Page 1: Instruction Manual
Instruction Manual 360° Surround View Camera System RVS-77535 Reverse With Confidence ™... -
Page 2: Table Of Contents
Specification......47 Troubleshooting......48-49 Rear View Safety... - Page 3 NOTE! Please read all of the installation instructions carefully before installing the product. Improper installation will void manufacturer’s warranty. Congratulations on purchasing a Rear View Backup Camera System! With this manual you will be able to properly install and operate the unit. The Backup Camera System is intended to be installed as a supplement aid to your standard rear view mirror that already exists in your vehicle.
-
Page 4: Safety Information
Rear View Camera System. If you back up while looking only at the monitor, you may cause Rear View Safety... - Page 5 INSTALLATION: • Electric shock or product or disconnected wire may cause a malfunction may occur if this fire. product is installed incorrectly. • While installing the Rear View System be careful with the wire • Use this product within positioning in order to avoid wire the voltage range specified.
- Page 6 If you have questions about this product, contact: Rear View Safety 1797 Atlantic Avenue Brooklyn, NY 11233 Tel: 1.800.764.1028 IN NO EVENT SHALL SELLER OR MANUFACTURER BE LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT.
-
Page 7: Before Beginning Installation
Before drilling please check that no cable or wiring is on the other side of the wall. Please clamp all wires securely to reduce the possibility of them being damaged while vehicle is in use. Keep all cables away from hot or moving parts and electrical noisy components. We recommend doing a benchmark test before installation to insure that all components are working properly. -
Page 8: Introduction
The system offers various connection types, including HDMI and AV. It also features both 2D and 3D views. The RVS-77535 is also a fully functional DVR, capable of 24 hour loop recording. Rear View Safety... -
Page 9: Product Features
Product Features • Four 190° ultra wide fish-eye cameras • Seamless video merging based on dual core ARM CPU and high efficiency acceleration engine • Adjustable viewing angle in 3D mode • Advanced fish-eye distortion correction • Automatic brightness adjustment for each camera •... -
Page 10: Applications
Main Application Side Parking Reverse Parking Narrow Roads Blind Spot Coverage Turning Assist Rear View Safety... -
Page 11: Other Functions
Proof of Fault in Accidents Car DVR Crowded Roads Product Features Other Functions 3D & 360° seamless merging Video recording 360° blind spot coverage 24 hour parking monitoring Adjutable viewing angle in 3D mode G-sensor triggered recording Flexible omni-directional monitoring Fish-eye distortion correction Guided camera calibration Reverse With Confidence ™... -
Page 12: System Check
Wiring Test Double check all wire connections before turning on the system. Do not plug in control box until you are sure wiring is correct. Rear View Safety... - Page 13 Functionality Test Before using the system, please perform a functionality test on the main functions. Camera Calibration and Image Merging The system menu provides a step by step camera calibration guide. Once all the calibration information is collected the software will auto- matically complete the video merging.
-
Page 14: Wiring Diagram
Wiring Diagram Control Box Rear View Safety... -
Page 15: Cameras Distribution
Cameras Distribution Perspective Drawing Reverse With Confidence ™... -
Page 16: Wiring
Rear View Safety... - Page 17 Front Camera 1. Disassemble the glove box/central panel 2. Distribute the front camera cable from the logo position along the original wire distribution tube to the glove box/central panel. Rear Camera 1. Take out the trunk inner panel. 2. Distribute the rear camera cable from the license plate lamp along the original wire distribution tube to the glove box/central panel.
-
Page 18: Camera Installation
4. Using screws and the metal pad accessories, fix the front camera to the car. Note: Different car models work differently with various cameras types. Installation loca- tion may vary. Please see model installation drawings. Rear View Safety... - Page 19 Camera Installation Demonstration Of Universal Front Camera Installation method for front camera: 1. Insert the front camera to the center of the front vehicle logo. 2. Connect the front camera to the extending cable. 3. Double check the field of the view from the system preview menu window and adjust accordingly.
- Page 20 4. Connect rear camera extending cable to 12V anode of the reversing lamp to create a reversing signal. 5. After testing the video from the connected camera, place the trunk inner panel back in the vehicle. Rear View Safety...
- Page 21 Note: The installation method may be different for various vehicle models and camera shapes. Reverse With Confidence ™...
- Page 22 4. Connect rear camera extending cable to 12V anode of the reversing lamp to create a reversing signal. 5. After testing the video from the connected camera, place the trunk panel back in the vehicle. Rear View Safety...
- Page 23 Place the locating plate on the vehicle, then drill a wiring hole. Remove locating plate after drilling is complete. Lastly, fix the camera to the car with a screwdriver. Reverse With Confidence ™...
- Page 24 When drilling, use a drill bit based on the size of your camera. Choose a flat area near the edge of the side mirror plastic shell that gives the camera the widest field of view (FOV) possible. Place the camera in a location allowing easy adjustment of the side mirrors. Rear View Safety...
- Page 25 Installation Diagram Of Universal Camera Reverse With Confidence ™...
- Page 26 18mm and 26mm in di- ameter. Please be careful to select the proper drill location. Also, be sure that the camera is placed in such a location that allows for easy side mirror adjustments. Rear View Safety...
- Page 27 Control Box Installation 1. Disassemble central control unit panel/glove box and connect the re- versing video channel of monitor/other display screen (AV in). 2. Control box installation: A) Put the infrared receiver in an easily accessible position. B) After selecting a position in/near the central control panel or beside the vehicle door handle, drill hole 3.55mm in diameter, screw the unit to the bottom panel, and connect the cables.
-
Page 28: Camera Calibration
Image Calibration Menu. Choose the correct vehicle calibration size. You may also change sensor type in this menu, however it is recommended that you leave it at the default setting if you are unsure about your sen- sor type. Rear View Safety... - Page 29 Calibration Tape Placement Note: Place calibration tape around the vehicle as shown in the diagram above. Vehicles come in many different models and sizes. Please refer to calibration images matching your vehicle size for proper calibration. Reverse With Confidence ™...
- Page 30 When rotating the side camera for calibraiton, keep the vehicle body in the image next to the calibration line, while also allowing for the widest field of vision. Rear View Safety...
- Page 31 Packing Box Location Each camera has 8 calibration points to set. Both the inner and outer box of the system must be used for the third and fourth calibration points the cameras. Note: Place the 2 boxes (inner and outer) in the correct position as illustrat- ed above.
- Page 32 UP/DOWN/LEFT/RIGHT buttons and press the “OK” button to confirm the calibration point. After selecting a point the system will guide you to the next calibration point in numerical order. Press the red “MODE” button to toggle to previous calibration point as needed. Rear View Safety...
- Page 33 Note: The 7th and 8th calibration points are very different between the front/ rear cameras and side cameras. The more accurate your calibration marks are, the more accurate your image stitch will be. Image Calculation Once you have calibrated all of your cameras press “OK” to start merging. The system will reboot automatically Reverse With Confidence ™...
-
Page 34: User Settings
User Settings Viewing Modes 3D full screen Rear View Safety... - Page 35 3D+2D split screen Reverse With Confidence ™...
- Page 36 2D split screen Rear View Safety...
- Page 37 Parameters Setting and Menu Description This option allows the SVM system to automatically toggle views based on when a turn signal is used. When the system is in standby mode, this option allows it to be activated by using a turn signal. When the SVM system is in standby mode, this option allows it to be activated with the emergency blinker.
- Page 38 Rear View Safety...
- Page 39 Reverse With Confidence ™...
- Page 40 The User Preference option restores user video settings/window configurations and other options. Use this option to upgrade firmware or change the car model to better suit your vehicle Rear View Safety...
- Page 41 Use this option to choose how long the system will be active when turned on with the Emergency Blinker. Remember to first turn on Blinker Activation in the function menu. Some DVD models may have a problem with the AV-In signal coming in when the system boots up.
-
Page 42: Video Recording
2. Press “OK” button to stop current recording. 3. Use the “UP/DOWN” buttons to navigate between recorded files. 4. Press “CONFIRM” button to select a file to playback. Press the “LEFT” or “RIGHT” buttons to view the individual cameras in full screen. Rear View Safety... -
Page 43: Basic Settings
Recording Parameters Basic Settings Reverse With Confidence ™... -
Page 44: Power Management
During silent driving mode, the system will continuously record onto the microSD card/USB disk. Note: USB disks have a higher priority over microSD cards. Driving Assistant Mode/Parking Assistant Mode These modes use the most power, because both the recording board and SVM core board are being used. Rear View Safety... -
Page 45: Standby Mode
Standby Mode The system is on standby. Any vibration detected by the G-sensor, the SVM system will power up the external Cameras/LEDs immediately and start recording. Power Off Mode In this mode, the system is off except for the real time clock chip and G-sensor. -
Page 46: Packing List
Packing List Control Box Rear View Safety... -
Page 47: Specification
Specification Reverse With Confidence ™... -
Page 48: Troubleshooting
If you are using OEM cameras, check if the the image is mirrored. If mirrored, change the setting. Problem #3 Corner Picture Is Blank These problem may be caused by the camera position. Make sure the camera has a wide field of vision. Rear View Safety... -
Page 49: Troubleshooting
Diagnostics & Troubleshooting Merging Does Not Work 1. Be sure calibrate correctly based on your vehicle size. Failure to do so will result in improper calibration. 2. Do not mix up the camera positions when calibrating. This will result in improper calibration. - Page 50 If you have any questions about this product, contact: Rear View Safety, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 800.764.1028 Better Cameras. Better Service. IT’S OUR GUARANTEE. Rear View Safety...
