HP ProLiant ML10 Maintenance And Service Manual page 18

Item Description
300 W Integrated power supply
2
System fan
3
Heatsink and fan
4
Processor (includes alcohol pad and thermal
5
compound)
a) 3.10-GHz Intel Xeon E3-1220 v2
processor, 4 C, 8 MB, 69 W
b) 3.20-GHz Intel Pentium G2130 processor,
2 C, 3 MB, 55 W*
System board assembly
6
DIMMs
7
a) 2 GB PC3-12800E, 256Mx8
b) 4 GB PC3-12800E, 256Mx8*
c) 8 GB PC3-12800E, 512Mx8*
LFF non-hot-plug SATA drives
8
a) 500 GB, 3G drive
b) 1 TB, 3G drive*
c) 2 TB, 3G drive*
Optical drive
9
a) SATA ROM drive
b) SATA RW drive
Drive enablement kit*
10
a) 220 mm SATA cable*
b) T-15, 6-32 screws (4)*
c) M3 screws (2)*
d) 1 LFF drive carrier*
4 LFF Drive enablement kit*
11
a) 1 LFF drive carrier*
b) 3 LFF drive bracket*
c)3 LFF drive carrier*
d) Shoulder screws (8)*
e) M3 screws (2) (black)*
f) T-15, 6-32 screws (20)*
g) Mini-SAS/power cable assembly*
h) 220mm SATA cable*
i) Thermal grease*
Cable kit*
12
a) Ambient temperature sensor cable*
Spare part Customer self
number repair (on
page 5)
732598-001 Mandatory
732595-001 Mandatory
732596-001 Mandatory
— —
686686-001 Optional 2
715898-001 Optional 2
732594-001 Optional 2
— —
684033-001 Mandatory
684034-001 Mandatory
684035-001 Mandatory
— —
459316-001 Mandatory
508039-001 Mandatory
508041-001 Mandatory
— —
624591-001 Mandatory
624592-001 Mandatory
732593-001 Mandatory
730645-002 Mandatory
482298-003 Mandatory
247348-001 Mandatory
744240-001 Mandatory
743250-001 Mandatory
744240-001 Mandatory
742975-001 Mandatory
742974-001 Mandatory
742977-001 Mandatory
247348-001 Mandatory
482298-003 Mandatory
742976-001 Mandatory
730645-002 Mandatory
390717-002 Mandatory
732599-001 Mandatory
731213-001 Mandatory
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Illustrated parts catalog 18
