Introduction; Unpacking The Unit; Items Included In The Box - Lectrosonics DMPA12 Installation Manual

Introduction

The purpose of this guide is to assist in the correct
installation and initial setup of a DMPA12 digital power
amplifier in a sound system utilizing other DM Series
components. This guide assumes familiarity with the
DMPA12 amplifier and other components and software
used in the system. To get the most out of this power
amplifier, it is suggested that you review the information
presented in the Reference Manual, available on the
supplied CD or downloaded from the web site at:
http://www.lectrosonics.com/LecNet2/
A detailed online Help is also available to assist in the
setup and operation of this power amplifier using the
USB interface and a computer system running Win-
dows XP, Vista and 7 operating systems. In addition to
assistance setting up and operating this amplifier, the
Help includes a complete listing of Commands. These
commands can be used to setup and operate the ampli-
fier via external devices using either the USB or RS232
serial port.

Unpacking the Unit

Compare the packing list enclosed with the unit with
the original order. Inspect all items for damage. Im-
mediately call 1-800-821-1121 to report any items that
are missing or damaged. The sooner we get notified,
the sooner we can get any needed replacement items
shipped to your location.
Rio Rancho, NM

Items Included in the box:

Description
Installation Guide
Warranty Card
Power cable
5-pin Phoenix connector
25-pin connector
LecNet serial cable, black
DB-9 to 3.5mm stereo
plug
LecNet serial cable, red
DB-9 to 3.5mm stereo
plug
for AMX, Crestron
USB interface cable
CAT-5 interconnect cable
Small screwdriver
Rack Mount Support Kit:
Siderail
Screws
Washers
If there are any problems or items missing,
immediately call 1-800-821-1121 and ask for
anyone in sales or service.
DMPA12 Installation Guide
Quan. Part Number
1 M-DMPA12-I
1
1 21499
6 21580
1 21558
1 21529-1
1 21710-1
1 21713
2 21716
1 35679
2 26693
6 28505
6 28402
5
