Cub Cadet 521R Operator's Manual page 14

Models 521R & 521E
Ref. Part
No. No.
1 710-0167 Bolt, Carriage
2 710-0276 Bolt, Carriage
3 710-0323 Screw, Pan Head
4 710-0451 Bolt, Carriage
5 710-0642 Screw, Hex Washer
6 710-1005 Screw, Hex Washer
7 710-0773 Screw, Hex Washer
8 710-0896 Screw, Hex Washer
9 710-3015 Screw, Hex Cap
10 711-0848A Axle
11 712-0429 Nut, Hex Center Lock
12 712-3010 Nut, Hex
13 712-0116 Nut, Hex Lock
15 712-3027 Nut, Hex Lock Flanged
16 720-0284 Knob Assembly
17 731-0851A Keeper, Chute
18 731-0915B Chute, Lower
19 731-0921 Chute, Upper
20 731-1033 Shave Plate
21 732-0357A Spring, Extension
22 736-0108 Washer, Flat
23 736-0119 Washer, Lock
25 736-0176 Washer, Flat
26 736-0159 Washer
Description Qty.
4
1
1
1
1
6
2
4
6
1
1
3
1
10
1
3
1
1
1
1
2
1
1
2
Ref. Part
No. No.
27 736-0326 Washer, Flat
28 736-0329 Washer, Lock
29 734-1811 Wheel Assembly, Beige
30 741-0600 Ball Bearing
31 746-0910A Cable, Clutch
32 748-0234 Spacer, Shoulder
33 749-0796 Handle, Lower
34 756-0313 Idler, Flat
35 784-5174 Cup, Bearing
36 784-5176- Cover, Belt
0498
37 784-5175B Bracket, Idler/Brake
38 684-0114- Housing, Blower
0498
39 784-5485- Auger Ass'y. Comp.
0498
40 753-0613 Auger Rubber Replacement
41 710-0352 Screw, Hex Washer
42 784-5720 Bracket, Crank
43 710-0451 Screw, Cap
44 736-0242 Washer, Bell
45 741-0475 Bushing
46 710-0459A Screw, Cap
14
Description Qty.
1
1
2
2
1
1
1
1
2
1
1
1
1
1
1
1
2
2
1
1
