Table Of Contents; Introduction - Lectrosonics DA4 Operating Instructions Manual

The DA4 is a 2 width module that provides the means to control and distribute an input signal to four balanced,
high-current output drivers. Each output has a separate level control. The DA4 can supply up to 20dB of gain, so
small signals can be boosted to avoid noise contamination on long cable runs.
