- Page 1 Multimedia Projector UST-P1 MODEL UST-P1C, UST-P1V1, UST-P1CV1, UST-P1G PROJECTOR PROMETHEAN LTD PROMETHEAN HOUSE Owner’s Manual LOWER PHILIPS ROAD BLACKBURN BB1 5TH UNITED KINGDOM (44) 1254 298 598...
-
Page 2: Important Safety Information
Alerts you to situations that may damage the unit, create a hazardous environment, or cause personal injury. Throughout this manual, component parts and items in the OSD menus are denoted in bold font as in this example: “Push the Menu button on the remote control to open the Main menu.” Promethean, Company Confidential... -
Page 3: Projector Installation Notice
Do not place anything on the power cord. Place the power cord where it will not be in the way of foot traffic. Remove the batteries from the remote control when storing or not in use for a prolonged period. Promethean, Company Confidential... -
Page 4: About This Manual
Wherever possible, relevant information—such as an illustration and its description—has been kept on one page. This printer-friendly format is both for your convenience and to help save paper, thereby protecting the environment. It is suggested that you only print sections that are relevant to your needs. Promethean, Company Confidential... -
Page 5: Table Of Contents
..........................46 OMMON PROBLEMS AND SOLUTIONS ............................46 IPS FOR ROUBLESHOOTING LED E ..............................47 RROR ESSAGES ................................47 MAGE ROBLEMS ................................48 ROBLEMS ............................48 EMOTE ONTROL ROBLEMS ..........................48 AVING THE ROJECTOR ERVICED ................................. 49 PECIFICATIONS Promethean, Company Confidential... - Page 6 ........................50 ROJECTION ISTANCE VS ROJECTION Projection Distance and Size Table......................... 50 ................................ 51 IMING ABLE ..............................54 ROJECTOR IMENSIONS REGULATORY COMPLIANCE............................55 FCC W .................................. 55 ARNING .................................... 55 ANADA ..............................55 AFETY ERTIFICATIONS Promethean, Company Confidential...
-
Page 7: Getting Started
Contact your dealer immediately if any items are missing, appear damaged, or if the unit does not work. It is recommend that you keep the original packing material should you ever need to return the equipment for warranty service. Caution: Avoid using the projector in dusty environments. Promethean, Company Confidential... -
Page 8: Views Of Projector Parts
Flashing Cooling POWER LED Power On, Ready to power on Green (Standby) Important: Ventilation openings on the projector allow for good air circulation, which keeps the projector lamp cool. Do not obstruct any of the ventilation openings. Promethean, Company Confidential... -
Page 9: Rear View
If your video equipment has various input sources, it is recommended to connect in priority of HDMI/DVI, component (thru VGA), Composite for better picture quality. Warning: As a safety precaution, disconnect all power to the projector and connecting devices before making connections. Promethean, Company Confidential... -
Page 10: Bottom View
(not less than 5.15 kg) over a period of 60 seconds. Promethean, Company Confidential... -
Page 11: Remote Control Parts
3. The buttons and keys on the projector have the same functions as the corresponding buttons on the remote control. This user’s manual describes the functions based on the remote control. Promethean, Company Confidential... - Page 12 Page Up Page up when connected through USB to a PC Left Left arrow when connected through USB to a PC Enter Enter key when connected through USB to a PC Power Turns the projector on or off Promethean, Company Confidential...
-
Page 13: Remote Control Operating Range
15 degrees above or below the projector level. If the projector does not respond to the remote control, move a little closer. Projector and Remote Control Buttons The projector can only be operated using the remote control. All operations can be carried out with the remote control. Promethean, Company Confidential... -
Page 14: Setup And Operation
Replace the cover. Caution: 1. Only use AAA batteries (Alkaline batteries are recommended). 2. Dispose of used batteries according to local ordinance regulations. 3. Remove the batteries when not using the projector for prolonged periods. Promethean, Company Confidential... -
Page 15: Starting And Shutting Down The Projector
HDMI: HDMI, DVI When the “Power Off? /Press Power again” message appears, press the POWER button. The projector turns off. Caution: Do not unplug the power cord until the POWER LED change to green–indicating the projector has cooled down. Promethean, Company Confidential... -
Page 16: Setting An Access Password (Security Lock)
If you lose the password, contact your reseller for information on clearing the password. Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Installation I menu. Press the cursor ▲▼ button to select Advanced. Promethean, Company Confidential... - Page 17 Security Lock is enabled. Enter the password in the order you set it at step 5. In case you forget the password, please contact the service center. Service center will validate the owner and help reset the password. Promethean, Company Confidential...
-
Page 18: Adjusting The Projector Level
Position the projector so that it is perpendicular to the screen. • Ensure the cables are in a safe location. You could trip over them. To adjust the angle of the picture, turn the tilt-adjuster right or left until the desired angle has been achieved. Promethean, Company Confidential... -
Page 19: Adjusting The Focus And Keystone
Adjusting the Focus and Keystone Use the Image-focus control (on the projector only) to sharpen the projected image Use the KEYSTONE buttons the remote control to correct image-trapezoid (wider top or bottom) effect. The keystone control appears on the display. Promethean, Company Confidential... -
Page 20: On-Screen Display (Osd) Menu Settings
Depending on the video source, not all items in the OSD are available. For example, the Horizontal/Vertical Position items in the Computer menu can only be modified when connected to a PC. Items that are not available cannot be accessed and are grayed out. Promethean, Company Confidential... -
Page 21: Setting The Osd Language
1. Press the MENU button. Press the cursor ◄► button to navigate to Installation I. 2. Press the cursor ▲▼ button until Language is highlighted. 3. Press the cursor ◄► button until the language you want is highlighted. 4. Press the MENU button twice to close the OSD. Promethean, Company Confidential... -
Page 22: Osd Menu Overview
Front, Rear, Ceiling, Rear + Ceiling Auto Power On On, Off Aspect Ratio Fill, 4:3, 16:9, LetterBox, Native Fan Speed Normal, High ActivBoard Lamp Mode Normal, Bright Installation Keystone -40 ~ 40 Advanced Advanced Factory Reset Reset Status Promethean, Company Confidential... -
Page 23: Osd Sub-Menu Overview
OSD Sub-Menu Overview Promethean, Company Confidential... -
Page 24: Image Menu
Press the cursor ◄► button to adjust the gamma correction of the display. Press (Enter) / ► to enter the Advanced menu. See Advanced Feature on page Advanced Reset Press (Enter) / ► to reset all settings to default values. Promethean, Company Confidential... -
Page 25: Advanced Feature
(Range: Native – Warm – Normal – Cold ) Press (Enter) / ► to enter the color manager menu. Color Manager (Range: Red – Green – Blue – Cyan-Magenta – Yellow – White). See page 20 for more information on Color Manager. Promethean, Company Confidential... -
Page 26: Color Manager
Select to enter the Yellow Color Manager. Yellow Press the◄► buttons to adjust the Hue, Saturation, and Gain. Select to enter the White Color Manager. White Press the ◄► buttons to adjust the Red, Green, and Blue. Promethean, Company Confidential... -
Page 27: Computer Menu
Press the cursor ◄► button to adjust the A/D sampling clock. Tracking Press the cursor ◄► button to adjust the A/D sampling dot. Press (Enter) / ► to automatically adjustment for phase, tracking, size and Auto Image position. Promethean, Company Confidential... -
Page 28: Video Menu
Press the ◄► buttons to enable or disable closed captioning. Reset Press (Enter) / ► to reset all settings to default values. Note: Video jagging may occur when playing interlace video. To overcome this issue, open the Video menu and adjust the Film Mode feature. Promethean, Company Confidential... -
Page 29: Installationi Menu
Press the cursor ◄► button to adjust the display keystone. Advanced Press (Enter) / ► to the Advanced menu. See Advanced Feature on page 25. Reset Press (Enter) / ► to reset all settings to default values (except Language). Promethean, Company Confidential... -
Page 30: Activboard Installation
Press ◄► button to adjust vertical image position. Adjustment Note: Only available when White Board 4:3/16:9 is selected Horizontal Image Press ◄► button to adjust horizontal image position. Adjustment Note : Only available when White Board 4:3 is selected Promethean, Company Confidential... -
Page 31: Advanced Feature
Press the cursor ◄► button to enable or disable presentation timer. Timer Period Press the cursor ◄► button to select timer period (1 ~ 60 minutes) Timer Reset Press (Enter) / ► to reset the timer settings. Promethean, Company Confidential... -
Page 32: Installation Ii Menu
(Enter) / ► to enter the Advanced menu. See Advanced Feature on page Advanced Factory Reset Press (Enter) / ► to reset all items to factory preset values. Press (Enter) / ► to enter the Status menu. See page 39 for more information on Status Status. Promethean, Company Confidential... -
Page 33: Advanced Feature
(Enter) / ► to enter the Network menu. See page 30 for more information on Network Network settings. Note: To enjoy the 3D function, first enable the Play Movie in 3D setting found in your DVD device under the 3D Disc Menu. Promethean, Company Confidential... -
Page 34: Osd Menu Setting
(Enter) / ► to test the IR remote controller for diagnostic. Test Color Test Press (Enter) / ► to select different colors on screen. USB Test Press (Enter) / ► to test the USB connection with connected PC. Promethean, Company Confidential... -
Page 35: Lamp Hour Reset
Press ◄► to select Off, DLP-Link or IR. 3D Sync Invert Press ◄► to turn 3D Sync Invert On or Off. 3D Format Press ◄► to enable or disable 3D Format. Note: The model is 3D ready, please contact Promethean for more details. Promethean, Company Confidential... -
Page 36: Network
Enter a valid Subnet Mask if DHCP is turned off. Gateway Enter a valid Gateway address if DHCP is turned off. Enter a valid DNS name if DHCP is turned off. Apply Press (Enter) / ► to confirm settings. Promethean, Company Confidential... - Page 37 This projector is compliant to support Extron device(s) for reference. http://www.extron.com/ For more information about the range of external devices which can be connected to the LAN/RJ45 port, as well as the related control commands for each external device, please contact the Service team directly. Promethean, Company Confidential...
- Page 38 LAN RJ45 1. Connect an RJ45 cable to RJ45 ports on the projector and the PC (Laptop). 2. On the PC (Laptop), select Start → Control Panel → Network Connections. Promethean, Company Confidential...
- Page 39 3. Right-click on Local Area Connection, and select Properties. 4. In the Properties window, select the General tab, and select Internet Protocol (TCP/IP). 5. Click Properties. Promethean, Company Confidential...
- Page 40 The projector is setup for remote management. The LAN/RJ45 function displays as follows. Based on network web-page for the input-string in tools tab, the limitation for Input-Length is in the below list (“space” and the other punctuation key included): Promethean, Company Confidential...
- Page 41 Projector Location Assigned To DHCP (Enabled) (N/A) IP Address Network Configuration Subnet Mask Default Gateway DNS Server Enabled (N/A) User Password New Password Confirm Enabled (N/A) Admin Password New Password Confirm For more information, please visit http://www.crestron.com/. Promethean, Company Confidential...
- Page 42 Make sure that laptop/PC can access the web-page of the projector. Make sure that “Windows Firewall” setting to be disabled in case of “TELNET” function filtering out by laptop/PC. Start => All Programs => Accessories => Command Prompt Promethean, Company Confidential...
- Page 43 How to have TELNET enabled in Windows VISTA / 7 By default installation for Windows VISTA, “TELNET” function is not included. But end-user can have it by way of “Turn Windows features On or Off” to be enabled. Open “Control Panel” in Windows VISTA Open “Programs” Promethean, Company Confidential...
- Page 44 Limitation 3 for Telnet-Control: there is less than 26 bytes for one complete RS232 command for Telnet-Control. Limitation 4 for Telnet-Control: Minimum delay for next RS232 command must be more than 200 (ms). (*, In Windows XP built-in “TELNET.exe” utility, “Enter” key pressed will have “Carriage-Return” and “New-Line” code.) Promethean, Company Confidential...
-
Page 45: Factory Reset
ESCRIPTION Active Source Display the activated source. Displays resolution/video information for RGB source and color standard for Video Video Information source. Lamp Hours Lamp hour used information is displayed. Normal and Bright counters are separated. (Normal, Bright) Promethean, Company Confidential... -
Page 46: Maintenance And Security
Be sure to turn off and unplug the projector at least 30 minutes before replacing the lamp. Failure to do so could result in a severe burn. Remove the single screw on the lamp compartment cover. Remove the lamp compartment cover. Promethean, Company Confidential... - Page 47 While installing, align the lamp module with the connector and ensure it is level to avoid damage. Note: The lamp module must sit securely in place and the lamp connector must be connected properly before tightening the screws. Promethean, Company Confidential...
-
Page 48: Resetting The Lamp
Press the cursor ▼▲ button to move down to Lamp Hour Reset. Press the cursor ► or Enter button. A message screen appears. Press ▼▲◄► buttons to reset the lamp hour. Press the MENU button to get back to Installation II. Promethean, Company Confidential... -
Page 49: Cleaning The Projector
1. Always turn the projector off and allow to cool for at least 30 minutes prior to cleaning. 2. Never touch the projector mirror or Lens directly by hand. 3. Do not use hard fibre cloths. 4. Do not use abrasive cleaners, solvents or other harsh chemical cleaners. Promethean, Company Confidential... -
Page 50: Cleaning The Case
3. If a little water gets into the projector interior while cleaning, leave unplugged in a well-ventilated room for several hours before using. 4. If a lot of water gets into the projector interior when cleaning, have the projector serviced. Promethean, Company Confidential... -
Page 51: Using The Physical Lock
Kensington, 2853 Campus Drive, San Mateo, CA 94403, U.S.A. Tel: 800-535- 4242, http://www.Kensington.com. Using the Security Bar In addition to the password protection function and the Kensington lock, the Security Bar helps protect the projector from unauthorized removal. See the following picture. Promethean, Company Confidential... -
Page 52: Troubleshooting
For example, if you replace batteries and the problem remains, put the original batteries back and go to the next step. Keep a record of the steps you take when troubleshooting: The information may be useful when calling for technical support or for passing on to service personnel. Promethean, Company Confidential... -
Page 53: Led Error Messages
Adjust the Contrast setting on the Image menu of the OSD. Problem: The color of the projected image does not match the source image. Adjust the Color Temperature and Gamma settings on the Image menu of the OSD. Promethean, Company Confidential... -
Page 54: Lamp Problems
Include a description of the problem and a checklist of the steps you took when trying to fix the problem: The information may be useful to service personnel. For servicing, return the projector to the place you purchased it. Promethean, Company Confidential... -
Page 55: Specifications
Mini jack x 1 (Audio In) Input Terminals Composite Video x 1 HDMI x 1 VGA x 1 (Loop Thru only for VGA IN-1) Output Terminals Mini jack x 1 (Audio out) RS-232C Control Terminals RJ45 USB (type B) Security Kensington lock Promethean, Company Confidential... -
Page 56: P Rojection D Istance Vs . P Rojection S Ize
Projection Distance vs. Projection Size Projection Distance and Size Table WXGA 16:9 16:10 421.9+/-20mm 340.3+/-20mm 372.1+/-20mm Distance 95" 87" 78" Diagonal Image Width 2089mm 1880mm 1566mm Image height 1175mm 1175mm 1175mm 327.6+/-50mm 300.2+/-50mm 310.7+/-50mm Promethean, Company Confidential... -
Page 57: Timing Mode Table
1024 x 768 68.7 85.0 ○ ○ － － ** 1024 x 768 97.6 120.0 ○ ○ － － 1024 x 768 99.0 120.0 ○ ○ － － 1152 x 864 67.5 75.0 ○ ○ － － Promethean, Company Confidential... - Page 58 60.0 ○ ○ － － 1920 x 1080 67.5 60.0 ○ ○ － － Apple — — 640 x 480 35.0 66.7 Macintosh — — 832 x 624 49.7 74.5 — — 1024 x 768 60.2 74.9 Promethean, Company Confidential...
- Page 59 There 3D timing showing depend the EDID file and display card. It is possible that user cannot choose the above 3D timings on display card. The resolution of the panel is 1280 x 800. Resolution other than native resolution may display with uneven size of text or lines. Promethean, Company Confidential...
-
Page 60: P Rojector D Imensions
Projector Dimensions Promethean, Company Confidential... -
Page 61: Regulatory Compliance
Changes or modifications not expressly approved by the parties responsible for compliance could void the user’s authority to operate the equipment. Canada This class B digital apparatus complies with Canadian ICES-003. Safety Certifications FCC-B, UL, CB, CE, CCC, KC, GOST, SASO, KUCAS, NOM, PSB and TUV-GS Promethean, Company Confidential...
