without Samsung’s authorization - Ear Jack Samsung Electronics 11-2... -
Page 38: Main
- This Document can be used without Samsung’s authorization - 12. Schematic Diagram 1. MAIN 12-1 Samsung Electronics... -
Page 39: Circuit Board Description
- This Document can be used without Samsung’s authorization - 13. Circuit Description 1. Description of the Circuit 1-2.Main Functions by Block 1-1. Main Blocks in the Circuit Diagram 13-1 Samsung Electronics... -
Page 40: Ch14 Basic Information Of Mp3
ATRAC(3) : Adaptive TRansform Acoustic Coding (SONY) EPAC : Enhanced Perceptual Audio Coder (Luscent Technology) OGG : Ogg Vorbis DECODING : Process of recovering the digital data encoded to the data before encoding D/A : Process of converting Digital Data to Analog Data 14-1 Samsung Electronics... - Page 41 Yepp Block Diagram Samsung Electronics 14-2...
- Page 42 Flash memory is embedded to store the data even if the power is turned off and it is a super-high speed product that can record up to 250 characters per second.(mass production of 8MB, 16MB, 32MB currently at Samsung Electronics) OTP (Once Time Programmable) OTP is one type of micro controller(MCU) and is the customer-oriented semi-conductor on which the customers can directly record the program.
- Page 43 SecuMAX server and utilized as a basic data for performing user certification role. After registration, download the dedicated player and decryption key to use service. Music drive developed by Samsung Electronics is embedded with SecuMAX decryption module. Decryption key will be registered during installation of music drive. Music file downloaded from digi- tal contents music service site with SecuMAX can be played back.
-
Page 44: Mp3 Overview
Layer-2. In general, it is called MP3 since Layer-1 has compression rate of 1:4, Layer-2 of 1:61:8, Layer-3 of 1:101:12. Using MP3 technology, up to 100 songs(7 hours) can be contained in one copy of empty CD of 650MB. Transition of Portable Player 14-5 Samsung Electronics... -
Page 45: Understanding Of Digital Audio Format
16Kbps-32Kbps using [RealAUDIO G2 Music Codec] as com- pression type. Since streaming play in Internet radio is the main purpose, file does not contain copyright protection technology. “Real Player G2” supports MP3 play- back and “Real Juke Box” supports encoding from CD to MP3. Samsung Electronics 14-6... - Page 46 There is no difference in sound quality between MP3 and CD since encoding(converting CD track to MP3) is done with 44.1KHz at 16 bit. Better CD sound quality cannot be obtained by lowering the sampling rate, but the capacity can be reduced. 14-7 Samsung Electronics...
- Page 47 Of course, MP3 also supports VBR format, but has effect of reducing capacity due to VBR based on existing MP3. Ogg Vorbis file supports VBR by default and helps you enjoy high quality music with- out loss due to big width of bit rate. Samsung Electronics 14-8...
-
Page 48: Type Of Storage
/ Flash Memory : MP3 Player, Digital audio player Type of Digital audio player storage. Audio Format Table * SSFDC (Solid State Floppy Disc Card) File System * Standard file system for support of SMC's compatibility(DOS/FAT adopted) 14-9 Samsung Electronics... - Page 49 Small Form - factor Cards Comparison Samsung Electronics 14-10...
-
Page 50: Copyright
However, as online MP3 sales have resolved, the number of legal Internet site has increased. However, reproduction prevention system is required for legal sales. All Internet sites serving Korean song in MP3 are introducing reproduction prevention system. 14-11 Samsung Electronics... - Page 51 Meaning of SecuMAX System Application Most legal Internet MP3 service sites adopt SecuMAX and YEPP of Samsung and several compa- nies have hardware supporting SecuMAX among MP3 players currently distributed. Then, user needs to receive MP3 applied with SecuMAX to receive legal service. It is required to have program that can play back MP3 applied with SecuMAX technology in MP3 player.
