Installation Guide

This Installation Guide will walk you through the easy steps
to set up your ScreenBeam Mini Receiver. During this
process, we'll show you how to :
SBmini-qsg-0530-0703-000-EN v2.indd 1
A
Install the Receiver
B
Connect Using
1
Windows 8.1 or Higher
B
Connect Using Intel WiDi App
2
B
Connect Using WiFi
3
Miracast-Enabled Device
Wireless Display
Receiver
Model # SBWD50A
Part No: 0530-0703-000
2014/3/7 14:26:51

Advertisement

loading
Need help?

Need help?

Do you have a question about the SBWD50A ScreenBeam Mini and is the answer not in the manual?

Questions and answers

Summary of Contents for ActionTec SBWD50A ScreenBeam Mini

  • Page 1: Installation Guide

    Wireless Display Receiver Model # SBWD50A Installation Guide This Installation Guide will walk you through the easy steps to set up your ScreenBeam Mini Receiver. During this process, we’ll show you how to : Install the Receiver Connect Using Windows 8.1 or Higher Connect Using Intel WiDi App Connect Using WiFi Miracast-Enabled Device...
  • Page 2 Welcome! Congratulations on your purchase of a ScreenBeam Mini Wireless Display Receiver. The Mini Wireless Display Receiver connects to your compatible Intel WiDi or Miracast wireless display-capable device, and displays the device’s screen on your HDTV. Install the Receiver Step Get the ScreenBeam Mini Wireless Display Receiver, USB cable and HDMI cable from the ScreenBeam Mini box.
  • Page 3 Step Turn on your TV and switch the input source until you see the Ready to Connect screen. Note: If you cannot plug the Receiver into an HDMI port on your TV (due to other components, or a poorly accessible port), use the supplied HDMI cable to connect the Receiver.
  • Page 4 The ScreenBeam Mini Receiver is now connected to your HDTV. Proceed to one of the next three sections of this Guide (depending on the device you are using to connect to ScreenBeam Mini) to finish the connection procedure. Connect Using Windows 8.1 or Higher Step From the Windows desktop, navigate to the Charms menu and...
  • Page 5 Enter the PIN as displayed on the television screen, then connect and display. Note: If you are running Windows 8.1 and the screens above do not appear, go to http://www.actiontec.com/widi81 for the latest software updates. SBmini-qsg-0530-0703-000-EN v2.indd 5 2014/3/7 14:26:52...
  • Page 6 Connect Using Intel WiDi App Note: 1. If your device’s OS is Windows 8.1 or higher, proceed to section B (“Connect Using Windows 8.1 or Higher”) for connection instructions. 2. ScreenBeam Mini only supports the 2.4GHz wireless fre- quency. Make sure your device is not connected to a 5GHz wireless router prior to connecting ScreenBeam Mini.
  • Page 7 Step Wait until the Receiver displays a PIN on the HDTV, and a PIN entry box on the screen of the WiDi device. Enter the PIN in the PIN entry box on the WiDi device, then click Continue. Step The HDTV displays messages to show the status of the connection process.
  • Page 8 Note: Make sure the device supports Intel Wireless Display (WiDi) software version 3.5 or higher. To find out what version of Intel WiDi your device has, enter the Intel WiDi application and click Help, then navigate to the “About WiDi” section. To obtain the latest Intel WiDi software and drivers, go to: http://www.intel.com/go/wirelessdisplayupdate Connect Using Miracast-Enabled Device...
  • Page 9 Wait for the device to associate with the Receiver. When it does, the device’s screen will be displayed on the HDTV. Product Support & Additional Information Go to http://international.actiontec.com/support for prod- uct support, updates, and more information including: • Firmware Updates • Troubleshooting • Registration • FAQs SBmini-qsg-0530-0703-000-EN v2.indd 9...
  • Page 10 Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Actiontec Electronics, Inc, may void the user’s authority to operate the equipment. Declaration of conformity for products marked with the FCC logo – United States only.
  • Page 11 The transmitter must not be co-located or operating in conjunction with any other antenna or transmit- ter. For questions regarding your product or the FCC/Industry Canada declaration, contact: Actiontec Electronics, Inc. 760 North Mary Avenue, Sunnyvale, CA 94086, United States Tel: (408) 752-7700 Fax: (408) 541-9005 SBmini-qsg-0530-0703-000-EN v2.indd 11...
  • Page 12: Warranty

    Go to http://www.actiontec.com/products/warranty.php for information. © 2014 Actiontec Electronics, Inc. ScreenBeam Pro and the Actiontec logo are registered trademarks or trademarks of Actiontec Electronics, Inc., in the U.S. or other countries. All other names are properties of their respective owners.
