3. Hardware Installation

Attach one end of the Ethernet cable with RJ-45 connector to your computer's Ethernet
port, and the other end to one of the LAN ports of your router.
Connect the Ethernet cable attaching to your Cable/ADSL modem to the WAN port of
your router.
Connect the single DC output connector of the power adapter to the power jack on the side
of the router. Then plug the Power Adapter into an AC outlet.

4. LED indicators

LED
SYS
WAN
Wireless 11N 150Mbps Broadband Router Quick Installation Guide
Figure 3-1
Function
Power on
CPU on
Flashing
WLAN ACT
WPS working (orange)
On
WAN Connection normal
2
