UVI GROUP CORPORATION
Email/MSN: kevinchu81@yahoo.cn
T30C
Personal GPS Tracker User Manual
Designer and Manufacturer of GPS Tracking System & Solutions.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T30C and is the answer not in the manual?

Questions and answers

Summary of Contents for UVI Group T30C

  • Page 1 UVI GROUP CORPORATION Email/MSN: kevinchu81@yahoo.cn T30C Personal GPS Tracker User Manual Designer and Manufacturer of GPS Tracking System & Solutions.
  • Page 2: Table Of Contents

    Open covers ················································································································8 Operating Instructions··································································································9 Position Report Function ·······················································································11 Tracking Function ····································································································11 Stop tracking function. ···························································································12 GPRS function of T30C:··························································································12 Set the APN····································································································12 Set the center IP and Port···········································································12 Set the terminal ID························································································12 Designer and Manufacturer of GPS Tracking System & Solutions.
  • Page 3: Working Directions

    Working Directions Thank you for your purchase of T30C personal GPS Tracker. In order to realize the full functions of this product, please read this manual carefully before starting to use the product. 1. This product can only be maintained and repaired by qualified professional service personnel. If you detach this product for maintenance or repair, your warranty will be invalidated.
  • Page 4: Installation

    Installation 1. Product Picture Working condition: The red LED is power light, it always light at SMS mode, it flash while connect the Operation Platform at GPRS mode. The blue LED is GSM light , if the light flash continuously , it means trackers is not connected to the network ;but if the light go out for 3seconds , and then light for a half second , that means trackers have be connected to the network , and work normally .
  • Page 5: Precaution Before Installation

    T30C will switch between SMS mode & GPRS mode. Right Button: Turn on/off T30C Power. When T30C is off, press it to turn on T30C power. When T30C is on, press it for a long time until left LED (red) flashing, it means T30C is turned off.
  • Page 6 Insert a SIM Card (must have GPRS service) into the back T30C. ※ Make sure to turn off the power before install the SIM card. ※ Make sure to deactivate the PIN code, so that the SIM card can operate without PIN protection.
  • Page 7: Battery Installation

    5. Battery Installation: 1. At first, you should connect the battery contacts carefully, (Figure 4) 2. And then, press battery into tracker (Note: Do not press very hard, it will damage connects, Figure 5) Figure 4 Figure 5 6. Open covers (Figure 6, Figure7) Figure 6 Figure 7...
  • Page 8: Operating Instructions

    Operating Instructions SMS protocol of T30C, the default password of T30C is 000000 SMS Instruction Format Remark Request one position V******,000 ****** is old password Modify user password V******,001,###### ###### is new password XXX(3 digital) =000,stop Set the time internal of...
  • Page 9 speed alarm SMS to the control number. X =1, turn on the LED Turn on/off the LED V******,007,X display (default) =0, turn off the LED display Including software version, password, interval, speed limit, area limit, I/O Inquire the system state V******,008 state, LED display state, GPS state, SOS number,...
  • Page 10: Position Report Function

    Position Report Function No matter where you are, when you want to know the position of the terminal, send a SMS message or make a telephone call to the T30C; it will report its location back to you by SMS.
  • Page 11: Stop Tracking Function

    GPRS function of T30C: If you want to use the GPRS functions of T30C, first you must set the GPRS parameters (APN, Terminal ID, IP, port) in the SMS mode. Send V******, 013, 1 to turn T30C into SMS mode A.
