Safe Operation Practices • Set-Up • Operation • Maintenance • Service • Troubleshooting • Warranty
O
'
M
peratOr
s
anual
Pressure Washer —
Model Series CC3224, CC3425, CC4033
WARNING
READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL
BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
MTD LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
Printed In USA
Form No. 769-10274
(November 24, 2014)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cub Cadet CC3224
Summary of Contents for Cub Cadet CC3224
-
Page 1: Pressure Washer
’ peratOr anual Pressure Washer — Model Series CC3224, CC3425, CC4033 WARNING READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL BEFORE ATTEMPTING TO OPERATE THIS MACHINE. FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY. -
Page 2: Table Of Contents
Visit us on the web at www.cubcadet.com ◊ Call a Customer Support Representative at (800) 965-4CUB ◊ Locate your nearest Cub Cadet Dealer at (877) 282-8684 ◊ Write us at Cub Cadet LLC • P.O. Box 361131 • Cleveland, OH • 44136-0019... -
Page 3: Safe Operation Practices
Important Safe Operation Practices This manual contains information that is important for you to know and understand. This information relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you recognize this information, we use the symbols below. Please read the manual and pay attention to these symbols. DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in... - Page 4 WARNING: Do not operate this unit until you read this instruction manual and the engine instruction manual for safety, operation and maintenance instructions. DANGER: Risk of injection or severe injury. Keep clear of nozzle. Do not direct discharge stream at persons or live animals. This product is to be used only by trained operators. DANGER: RISK Of ExPLOSION OR fIRE WhAT CAN hAPPEN hOW TO PREVENT IT...
- Page 5 DANGER: RISK Of fLUID INJECTION AND LACERATION WhAT CAN hAPPEN hOW TO PREVENT IT • Your pressure washer operates at fluid pressures and • Inspect the high pressure hose regularly. Replace the velocities high enough to penetrate human and animal flesh hose immediately if it is damaged, worn, has melted from which could result in amputation or other serious injury.
- Page 6 DANGER: RISK Of UNSAfE OPERATION (CONTINUED) WhAT CAN hAPPEN hOW TO PREVENT IT • If proper starting procedure is not followed, engine can • If engine does not start after two pulls, squeeze trigger of kickback causing serious hand and arm injury. gun to relieve pump pressure.
-
Page 7: Spark Arrestor
WARNING: RISK Of BURSTING WhAT CAN hAPPEN hOW TO PREVENT IT • Over inflation of tires could result in serious injury and • Use a tire pressure gauge to check the tires pressure before property damage. each use and while inflating tires; see the tire sidewall for the correct tire pressure. -
Page 8: Safety Symbols
Safety Symbols This page depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the machine before attempting to assemble and operate. Symbol Description READ THE OPERATOR’S MANUAL(S) Read, understand, and follow all instructions in the manual(s) before attempting to assemble and operate DANGER —RISK OF FIRE OR EXPLOSION. -
Page 9: Assembly & Set-Up
Assembly & Set-Up Contents of Carton • One Pressure Washer • One Handle • One Spray Gun • One Pressure Washer Operator’s Manual • One High Pressure Hose • Five Quick-Connect Nozzles • One Engine Operator’s Manual • One Quick-Connect Spray Wand • One Bottle of Oil Assembly Nozzles Remove the colored quick-connect nozzles from the plastic NOTICE: This unit is shipped without gasoline or oil in bag and insert them into correct grommet on the nozzle the engine. Fill up with gasoline and oil as instructed in the holder. Nozzles are color coded to match colored nozzles accompanying engine manual BEFORE operating your mower. on label. NOTICE: The high-pressure pump was filled with oil at the factory. Always check oil level before using (refer to Maintenance & Adjustments for more information). Handle Slide the handle assembly onto the frame and secure with saddle bolts and knobs. - Page 10 Set-Up Wand to Gun Connect wand to gun. Tighten securely. Gas and Oil Fill-Up Refer to the separate engine owner’s manual for additional engine information. Add oil provided before starting unit for the first time out of the box. Service the engine with gasoline as instructed in the separate engine owner’s manual. WARNING: Use extreme care when handling gasoline. Gasoline is extremely flammable and the vapors are explosive. Never fuel the machine indoors or while the engine is hot or running. Extinguish cigarettes, cigars, pipes and other sources of ignition. Figure 3-3 Hose to Gun Attach high pressure hose to gun. Tighten se c ure l y. Figure 3-4 3 — A & S ection SSembly...
-
Page 11: Controls & Features
Controls and Features Quick-Connect High Pressure Handle Nozzles Hose Nozzle Holder Engine Side Gun Handle CC3425, CC4033 Dial-N-Wash® CC3425, CC4033 High Pressure Pump Frame Pump Pump Outlet Inlet Quick-Connect Spray Wand Figure 4-1 High Pressure Pump Spray Gun Increases the pressure of the water supply. Connects with spray wand to control water flow rate, direction and pressure. -
Page 12: Pressure Washer Terminology
• CC3224- Change to the 40˚ nozzle (white). This nozzle Thermal Relief Valve delivers a less powerful stream of water and a wider spray pattern. Refer to “How To Use Spray Wand”. - Page 13 Nozzle Spray Uses Surfaces* Color Pattern 0˚ powerful unpainted metal pinpoint for or concrete; spot cleaning of DO NOT use on hard, unpainted wood surfaces or for high reach areas 15˚ intense cleaning grills, driveways, of unpainted concrete or Yellow hard surfaces brick walkways, unpainted brick...
- Page 14 NOTE: For every 7 gallons of water pumped 1 gallon of chemical/cleaning solution will be used. CC3224 – Install low pressure (black) nozzle into quick connect fitting of spray wand, see “How To Use Spray Wand” paragraph in this section.
-
Page 15: Operation
Operation Starting • D O NOT use hot water, use cold water only. • N ever turn water supply off while pressure washer WARNING: To reduce the risk of injury, read the engine is running or damage to pump will result. pressure washer instruction manual and the engine •... -
Page 16: Shutting Down
WARNING: Connect water source to pump inlet. Risk of unsafe operation. If engine NOTE: Water source must provide a minimum of 5 gallons does not start after two pulls, squeeze trigger of gun per minute at 20 PSI. to relieve pump pressure. Pull starter cord slowly until resistance is felt. -
Page 17: Maintenance & Adjustment
Maintenance & Adjustments Maintenance How To Change Pump Oil Loosen pump oil fill plug. General Recommendations Place a container under the pump oil drain plug. • Always observe safety rules when performing any Remove pump oil drain plug. maintenance. After oil is drained, replace pump oil drain plug. Tighten • The warranty on this pressure washer does not cover items securely. that have been subjected to operator abuse or negligence. To receive full value from warranty, operator must maintain Refill pump using SIMPSON Premium Pump Crankcase Oil. ® the pressure washer as instructed here. If this oil is not available, an SAE 15W-40 oil may be used. • Changing of engine-governed speed will void engine Replace pump oil fill plug and tighten securely. warranty. If there is a problem with the pump, please contact our customer • All adjustments should be checked at least once each service department. season. Oil Fill Plug •... - Page 18 Nozzle Cleaning Re-insert filter into water inlet of pump. NOTE: Convex side faces out. If the nozzle becomes clogged with foreign materials, such as dirt, excessive pressure may develop. If the nozzle becomes partially clogged or restricted, the pump pressure will pulsate. Clean the nozzle immediately using the nozzle kit supplied and the following instructions: Shut off the pressure washer and turn off the water supply. Pull trigger on gun handle to relieve any water pressure. Disconnect the spray wand from the gun. Remove the high pressure nozzle from the spray wand. Remove any obstructions with the nozzle cleaning tool provided and backflush with clean water. Figure 6-3 NOTE: Do not operate the pressure washer without filter properly installed. Engine Care A list of key engine maintenance jobs required for good performance by the pressure washer is given below. Follow the accompanying engine manual for a detailed list and instructions. • Maintain oil level as instructed in engine manual. • Service air cleaner as instructed in engine manual. Clean every few hours under extremely dusty conditions. Poor engine performance and flooding usually indicates that the air cleaner should be serviced. To service the air cleaner, refer to the engine manual. • Clean spark plug and reset the gap once a season. Spark plug replacement is recommended at the start of each Figure 6-2 mowing season. Check engine manual for correct plug Direct water supply into nozzle to backflush loosened type and gap specifications.
-
Page 19: Service
Visit us on the web at www.cubcadet.com Specifications ◊ Call a Customer Support Representative at (800) 965-4CUB Model CC3224 CC3425 CC4033 ◊ Locate your nearest Cub Cadet Dealer at (877) 282-8684 PSI Max* 3200 3400 4000 ◊ W riteusatCubCadetLLC•P.O.Box361131•Cleveland, GPM Max* OH•44136-0019 High Pressure 25 ft. -
Page 20: Troubleshooting
Troubleshooting Cause Remedy Problem Engine will not start , refer to engine 1. No fuel. 1. Add fresh fuel. See engine manual. manual 2. Pressure builds up after two pulls on the 2. Squeeze gun trigger to relieve recoil starter or after initial use. pres sure. - Page 21 Cause Remedy Problem Will not draw chemicals 1. Spray wand not in low pressure. 1. See How to “Use Spray Wand” paragraph in the Features and Controls Section. 2. Clean filter. 2. Chemical filter clogged. 3. Chemical screen not in cleaning solution. 3.
-
Page 22: Replacement Parts
Notes... - Page 23 Notes...
-
Page 24: Warranty
Service completed by someone other than an authorized service The limited warranty set forth below is given by Cub Cadet LLC with dealer. respect to new merchandise purchased or leased and used in the United...
