S J
ELECTION UMPERS
DRF-POT for POTENTIOMETER SIGNALS
Range : 100% FS
Range : 50% FS
DRF-RES for RESISTANCE SIGNALS
Range :
Range Min : 5 KOhms
Range :
Range Min : 3 KOhms
User's Manual DRF Series
: I S R
NPUT IGNAL ANGE
10 KOhms
5 KOhms
Page 7
Range : 25% FS
Range : 12.5% FS
Range : 3 KOhms
Range Min : 1.5 KOhms
Range : 1.5 KOhms
Range Min : 750 Ohms
