Z334 or Z340 Z Master
For all Z334 or Z340 Z Master Mowers

Loose Parts

Use the chart below to verify that all parts have been shipped.
Procedure
1
2
3
4
5
6
7
8
9
10
11
© 2008—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
Description
No parts required
Bolt (3/8 x 1 inch)
Nut (3/8 inch)
Right control lever
Left control lever
Bolt (3/8 x 1 inch) (2 are assembled)
Curved washer (3/8 inch) (2 are
assembled)
No parts required
No parts required
Number 2 general purpose lithium base
or molybdenum base grease. (Purchase
separately.)
No parts required
No parts required
No parts required
No parts required
Operator's Manual
Parts Catalog
Engine Owner's Manual
Registration Card
Safety Video
Key
Register at www.Toro.com.
Mowers
®
Qty.
–
Remove the machine from the crate.
1
Install the seat lanyard.
1
1
1
Install the motion control levers.
4
4
–
Adding fuel to the machine.
–
Charge the battery.
1 tube
Check the machine for grease.
–
Check the engine oil level.
–
Prepare the side discharge chute.
–
Check the hydraulic oil.
Check the machine before delivery to
–
the customer.
1
1
1
Delivering the machine to the customer.
1
1
2
Form No. 3356-151 Rev D
Setup Instructions
Use
Original Instructions (EN)
Printed in the USA.
All Rights Reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Z334 Z Master and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Toro Z334 Z Master

Summary of Contents for Toro Z334 Z Master

  • Page 1: Loose Parts

    Operator’s Manual Parts Catalog Engine Owner’s Manual Delivering the machine to the customer. Registration Card Safety Video Register at www.Toro.com. © 2008—The Toro® Company Original Instructions (EN) 8111 Lyndale Avenue South Printed in the USA. Bloomington, MN 55420 All Rights Reserved...

  • Page 2: Removing The Machine From The Crate

    Removing the Machine from the Crate No Parts Required Procedure 1. Remove the straps holding the machine to the crate. 2. Check the air pressure in the rear tires. Pressure: 13 psi (90 kPa) Note: There is no valve stem located in the front tires, it is a semi-pneumatic tire and does not need to be checked.

  • Page 3: Adding Fuel To The Machine

    3. Raise the levers to the neutral position and align them by sliding them forward or backward and tighten the bolts. 4. If the ends of the levers hit against each when rotated Adding Fuel to the Machine into the drive position, move them to the neutral position and carefully bend them outward.

  • Page 4: Charging The Battery

    Charging the Battery Checking the Machine for Grease No Parts Required Parts needed for this procedure: Procedure Number 2 general purpose lithium base or 1 tube molybdenum base grease. (Purchase separately.) Charging the battery produces gasses that can Procedure explode and cause serious injury. 1.

  • Page 5: Checking The Engine Oil Level

    Checking the Engine Oil Level No Parts Required Procedure Before you start the engine and use the machine, check the oil level in the engine crankcase; refer to Checking Oil Level in Operator’s Manual. Figure 7 1. Cap 3. Cold fluid level-full 2.
  • Page 6 Checking the Machine Before Delivery to the Customer No Parts Required Procedure Before delivering the machine to the customer, ensure that you perform or have performed the procedures listed in the following table and initial each when finished. Refer to the Operator’s Manual for instructions on performing these procedures.
  • Page 7 Delivering the Machine to the Customer Parts needed for this procedure: Operator’s Manual Parts Catalog Engine Owner’s Manual Registration Card Safety Video Procedure At delivery, complete the items listed in the following table and initial each when finished. Model No. Serial No.
  • Page 8 Describe the post sale service procedures for your store. Assist the customer in filling out and mailing the registration card or register online at www.Toro.com Make sure that the customer receives the Operator’s Manual, Parts Catalog, and Engine Owner’s Manual, Set Up Instructions, and safety video.
