lumishore TIX 802 Installation And Operating Manual

EOS Thru-Hull Integrated System
Congratulations! You have purchased a LUMISHORE advanced technology underwater light. Every care has been
taken to ensure your Thru-Hull light arrives in perfect condition, so please enjoy the ultimate experience in
underwater lighting.
LUMISHORE Thru-Hull high intensity lights are designed for those owners who prefer the integrity of a thru-hull
installation in a light that employs the most powerful, e cient and cost e ective underwater LED lighting on
the market today. The LUMISHORE Thru-Hull is suitable for many sizes and types of watercraft, including Sports
Boats, Cruisers, Yachts and Super Yachts. LUMISHORE Thru-Hull LED lights come with a compact electronic driver
module to ensure trouble free operation for years to come.
Please read the following pages before attempting installation to ensure complete understanding of
the LUMISHORE LED lights.
BEFORE YOU START
• High Intensity LED light – Do not stare into the LED module at close proximity.
• Always ensure that the vessel's power source and battery are disconnected or isolated prior to installation
• A quali ed professional should carry out both the electrical and mechanical installation. If in doubt please contact LUMISHORE;
Refer to product support section
• Always use a suitable fuse or circuit breaker to protect the complete system. Each light to be individually fused.
• The Thru-Hull maybe installed into GRP (Glass Reinforced Plastic or Fibreglass) and wooden hulls.
• For metal hull or carbon bre installations an isolation kit will be required.
• The light should be installed 6" - 10" (150-250mm) below the minimum load waterline.
• For best results install the lights between 2.5ft (0.8m) and 6.5ft (2m) apart.
• Never try to install or remove light with the vessel in the water.
• Lights should not be exposed to any temperatures in excess of 150°F (65°C). For example, next to hot engine components or
where exhaust emissions could be expelled onto the light while underwater.
• Do not over tighten the retaining bolts. A force of
• All LUMISHORE products should have a bonding to the DC system via bonding strap for galvanic protection.
• Choose a location - The light must be installed onto a at (not curved) surface. Mount on transom or side hull only.
The following components should be used;
• Fuse (1 per light)
• Waterproof junction box
• Power Relay
• EOS Controller
• Power cable - See cable gauge
guide for more information
• Power Switch
Lumishore UK Unit 3, Technium 1, Kings Road, Swansea, SA1 8PH, UK | +44(0)208 144 1694 | Info@Lumishore.com
Lumishore USA 7137 24TH Court East Sarasota, Florida 34234 | (941) 405-3302 | Sales@LumishoreUSA.com
TIX 802 & TIX 1602 Thru-Hull Light
Lumishore EOS Full Colour Change light
Installation and Operating Guide
3Nm
on each bolt should not be exceeded.
The following tools will be required;
45-0057-REV-3
• Hand Drill
• Screwdriver (Cross head)
• Appropriate Sealant (e.g. 3M 4200)
• Cleaning rags
• Holesaw - Refer to holesaw size on
page 8
www.Lumishore.com
