Summary of Contents for Goldair Platinum GBH500
- Page 1 Operating Instructions Ceramic Bathroom Heater with WiFi For Model: GBH500...
- Page 2 WARNING: To reduce the risk of fire, keep textiles, curtains, or any flammable material a minimum distance of 1 metre from the air outlet. • Your Goldair Bathroom Fan Heater Wall Mount must be installed with: • At least 1.85m clearance from the floor.
- Page 3 General Care and Safety Guide (continued) • Never cover this heater or restrict its airflow with a towel or any other item. Covering or restricting the airflow of the heater will cause activation of the thermal safety device. Do not use appliance to dry clothes. •...
- Page 4 Components Main Unit x 1 – GBH500 Wall Mounting Plate x 1 Remote x 1 Screw Pack: Screw x 4, Wall Plug x 4...
- Page 5 CAUTION: The appliance is to be installed so that switches and other controls cannot be touched by a person in the bath or shower. NOTE: Your Goldair Bathroom Fan Heater Wall Mount must be installed with: • At least 1.85m clearance from the floor.
-
Page 6: Installing Your Appliance
The measurements are taken from the fixed plumbing connection (water source) and each zone has specific requirements regarding the electrical equipment that can be used within it. Goldair Bathroom heaters are rated IPX0 so must be installed in Zone 3. -
Page 7: Operating Your Heater
Do not use this heater with a programmer, separate timer, remote-control system or any other device that switches the heater on automatically – this does not include remote supplied with this item or the Goldair app - as a fire risk exists if the heater is covered or positioned incorrectly. -
Page 8: Control Panel And Remote Control
Control Panel and Remote Control CONTROL PANEL REMOTE CONTROL A. Stand-by indicator Stand-by B. Clock indicator Clock setting C. Heating indicator (50%) Heating setting D. Heating indicator (100%) Timer off/on E. Hour, timer, power display Increase F. Minute, timer, display Decrease G. -
Page 9: Specification
Operating Instructions Specification Voltage AC230-240V Frequency 50Hz Power 1900-2000W Battery Model 2 x AAA Battery (Remote) How to use The heater will start with a beep sound when power has been supplied. The indicator light is on, and the heater is in stand-by mode. Press on remote control to turn on the heater. - Page 10 Operating Instructions (continued) Timer off/on function To access this function, press the timer button , use to set the timer from 15 mins, 30 mins, 45 mins, 1 hour……3 hours. The timer will show Press timer button again to confirm the timer. When the heater is in standby mode, operate as above to use the timer on function.
- Page 11 WiFi – Downloading and setting up APP This APP is supported only on 2.4GHz Wi-Fi channels. The Goldair app and device pairing process require your 2.4ghz connection to be separated from your 5ghz connection. For instructions on how to do this please contact your internet provider.
- Page 12 Pairing APP to Device Connect with 2.4ghz Wifi Network On the Home screen, Using the categories on tap ‘Add Device’ or the the left, navigate to your ‘+’ icon. device and tap on the image. Confirm you are connected to a 2.4ghz network.
- Page 13 Pairing APP to Device (continued) Connect with 2.4ghz Wifi Network: EZ Mode See instructions below to finalise your device pairing via EZ mode. The app will default to EZ Mode in the top right hand corner. Ensure your device’s Wifi LED is flashing rapidly.
- Page 14 Hotspot by selecting the Ensure your device’s WiFi LED is If not, navigate back to the Goldair network highlighted on the flashing slowly. app. screen in your app, e.g.
-
Page 15: Connect With Bluetooth
Pairing APP to Device (continued) Connect with Bluetooth As an alternative way of connecting your device, you can pair via Bluetooth. Please ensure you have Bluetooth switched on on your mobile phone. On the Home screen, tap ‘Add On the top right, click ‘Auto Scan’ Choose your 2.4ghz Wifi Device’... -
Page 16: Device Settings
Operating your Device from the APP Device settings: Change the name, location & image of your device View your device information View your tap-to- run and smart scene automations View compatible Voice Control devices & instructions on setting up. Turn on notifications for when device goes Offline. - Page 17 How to connect to your Alexa Devices Follow the below instructions to connect your device to Amazon Alexa. • Download the Goldair App and pair your device. Note: change the name of the device to an easily identifiable name such as ‘Bedroom Fan’ or ‘Living Room Heater’...
- Page 18 How to connect to your Alexa Devices (continued) • Type ‘Goldair’ in the search bar and click to proceed. • Click ‘Enable to use’ and type your phone number/ email address and password and click ‘Link Now’ • Click ‘Authorise’ and go back to the Home screen. Your devices will now appear, and you can operate using voice control.
- Page 19 How to connect to your Alexa Devices (continued) SUGGESTED VOICE COMMANDS Note: Amazon and Google are in control of voice control functionality and terminology. Not all functions available via the controller or APP can be controlled via voice command. Voice control on your device will allow you to turn ON and OFF and adjust the settings. Suggested voice commands to work with your Alexa device are: Turning ON/OFF Alexa, turn ON <Device Name>...
- Page 20 How to connect to your Google Home devices Follow the below instructions to connect your device to Google Home. • Download the Goldair App and pair your device. Note: change the name of the device to an easily identifiable name such as ‘Bedroom Fan’ or ‘Living Room Heater’...
- Page 21 How to connect to your Google Home devices (continued) • Click ‘Works with Google’ • Type ‘Goldair’ in the search bar and click to proceed. • Type your phone number/ email address and password and click ‘Link Now’...
- Page 22 How to connect to your Google Home devices (continued) • Click Authorise and all devices from your Goldair App will appear on screen. • You have the option to add these to a particular room in your home • When you go back to the Home screen, your devices will now appear, and you can operate using voice control.
-
Page 23: Pairing Mode
Pairing APP to Device Details for pairing this heater to the Goldair App can be found at the below website link. Either scan the QR code below or enter the website into your browser. New Zealand Products https://www.goldair.co.nz/goldair-app Pairing Mode To connect to the Goldair app you must ensure that your device is in pairing mode which is where the WiFi Icon is flashing. -
Page 24: Cleaning Your Heater
Do not attempt to repair or adjust any electrical or mechanical functions on this unit. Doing so will void the warranty. Contact a qualified electrical person to service the heater. SUPPORT AND TECHNICAL ADVICE Goldair – New Zealand Monday – Friday 8am-5pm Phone +64 (0)9 917 4000 Phone 0800 232 633... -
Page 25: Two Year Warranty
Goldair undertake to repair or replace this product at no charge if found to be defective due to a manufacturing fault during the warranty period. Your Goldair product has been inspected and tested and is guaranteed subject to the following for a period to one year from the date of purchase against defects in workmanship and materials. - Page 26 New Zealand PO Box 100707, North Shore Mail Centre, Auckland, 0745 www.goldair.co.nz Australia PO Box 574, South Morang, Victoria, 3752 www.goldair.com.au...
