a. Connect
b. Change inspection
c. Get date and time
d. Get program number
All messages have the same structure:
Lenght in bytes
4
4
4
4
Messages are ignored by the camera which do not comply with the given format (wrong "magic
number", wrong length, unknown message ID). The "magic number" is used to avoid accidential
transmissions. It is recommended to check the "magic number" in the control software.
Every message has a unique ID:
ID Message
01 Connect
hex
02 Disconnect
hex
20 Result container
hex
30 Get program number
hex
31 Change inspection program
hex
32 Get date and time
hex
33 Set date and time
hex
34 Set input data
hex
35 Set inspection number
hex
40 Trigger inspection
hex
41 Start inspection
hex
42 Stop inspection
hex
mvBlueGEMINI Technical Manual (EN)
Structure Description
uint32 Magic number: 42565350
uint32 User data length in bytes
uint32 Message ID
uint8[] User data
APPENDIX - CONTROL COMMANDS
v1.2.2
hex
