DVTEL CT-5322F Quick Installation Manual

Fixed thermal analytic camera
Hide thumbs Also See for CT-5322F:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installer and User Manual
DVTEL INC.
65 Challenger Road
Ridgefield Park, NJ 07660
CT-5322F/CT-5642F
Fixed Thermal
Analytic Camera
Quick Installation
Guide
The contents of this guide
may not be reproduced or
reprinted in whole or in part
without the express written
Rev A1
September 24, 2015
permission of DVTEL, INC.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CT-5322F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DVTEL CT-5322F

Summary of Contents for DVTEL CT-5322F

  • Page 1 Ridgefield Park, NJ 07660 CT-5322F/CT-5642F Fixed Thermal Analytic Camera Quick Installation Guide The contents of this guide may not be reproduced or reprinted in whole or in part without the express written Rev A1 September 24, 2015 permission of DVTEL, INC.
  • Page 2 CT-5322F/CT-5642F Fixed Thermal Analytic Camera QIG...

  • Page 3: Table Of Contents

    Mounting the Camera..........18 4. Accessing the Camera ............19 4.1. Device Discovery ............19 4.2. Viewing Live Video ............20 5. Configuring Analytics ............24 5.1. Configuring Depth Settings .......... 24 5.2. Configuring Rules ............25 Contacting DVTEL ..............27...
  • Page 4 CT-5322F/CT-5642F Fixed Thermal Analytic Camera QIG List of Figures Figure 1: System Installation ............5 Figure 2: Package Contents ............6 Figure 3: Connector Panel .............. 8 Figure 4: Recommended Tools ............. 11 Figure 5: Attaching the Base Mount ..........11 Figure 6: Cordgrip Parts ..............

  • Page 5: Document Information

    Document Scope and Purpose The purpose of this document is to provide instructions and installation procedures for physically connecting the ioi Thermal CT-5322F/CT-5642F fixed cameras. After completing the physical installation, additional setup and configurations are required before video analysis and detection can commence.
  • Page 6 Users of DVTEL products accept full responsibility for ensuring the suitability and considering the role of the product detection capabilities and their limitation as they apply to their unique site requirements. DVTEL, Inc. and its agents make no guarantees or warranties to the suitability for the users’ intended use. DVTEL, Inc.
  • Page 7 Document Information Camera Warnings Warning: 1. Only qualified trained personnel should service and repair this equipment. 2. Observe local codes and laws and ensure that installation and operation are in accordance with fire, security and safety standards. 3. The unit’s cover is an essential part of the product. Do not open or remove it.
  • Page 8 CT-5322F/CT-5642F Fixed Thermal Analytic Camera QIG Avertissements relatifs à la Caméra Avertissement: 1. Seul un technicien formé et qualifié est autorisé à entretenir et à réparer cet équipement. 2. Respectez les codes et réglementations locaux, et assurez-vous que l'installation et l'utilisation sont conformes aux normes contre l'incendie et de sécurité.

  • Page 9: Introduction

    Introduction 2. Introduction This document provides information about the ioi Thermal CT-5322F/ CT-5642F fixed-mount, fixed focal length thermal camera that includes integrated video analytics. The NTSC/PAL camera system is a hybrid analog/ Internet Protocol (IP) networked solution that supports the Open Network Video Interface Forum (ONVIF™) Profile S standard.

  • Page 10: Package Contents

    CT-5322F/CT-5642F Fixed Thermal Analytic Camera QIG 2.1. Package Contents The unit package contains the following items: Figure 2: Package Contents Item Description CT-5322F/CT-5642F Fixed Thermal Analytic Camera (with 90° RG179BU BNC adapter attached to the connector panel) Base mount Back cover...
  • Page 11 Note: Use PoE+ or a 12-24VDC or 24 VAC power source that supplies 20W. IEEE 802.3af PoE is NOT supported. Related information:  ioi Thermal CT-5322F/CT-5642F User and Installation Guide  HTML Edition Units User’s Guide  DNA User Manual...

  • Page 12: Connector Panel

    CT-5322F/CT-5642F Fixed Thermal Analytic Camera QIG 2.2. Connector Panel The connector panel includes the following items: Figure 3: Connector Panel Item Comment Connects the analog video coax cable between the camera and an Video Port analog DVR. Connects the network cable between the camera and the...

  • Page 13: Installation And Mounting

    IP network connectivity. When finished with the physical installation, refer to the ioimage Thermal CT-5322F/CT-5642F User and Installation Guide to complete the second phase of installation, which is the setup and configuration of the unit.

  • Page 14: Preparation

    CT-5322F/CT-5642F Fixed Thermal Analytic Camera QIG 3.1. Preparation Read the instructions in this chapter thoroughly before installing the camera. Following are additional considerations for outdoor installation:  Always use weatherproof equipment, such as boxes, receptacles, connectors, etc.  For electrical wiring, use the properly rated sheathed cables for conditions to which the cable will be exposed (for example, moisture, heat, UV, physical requirements, etc.).

  • Page 15: Attach The Base Mount To The Camera

    Installation and Mounting  Hex wrench  RJ45 connector  RJ45 crimping tool  Coax cable  Coax cable cutter/stripper  BNC connector  BNC crimping tool Figure 4: Recommended Tools 3.3. Attach the Base Mount to the Camera To attach the base mount to the camera Screw the base mount into the camera body with eight #6 screws.

  • Page 16: Connecting The Camera Cables

    CT-5322F/CT-5642F Fixed Thermal Analytic Camera QIG 3.4. Connecting the Camera Cables In order to connect the camera to the network, take the analog video cable, network cable, power supply leads (if an AC or DC supply is used), alarm, and relay wiring from the wall at the installation site.

  • Page 17: Figure 8: Rubber Grommet

    Installation and Mounting Place the orange O-ring over the cordgrip and feed the wires through the cordgrip body and sealing nut as seen in Figure 9. Insert the Ethernet cable through the center opening of the rubber grommet. Then insert the other wires through the small holes in the rubber.

  • Page 18: Figure 11: Assembling Sealing Nut

    CT-5322F/CT-5642F Fixed Thermal Analytic Camera QIG Insert the wires through the sealing nut and screw the nut so that it is closes tightly on the cordgrip body. Use the hex wrench to tighten the nut to 50-55 inch-pounds (5.65-6.215 newton meters) of torque so that the cordgrip is securely fastened.

  • Page 19: Figure 14: Power Wires With Ferrite

    Installation and Mounting If the camera is connected to an alarm or a 12 or 24 volt power supply, it is necessary to insert the wires through the supplied ferrites in order to comply with EMI emission standards. Figure 13: Power Wires with Ferrite Attach the supplied plugs to the wires.

  • Page 20: Figure 15: Back Cover And White Desiccant

    CT-5322F/CT-5642F Fixed Thermal Analytic Camera QIG Note: If you use a PoE+ switch, in order to ensure a proper earth ground between the camera and the PoE+ switch, we strongly recommend using Shielded Twisted Pair (STP) cabling. Installations of ioimage Thermal cameras with STP...

  • Page 21: Figure 16: Covering The Connector Panel

    Installation and Mounting Close the rear cover over the assembled connector panel by aligning the notch on the cover with the notch in the camera body. If necessary, reinsert any excess cable into the body of the camera. Figure 16: Covering the Connector Panel Attach the back cover to the camera.

  • Page 22: Mounting The Camera

    CT-5322F/CT-5642F Fixed Thermal Analytic Camera QIG Figure 18: Fully Assembled Camera 3.5. Mounting the Camera The camera can be mounted on a tripod or on a base mount or four-hole bracket.  For tripod mounting, use the tripod adapter, which is available as an accessory.

  • Page 23: Accessing The Camera

     IE 8, 9, 10, or 11 browser 4.1. Device Discovery We recommend using DVTEL’s DNA tool to discover the camera on the network. Note: Use a DHCP server to facilitate discovery of the unit’s IP Address. Confirm that Use DHCP is checked in DNA’s Assign IP dialog box.

  • Page 24: Viewing Live Video

    CT-5322F/CT-5642F Fixed Thermal Analytic Camera QIG Enter the unit’s IP address in your browser (IE 8, 9, 10, or 11). When the Login window opens, enter the unit’s default user name and password (“admin” and “admin”). 4.2. Viewing Live Video After logging in for the first time or loading a new firmware version, a dialog box opens in the user interface, requesting you to install the ActiveX plug.

  • Page 25: Figure 21: Windows Restart Dialog Box

    Accessing the Camera If you receive this message, click Restart Now on the Windows dialog box to restart the computer. The computer restarts. Figure 21: Windows Restart Dialog Box Open your browser and enter the camera’s IP address. The Login window opens.
  • Page 26 CT-5322F/CT-5642F Fixed Thermal Analytic Camera QIG The View screen includes the following icons, buttons, controls and menus: Item Description Video Stream Select the video stream: H.264, MJPEG, or HTTP JPEG. You can select multiple video streams from a single camera, which open in separate browser windows.
  • Page 27 Accessing the Camera Item Description Automatic Gain Control (AGC) adjusts the gain and level of the entire scene in real-time. From the drop- down menu, select a mode:  Freeze – Turns off/freezes AGC at its current level.  Auto – provides an image with optimum average contrast and brightness.

  • Page 28: Configuring Analytics

    CT-5322F/CT-5642F Fixed Thermal Analytic Camera QIG 5. Configuring Analytics The Analytics tab contains menus for defining the camera’s field of view depth and detection rules. Figure 23: Depth Screen 5.1. Configuring Depth Settings Follow these steps in the Analytics > Depth screen wizard to configure depth settings: 1.

  • Page 29: Configuring Rules

    Configuring Analytics 5. Click Browse to load and view the clip. Navigate the clip and add human markers. 6. Exit Clip mode and return to Live mode by pressing the round Play button on the control panel located to the left of the monitor. Continue setting depth by proceeding to the tabs for Steps 2-4.
  • Page 30 CT-5322F/CT-5642F Fixed Thermal Analytic Camera QIG Detection occurs when one or more detection rules are active, the camera is in Arm mode, and the scenario on the video (scene) fits the detection criterion specified. You can activate rules, modify settings, delete, or add a new rule. Rules are selected by clicking the Attributes tab.

  • Page 31: Contacting Dvtel

    電郵: info.northasia@dvtel.com info.northasia@dvtel.com To request the latest versions of firmware and software or to download other product-related documents, visit http://www.dvtel.com/support. If you have obtained a login, go to our support gateway. For assistance, email us at support@dvtel.com or phone 1-888-DVTEL77.
