Repotec WR5822 Quick Installation Manual

802.11ac dual band concurrent gigabit wlan router
Hide thumbs

Advertisement

Quick Links

Download this manual
802.11ac Dual Band Concurrent
Gigabit WLAN Router
Quick Installation Guide
V1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the WR5822 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Repotec WR5822

Summary of Contents for Repotec WR5822

  • Page 1 802.11ac Dual Band Concurrent Gigabit WLAN Router Quick Installation Guide V1.0...
  • Page 3 802.11ac Dual Band Concurrent GbE WLAN Router WEEE Directive & Product Disposal At the end of its serviceable life, this product should not be treated as household or general waste. It should be handed over to the applicable collection point for the recycling of electrical and electronics equipment, or returned to the supplier for disposal.

  • Page 4: System Requirements

    802.11ac Dual Band Concurrent GbE WLAN Router System Requirements Pentium 200MHZ processor or above Windows 98SE, Windows Me, Windows 2000, Windows XP, Windows Vista, Windows 7, Windows 8, Windows 8.1 and Windows 10. 64MB of RAM or above. 25MB free disk space Package Content 802.11ac Dual Band Concurrent GbE WLAN Router CD-ROM (Software &...

  • Page 5: Installation And Setup

    802.11ac Dual Band Concurrent GbE WLAN Router Installation & Setup Follow each STEP carefully and only go to the next step once you have completed the previous STEP. STEP 1 Connection of 802.11ac WLAN AP Router Step 1. Connect the Ethernet cable to WAN Port Connect the RJ45 Ethernet cable from your xDSL/Cable Modem's Ethernet port to 802.11ac WLAN Router's WAN Port.

  • Page 6: Led Meaning

    802.11ac Dual Band Concurrent GbE WLAN Router LED Meaning Your 802.11ac WLAN Router has indicator lights on the front side. Please see below for an explanation of the function of each indicator light. Power indicator Ethernet Active indicator Wireless Active indicator WPS Active indicator Ethernet Active indicator Table1.
  • Page 7 802.11ac Dual Band Concurrent GbE WLAN Router Connectors Table 2 shows the function of each connector and switch of the device. Table 2. Function / Description of Connectors Connector Description ANTENNA 2 fixed Antenna ON/OFF Power on / off the device SWITCH POWER Connects to the supplied power adaptor...
  • Page 8 802.11ac Dual Band Concurrent GbE WLAN Router Figure1. Rear View of the 802.11ac WLAN Router Figure2. WPS/ WLAN button Figure3. RESET button...

  • Page 9: Configuration Procedures

    802.11ac Dual Band Concurrent GbE WLAN Router STEP 2 Configuration Procedures Before starting the 802.11ac WLAN Router configuration, please kindly configure the PC computer as below, to have automatic IP address / DNS Server. For Windows 98SE/ME/2000/XP Click on "Start" -> "Control Panel" (in Classic View). In the Control Panel, double click on "Network Connections"...
  • Page 10 802.11ac Dual Band Concurrent GbE WLAN Router Double click on "Internet Protocol (TCP/IP)". Check "Obtain an IP address automatically" and "Obtain DNS server address automatically" then click on "OK" to continue Click "Show icon in notification area when connected" (see screen image in 3.
  • Page 11 802.11ac Dual Band Concurrent GbE WLAN Router For Windows Vista-32/64 Click on "Start" -> "Control Panel" -> "View network status and tasks". In the Manage network connections, click on "Manage network connections" to continue. Single RIGHT click on "Local Area connection", then click "Properties".
  • Page 12 802.11ac Dual Band Concurrent GbE WLAN Router The screen will display the information "User Account Control" and click "Continue" to continue. Double click on "Internet Protocol Version 4 (TCP/IPv4)". Check "Obtain an IP address automatically" and "Obtain DNS server address automatically" then click on "OK" to continue.
  • Page 13 802.11ac Dual Band Concurrent GbE WLAN Router For Windows 7-32/64 Click on "Start" -> "Control Panel" (in Category View) -> "View network status and tasks". In the Control Panel Home, click on "Change adapter settings" to continue. Single RIGHT click on "Local Area connection", then click "Properties".
  • Page 14 802.11ac Dual Band Concurrent GbE WLAN Router Double click on "Internet Protocol Version 4 (TCP/IPv4)". Check "Obtain an IP address automatically" and "Obtain DNS server address automatically" then click on "OK" to continue.
  • Page 15 802.11ac Dual Band Concurrent GbE WLAN Router For Windows 8/8.1-32/64 Move the mouse or tap to the upper right corner and click on “Settings”. Click “Control Panel”.
  • Page 16 802.11ac Dual Band Concurrent GbE WLAN Router Click on “View network status and tasks”. In the Control Panel Home, click on “Change adapter settings” to continue. Single RIGHT click on "Ethernet", then click "Properties".
  • Page 17 802.11ac Dual Band Concurrent GbE WLAN Router Double click on "Internet Protocol Version 4 (TCP/IPv4)". Check "Obtain an IP address automatically" and "Obtain DNS server address automatically" then click on "OK" to continue.
  • Page 18 802.11ac Dual Band Concurrent GbE WLAN Router For Windows 10-32/64 Right click on Network icon , then click "Open Network and Sharing Center" . In the Control Panel Home, click on “Change adapter settings” to continue. Single RIGHT click on "Ethernet", then click "Properties".
  • Page 19 802.11ac Dual Band Concurrent GbE WLAN Router Double click on "Internet Protocol Version 4 (TCP/IPv4)". Check "Obtain an IP address automatically" and "Obtain DNS server address automatically" then click on "OK" to continue.
  • Page 20 802.11ac Dual Band Concurrent GbE WLAN Router STEP 3 802.11ac WLAN Router Configuration Before you begin to execute utility CD Installations, please ensure the 802.11ac WLAN AP Router has been powered on. Please insert the supplied CD into your CD-ROM drive. The CD should auto-start, displaying the window shown in 4.
  • Page 21 802.11ac Dual Band Concurrent GbE WLAN Router From the head menu, click on SETUP. Click on Gateway and then click on Next. WAN Interface Setup DHCP From the WAN Access Type drop-down list, select DHCP Client setting. If you are happy with your settings, click on Next...
  • Page 22 802.11ac Dual Band Concurrent GbE WLAN Router Fixed IP From the WAN Access Type drop-down list, select DHCP client setting. Enter Local IP Address, Subnet Mask, Default Gateway and DNS which was given by Telecom or by your Internet Service Provider (ISP). If you are happy with your settings, click on Next PPPoE From the WAN Access Type drop-down list, select PPPoE setting.
  • Page 23 802.11ac Dual Band Concurrent GbE WLAN Router PPTP From the WAN Access Type drop-down list, select PPTP setting provided by your Network Administrator or ISP. Click on the ratio of Dynamic IP (DHCP) or Static IP. Enter IP Address for example 172.1.1.1 provided by your Network Administrator or ISP.
  • Page 24 802.11ac Dual Band Concurrent GbE WLAN Router L2TP From the WAN Access Type drop-down list, select L2TP setting provided by your Network Administrator or ISP. Click on the ratio of Dynamic IP (DHCP) or Static IP. Enter IP Address for example 172.1.1.1 provided by your Network Administrator or ISP.
  • Page 25 802.11ac Dual Band Concurrent GbE WLAN Router Click on Next. Wireless Configuration - 5GHz Enter SSID. 10. Click on Next.
  • Page 26 802.11ac Dual Band Concurrent GbE WLAN Router 11. From the Encryption list, choose the Encryption type and enter related parameters if necessary, as None / WEP / WPA2(AES) and WPA2 Mixed Mode (the default settings Security Mode = None). For example, the Encryption you choose is None.
  • Page 27 802.11ac Dual Band Concurrent GbE WLAN Router 15. From the Encryption list, choose the Encryption type and enter related parameters if necessary, as None / WEP / WPA2(AES) and WPA2 Mixed Mode (the default settings Security Mode = None). For example, the Encryption you choose is None.

  • Page 28: Wireless Connection

    802.11ac Dual Band Concurrent GbE WLAN Router Wireless Connection For easy installation it is saved to keep the settings. You can later change the wireless settings via the wireless configuration menu. (see user manual on the CD – Chapter 10/11 and other) Double click on the wireless icon on your computer and search for the wireless network that you enter SSID name.
  • Page 29 802.11ac Dual Band Concurrent GbE WLAN Router If the wireless network isn’t encrypted, click on "Connect " to connect.
  • Page 30 802.11ac Dual Band Concurrent GbE WLAN Router If the wireless network is encrypted, enter the network key that belongs to your authentication type and key. (the default settings Security Mode = None). You can later change this network key via the wireless configuration menu.
