INTRODUCTION

Welcome to the User Manual for the LaCie d2 Thunderbolt™ 2.
LaCie's Thunderbolt 2 storage enclosures feature transfer rates
with the potential to reach up to 20Gb/s bi-directional. Connect
the LaCie d2 to a computer that supports Thunderbolt 2
technology for the ultimate in performance with 4K video and
graphics. The LaCie d2 is ideal for professional editors,
photographers, and graphic artists that demand extraordinary
performance both in the office and the field.
The LaCie d2 also features a USB 3.0 port. Transfer rates can reach up to 5Gb/s when connected to a computer
with a USB 3.0 port. Since it is backwards compatible, USB 3.0 gives you universal connectivity to any computer
with a USB 2.0 port.
This manual will guide you through the process of connecting your LaCie d2 and explain its features. For
questions on installation or use, consult the

BOX CONTENT

LaCie d2
Thunderbolt cable
USB 3.0 cable (USB 2.0 compatible)
External power supply
Quick Install Guide
Important info: Save your packaging. In the event that the hard drive should need to be repaired or
serviced, it must be returned in its original packaging.
Introduction
Getting Help
page.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the d2 Thunderbolt 2 and is the answer not in the manual?

Questions and answers

Related Manuals for LaCie d2 Thunderbolt 2

Summary of Contents for LaCie d2 Thunderbolt 2

  • Page 1: Box Content

    The LaCie d2 also features a USB 3.0 port. Transfer rates can reach up to 5Gb/s when connected to a computer with a USB 3.0 port. Since it is backwards compatible, USB 3.0 gives you universal connectivity to any computer with a USB 2.0 port.

  • Page 2: Minimum System Requirements

    LaCie Private-Public (protect data with AES 256-bit encryption) MINIMUM SYSTEM REQUIREMENTS Your system must meet certain requirements in order for your LaCie product to function properly. For a list of these requirements, please refer to the product packaging or consult the product support web page at www.lacie.com/support/.

  • Page 3: Front View

    VIEWS OF THE HARD DRIVE ENCLOSURE Front view Hard drive status LED Vibration-dampening rubber feet Introduction...

  • Page 4: Rear View

    Rear view Kensington® lock slot USB 3.0 port Thunderbolt 2 ports (x2) Power supply connection Integrated cable lock Introduction...

  • Page 5: Technical Specifications

    TECHNICAL SPECIFICATIONS Power supply 100-240V; 50/60Hz; 18W Dimensions Width Depth Height 60 mm / 2.4 in 217 mm / 8.5 in 130 mm / 5.1 in Weight Capacity Weight 1.3 Kg / 2.9 lbs 1.4 Kg / 3.1 lbs 1.5 Kg / 3.2 lbs Introduction...
  • Page 6 DO NOT place the enclosure on its side when it is powered on. The LaCie d2 does not support stacking. Doing so poses a severe risk that it will fall. DO NOT stack other drives, enclosures, or equipment on top of the LaCie d2.
