UVI Group GPS-VT103 User Manual

Gsm/gprs/gps vehicle tracker
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Thank you for purchasing the tracker. This manual shows how to operate the device smoothly and correctly.
Make sure to read this manual carefully before using this product. Please note that specification and
information are subject to changes without prior notice in this manual.
Any change will be integrated in the latest release. The manufacturer assumes no responsibility for any errors
or omissions in this document.
VT -103 GPS Vehicle Tracker
UVI Group Corporation Limited
11C, HaiYue Building, HuiJing Garden,
Nanshan Technology Park, Shenzhen, China
Tel: +86-755-83315079 Mobile: +86-1860-7550 6905
E-mail:
kc@uvigroup.com.cn
GSM/GPRS/GPS Vehicle Tracker
GPS-VT103 User Manual
Website:
www.uvi-group.com
Preface
1 / 13
Solution B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GPS-VT103 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for UVI Group GPS-VT103

Summary of Contents for UVI Group GPS-VT103

  • Page 1 VT -103 GPS Vehicle Tracker UVI Group Corporation Limited 11C, HaiYue Building, HuiJing Garden, Solution B Nanshan Technology Park, Shenzhen, China Tel: +86-755-83315079 Mobile: +86-1860-7550 6905 E-mail: kc@uvigroup.com.cn Website: www.uvi-group.com GSM/GPRS/GPS Vehicle Tracker GPS-VT103 User Manual Preface Thank you for purchasing the tracker. This manual shows how to operate the device smoothly and correctly.
  • Page 2 GPS-VT 103 GPS Vehicle Tracker 1. Function Introduction  This tracker is a new product based on the GSM / GPRS network and GPS satellite positioning system, which set multiple functions of security, positioning, monitoring surveillance, emergency alarms and tracking in its entirety. It can track and monitor remote target by SMS or internet. ...
  • Page 3 GPS-VT 103 GPS Vehicle Tracker NAME PHOTOES NOTE GPS Antenna 3 meters GSM Antenna 3 meters Microphone 1.5 meters Harness 10PIN 12V/40A to 24V/40A Relay according to vehicle model Shake sensor Option Siren Optional Remote control Optional NOTE: No.6, 7 and 8 are optional. They need extra cost. 5．Specifications Content Specifications...
  • Page 4 GPS-VT 103 GPS Vehicle Tracker Cold status 45s Warm status 35s GPS Start time Hot status 1s 12 V -24V Voltage of car power system Backup battery Chargeable changeable 3.7V 800mAh Li-ion battery Storage Temp. -40° C to +85° C -20°...
  • Page 5 GPS-VT 103 GPS Vehicle Tracker  6.1.5 Note: The orange wire can be connected to the original car alarm horn; it can also be connected to the siren you buy with the tracker. (Siren is Option)  6.1.6 Find out the type of the door trigger is positive or negative trigger. Please connect the green wire to the door control circuit if it is positive, and connect blue wire if it is negative.
  • Page 6 GPS-VT 103 GPS Vehicle Tracker your cell phone. 6.7 Authorization There are 5 numbers to be allowed to authorize in the tracker at most.  6.7.1 Call and track the tracker device for 10 times from cell phone in success, it will make the cell phone number as the authorized number automatically, and reply “add master ok”.

  • Page 7: Low Battery Alarm

    GPS-VT 103 GPS Vehicle Tracker 6.10 Get location in real street/address name  6.10.1 You must set up the APN of your local GSM network for the SIM card in tracker first before using this function. (Please refer to 6.27 to configure the APN). ...

  • Page 8: Movement Alarm

    GPS-VT 103 GPS Vehicle Tracker Cancel: Send SMS “nostockade+password” to deactivate this function. 6.13.5 MOVEMENT ALARM Set up: when the unit stays immobile in a place for 3-10 minutes, the user can send SMS “move+password” to the tracker device. It will reply “move OK”. In case of such a movement (the default distance is 200m), it will send SMS “Move”...

  • Page 9: Arm  Disarm

    GPS-VT 103 GPS Vehicle Tracker Send SMS command "disarm + password" to the tracker device in the vehicle, It will reply “Tracker is deactivated” in both armed and disarmed state, and the SMS command will make the tracker device enter into disarmed state if the unit currently armed.
  • Page 10 GPS-VT 103 GPS Vehicle Tracker  Silent mode Press “A+B” together in disarm state for 0.5 second, the siren will alarm three time, siren won’t alarm after alarm is triggered, but tracker will send alarm SMS to authorized number.  Quite silent mode Press “A+B”...
  • Page 11 GPS-VT 103 GPS Vehicle Tracker  6.27.1 APN standards for Access Point Name and differs from country to country. For more information about your local APN, please inquire with your local GPRS network operator.  6.27.2 Text the tracker a SMS “APN123456 + Space + your local APN” via a cell phone and if succeeded, the tracker will return the message “APN OK”.
  • Page 12 GPS-VT 103 GPS Vehicle Tracker purchasing from us has 10 days free trial on this platform (the date starts from the production of the tracker) Second step: Configure your tracker so that it can connect to our server. If you want to track your trackers with our platform, you have to set APN (APN user/password if it has) first.
  • Page 13 GPS-VT 103 GPS Vehicle Tracker Advanced Common Causes Solution problems 1. SIM Card wrongly installed or GSM Move to a place with good signal. antenna is not fastened Calls can not go through 2. GSM signal is weak because of your Test again in a place with strong GSM signal.
