Summary of Contents for Blue PURE 121
- Page 1 Index Air Purifier Breathe freely English User Manual Pure 121 120VAC, 60 Hz...
- Page 2 Index Hello!
-
Page 3: Table Of Contents
Index Index Meet Blue® 04–05 What’s in the box 06–07 Usage 08–09 Setup On/off & operating speeds 11–13 Care and maintenance 16–19 Functionality 20–23 Safety 24–25 Specifications... -
Page 4: Meet Blue
Meet Blue You just made a wise decision to improve your health and your life. Thank you for choosing Blue® to clean the room air in your home. Before you start, please take a few minutes to become familiar with... -
Page 5: Meet Blue
Meet Blue Clean Air Blue® is designed to clean air in a room up to 57 m2 (613 sq. ft) in size. Five times per hour, Blue® replaces room air containing contaminants with fresh air. Filter Replacement To ensure your Blue air purifier is running in... -
Page 6: What's In The Box
What´ s in the Box Blue package The air purifier Blue® Particle filter. - Page 7 What´ s in the Box Options and add-ons A combination of active carbon filter and particle filter.
-
Page 8: Usage
Getting the most from Blue ® Close all windows and doors. Run your Blue® 24 hours a day. With Blue®, you get clean air that’s free of these potentially harmful air- borne contaminants: » Smoke » Dust » Pet dander »... -
Page 9: Usage
Placement Place Blue® in an upright position on the floor in your room. Choose a location where air can circulate freely into, out of and around the unit. The minimum recommend- ed distance to any adjacent object is 10 cm or 4”. -
Page 10: Setup
Getting started! Plug in your Blue air purifier. Touch the button to turn it on. It automatically sets itself to the rec- ommended energy-effi- cient operating speed. When the indicator light glows light blue, your unit is working properly. Then go ahead and take a deep breath of fresh air. -
Page 11: On/Off & Operating Speeds
on/off & operating speeds Button control/functions Change filter indicator When the indicator turns yellow, it’s time to order a new replace- ment filter. To acknoledge you got the information of the yellow filter replace- ment message, simply touch the indicator button for 5 seconds. - Page 12 & operating speeds On/off button control To choose the operating speed, touch the Blue® button. The white light indicates the speed selected . On/Low. Touch once to turn the unit on and set it to the recommended ener- gy-efficient speed.
-
Page 13: On/Off & Operating Speeds
& operating speeds Using Blue in your bedroom? Don’t worry. The light automatically switches itself off after 15 seconds so it won’t disturb your sleep. High. Touch three times for high speed. Off. Touch once more to turn the unit off. -
Page 16: Care And Maintenance
Care and MaintenanCe General care Take good care of your Blue® air purifier to ensure that it delivers optimal performance. Occasionally wipe the exterior of the unit with a dry dust cloth. Be sure to unplug the unit before changing the main filter. - Page 17 Care and MaintenanCe Change the main filter When the indicator light glows red, it’s time to change the main filter. Turn off the unit and unplug it. Gently press the re- lease buttons on both sides of the unit until you hear a click.
- Page 18 Care and MaintenanCe Change the main filter Lift off the top of the unit. Remove the main filter from the unit. Insert the replacement filter into the unit.
- Page 19 Replace the top of the unit, pressing firmly until you hear a click. Plug in the unit. To reset the unit, press the Blue on/off button for five seconds. The indicator will flash for five seconds, then change from red to...
-
Page 20: Functionality
funCtionality How it works The ion chamber continuously releases a flow of negatively charged ions into the air in the room. Airborne particles in the room pick up this negative charge and are drawn into the system through the 360o air inlet at bottom of unit. - Page 21 The main filter captures all particles down to 0.1 microns in size. Blue manages to deliver clean air at a rate of 680 cubic meters per hour or 400 cubic feet per minute.
- Page 22 funCtionality...
- Page 23 funCtionality Blueprint » Air outlet » Ion chamber – Air stream optimizer » Inner wall » Fan » Motor » Fan holder » Finger protection » Release button for filter » Exterior casing » Particle filter » Air inlet 360°...
-
Page 24: Safety
® appliance. Please read these safety instructions carefully before use and take the necessary precautions to reduce the risk of fire, electric shock or injury. The Blue warranty ® applies only if the unit is used accordingly to these instructions. - Page 25 If the power cord is damaged, you must have it replaced by Blue®, a service center authorized by Blue® or similarly qualified persons in order to avoid a hazard.
-
Page 26: Specifications
speCifiCations dimensions height: 715 mm (28.2 inches) Width: 330 mm (13 inches) depth: 330 mm (13 inches) Weight: 8.25 kg (18.2 lbs) room size 57m² (620 sq. ft.) Clean air delivery rate (Cadr) smoke: 680 m³/h (400 cfm) dust: 680 m³/h (400 cfm) pollen: 680 m³/h (400 cfm) airflow rate... - Page 27 Index Offices Headquarters Blue® Danderydsgatan 11 SE-11426 Stockholm SWEDEN Sales in the U.S. and Canada Blue® 100 North LaSalle Street, Suite 1900 Chicago, IL 60602 Sales in the Middle East and Europe Blue® Danderydsgatan 11 SE-11426 Stockholm SWEDEN...
- Page 28 Index Blue® is a global brand. Visit the website for more information www.pure.blue...
Need help?
Do you have a question about the PURE 121 and is the answer not in the manual?
Questions and answers
Is there a pre-filter somewhere on the model 121 that also needs to be changed? Or just the main filter?
The Blue Pure 121 model has two washable pre-filters that do not need to be changed but can be cleaned, while the main particle and carbon filter should be replaced every 6 months depending on usage.
This answer is automatically generated
The white speed indicator light is OUT. I tried holding the button and unplugging the unit to no avail. The unit works but no light.
Try the following steps to fix the white speed indicator light on the Blue PURE 121 if it is not working:
1. Ensure the Unit is Plugged In – Make sure the air purifier is properly connected to a working power outlet.
2. Turn the Unit On – Touch the Blue® button once to turn on the purifier and activate the low-speed setting.
3. Check for Filter Issues – If the indicator light is yellow or red, acknowledge the filter replacement message by touching the button for 5 seconds or replace the filter if needed.
4. Try Changing Speeds – Touch the button multiple times to cycle through speed settings and check if the light responds.
5. Inspect for Damage – If the unit has a damaged power cord or plug, do not use it and contact an authorized service center for assistance.
If the issue persists, the unit may need professional servicing.
This answer is automatically generated
My Pure Blue 121 has started a squeaking sound when running. Previously it was a quiet humming sound. Is this normal?
The Blue Pure 121 is designed to be ultra-quiet during operation. If it is making a squeaking sound instead of a quiet humming sound, this may indicate an issue, such as a mechanical problem or improper assembly. Checking for loose parts, ensuring the filter is properly installed, and verifying that the unit is placed on a stable surface may help resolve the noise.
This answer is automatically generated
Why does the yellow light stay on when I change the old filter with a new one?
