Programmable Inputs and Outputs Wiring

Remote control with external pots and switches is pro-
vided with Programmable Inputs on a standard DB-25
connector on the rear panel. Programmable Outputs
are used to provide external LED indicators and to trig-
ger other events.
Examples of the wiring are shown below.
PROGRAMMABLE INPUTS/OUTPUTS
6 - IN 9
1 - GND
7 - IN 11
2 - IN 1
8 - GND
3 - IN 3
9 - OUT 1
4 - IN 5
10 - OUT 3
5 - IN 7
1
IN 1
Potentiometer
IN 2
Potentiometer
IN 3
Common Connections can be used for
Switch
Vista and XP or are trademarks of
* Windows
Microsoft Corporation.
Rio Rancho, NM
11- OUT 5
16 - IN 4
21 - OUT 2
12 - OUT 7
17 - IN 6
22 - OUT 4
13 - GND
18 - IN 8
23 - OUT 6
14 - +5V
19 - IN 10
24 - OUT 8
15 - IN 2
20 - +5V
25 +5V
13
LED
500 Ohms
LED
500 Ohms
LED
500 Ohms
Three Programmable Inputs:
2 - 10 K linear potentiometers
for volume control
1 - Tobble switch for muting
3 Programmable Outputs:
LEDS for function indicators
(380 to 500 Ohm resistors in-line
to avoid burning out LEDS)
NOTE
all voltage and ground connections
among all devices.

Control System Interconnections

In addition to a Windows
the DM84 can be controlled by external serial control
system using the RS-232 interface, such as those from
Crestron
RS-232 Port
OUT 3
Two RS-232 serial cables are provided.
The cable with the BLACK TRS connector is an RS-
OUT 4
232 cable wired for use with a laptop computer system.
OUT 1
The cable with the
to be used with a control system such as those from
Crestron
NOTE: Crestron
Electronics, Inc. AMX
of AMX Corp.
DMPA12 Installation Guide
based computer system,
®
and AMX .
® ®
1: GND 6: IN 9
1 13
7: IN 11
2: IN 1
14 25
3: IN 3 8: GND
LecNet 2 4: IN 5 9: OUT 1
5: IN 7 10: OUT 3
RS-232 USB
USB Port
Black cable for
computer connection
RED TRS connector is designed
or AMX .
® ®
Red cable for AMX and
Crestron control systems
® is a trademark of Crestron
is a registered trademark
®
11: OUT 5 16: IN 4 21: OUT 2
22: OUT 4
12: OUT 7 17: IN 6
13: GND 18: IN 8 23: OUT 6
14: +5V 19: IN 10 24: OUT 8
15: IN 2 20: +5V 25: +5V
PROGRAMMABLE
INPUTS / OUTPUTS
