Installing your Bathroom Fan Heater

Always choose a safe location for the heater, keeping in mind the safety
precautions outlined. Ensure all packaging has been removed from the
unit before use. This appliance requires no installation, it should be used
solely as a portable appliance.
GENERAL INSTRUCTIONS
It is illegal for persons other than those
authorised by legislation to work on the fixed
wiring of any electrical installation.
All installations must be in accordance with the
local Electrical Wiring Regulations and Wiring
Rules.
Means for disconnection must be incorporated in
the fixed wiring in accordance with the wiring
rules.
This heater must not be mounted immediately
below a socket outlet.
The heater must be installed in a position where
the outlet grill is a minimum of 1.85 metres from
the floor, a minimum of 300mm from the nearest
side to an adjacent wall and a minimum of
210mm from the ceiling to the top face of the
heater.
The appliance is to be installed so that switches
and other controls cannot be touched by a
person in the bath or shower.
The appliance must be mounted in such a
position that doors or other moving objects will
not obstruct the airflow.
WIRING AND FIXING TO WALL
Select a location for mounting the heater in
accordance with the General Care and Safety
Guide.
The heater must be connected by permanent
wiring within the wall cavity from an isolating
switch.
The wall mounting base should be positioned as
shown in Figure 1 (on next page).
If this heater is mounted above a shelf or other
wall mounted object then there must be aminimum
of 700mm clearance between the shelf and the
outlet grille.
The wiring within the wall cavity can be terminated
into the respective terminals marked L and N on
the wall mounting base. (See Figure 3a on next
page).
The Wall Mounting Base must be secured with
all four screw fixing points.
Securely fix the wall mounting base to the wall
surface with the screws and wall plugs supplied.
(See Figure3b on next page). The wall mounting
base can be used with or without a flush box in the
wall cavity. When using a flush box the wall
mounting base can utilise either the left or right
pair of mounting holes.
Fit the heater to the wall mounting base by
ensuring the 4 hooks on the wall mounting base
have engaged with the mounting apertures of the
heater. Slide the heater down to lock it into place.
The electrical connection is automatically made
during this step.
The heater must be locked in place on the wall
mounting base for safe operation.
To check the heater is fully locked to the mounting
base, attempt to gently slide the heater
upwards. It should be securely held in position.
To remove the heater from the wall mounting base
insert a blade screwdriver into the hole located
below the middle of the outlet grille. Rotate the
screwdriver until the clip releases. Then while
holding the heater, gently push up with the
screwdriver sliding the heater off the wall mounting
base. (See Figure 2 on next page)
.
