- Page 1 MOUSE MAXI MOUSE PORTABLE AMPLIFIERS OPERATING INSTRUCTIONS and trouble-shooting guide LECTROSONICS, INC. Rio Rancho, NM...
-
Page 2: Table Of Contents
TROUBLESHOOTING GUIDE ....... . . MOUSE SPECIFICATIONS ........ -
Page 3: General Description
By moving the equalization switch to the appropriate position, it is possible to run any type of audio source into the Maxi, from microphones to tape decks. This is why Maxi Mouse is also used as a general utility amplifier, to amplify everything from a VCR to a "walkman" type portable stereo, in locations ranging from a hotel ballroom to the beach. -
Page 4: Mouse Portable Speaker/Amp
To use the MOUSE as a preamp for a larger amplifier, simply move the switch to the -10db position and connect the output of the MOUSE to the input of the other amplifier with a shielded cord. - Page 5 CONTROLS AND FUNCTIONS - MOUSE PORTABLE SPEAKER/AMP...
-
Page 6: Controls And Functions
CH40 INPUT JACK To charge the Maxi Mouse, insert the charger plug fully into the CH-40 INPUT jack on the control panel, and plug the CH-40 charger into a 110 Volt wall outlet. The green LED above the CH-40 INPUT jack will light up when the unit is taking a charge. - Page 7 CONTROLS AND FUNCTIONS MAXI MOUSE PORTABLE SPEAKER/AMP...
-
Page 8: Troubleshooting Guide
TROUBLESHOOTING GUIDE BEFORE GOING THROUGH THE FOLLOWING CHART, BE SURE THE BATTERY PACK IS FULLY CHARGED. The POWER LAMP should light up when the unit comes on. The POWER LAMP will grow dim as the batteries discharge. Keep the batteries fully charged when not in use to insure long battery life. - Page 9 TROUBLESHOOTING GUIDE (cont.) SYMPTOM POSSIBLE CAUSE DISTORTED SOUND FROM SPEAKER 1) Volume set too high. Reduce volume control. 2) Excessive wind noise or breath "pops". 3) Batteries very low. Recharge batteries. As the batteries discharge you have to turn up the volume.
-
Page 10: Mouse Specifications
Rechargeable 12 Volt, lead-acid gel cell, 4 Amp-hour self-contained battery pack. CH-40 charger included. SIZE AND WEIGHT 9 1/2" High x 12" wide x 10" deep - 13 pounds MAXI MOUSE SPECIFICATIONS AMPLIFIER All silicon transistor, 9 Watts, RMS, into 2 Ohms Distortion: Less than 1%... -
Page 11: Service And Repair
There are no adjustments inside that will make a malfunctioning unit start working. LECTROSONICS service department is equipped and staffed to quickly repair your equipment. In-warranty repairs are made at no charge in accordance with the terms of the warranty. Out of warranty repairs are charged at a modest flat rate plus parts and shipping. -
Page 12: Warranty
This warranty gives you specific legal rights. You may have additional legal rights which vary from state to state. LECTROSONICS, INC. 581 LASER ROAD RIO RANCHO, NM 87124 USA September 6, 1994...
