DVTEL CT-5320F Quick Installation Manual

Fixed thermal camera
Hide thumbs Also See for CT-5320F:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installer and User Manual
DVTEL INC.
65 Challenger Road
Ridgefield Park, NJ 07660
CT-5320F/CT-5640F
Fixed Thermal Camera
Quick Installation
Guide
The contents of this guide
may not be reproduced or
reprinted in whole or in part
without the express written
Rev H
December 18, 2014
permission of DVTEL, INC.
Document P/N 1018266

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CT-5320F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DVTEL CT-5320F

Summary of Contents for DVTEL CT-5320F

  • Page 1 Ridgefield Park, NJ 07660 CT-5320F/CT-5640F Fixed Thermal Camera Quick Installation Guide The contents of this guide may not be reproduced or reprinted in whole or in part without the express written Rev H December 18, 2014 permission of DVTEL, INC. Document P/N 1018266...
  • Page 2 CT-5320F/CT-5640F Fixed Thermal Camera QIG...

  • Page 3: Table Of Contents

    Attaching the Camera to an Analog Device ....11 3.7. Assembling the Camera Components ......11 3.8. Mounting the Camera..........13 4. Accessing the Camera ............15 4.1. Device Discovery ............15 4.2. Viewing Live Video ............16 Contacting DVTEL ..............19...
  • Page 4 CT-5320F/CT-5640F Fixed Thermal Camera QIG List of Figures Figure 1: Package Contents ............1 Figure 2: Recommended Tools ............5 Figure 3: Installation Step 1 Illustration ........... 6 Figure 4: Installation Step 2 Illustration ........... 7 Figure 5: Installation Step 4 Illustration ........... 7 Figure 6: Installation Step 5 Illustration ...........

  • Page 5: Document Information

    Document Scope and Purpose The purpose of this document is to provide instructions and installation procedures for physically connecting the ioimage Thermal CT-5320F/CT-5640F fixed cameras. After completing the physical installation, additional setup and configurations are required before video analysis and detection can commence.
  • Page 6 Users of DVTEL products accept full responsibility for ensuring the suitability and considering the role of the product detection capabilities and their limitation as they apply to their unique site requirements. DVTEL, Inc. and its agents make no guarantees or warranties to the suitability for the users’ intended use. DVTEL, Inc.
  • Page 7 Document Information Camera Warnings Warning: 1. Only qualified trained personnel should service and repair this equipment. 2. Observe local codes and laws and ensure that installation and operation are in accordance with fire, security and safety standards. 3. The unit’s cover is an essential part of the product. Do not open or remove it.
  • Page 8 CT-5320F/CT-5640F Fixed Thermal Camera QIG Avertissements relatifs à la Caméra Avertissement: 1. Seul un technicien formé et qualifié est autorisé à entretenir et à réparer cet équipement. 2. Respectez les codes et réglementations locaux, et assurez-vous que l'installation et l'utilisation sont conformes aux normes contre l'incendie et de sécurité.

  • Page 9: Introduction

    Introduction 2. Introduction This document provides information about the ioimage Thermal CT-5320F/ CT-5640F fixed-mount, fixed-focal length thermal camera. The NTSC/PAL camera system is a hybrid analog/Internet Protocol (IP) networked solution that conforms to the Open Network Video Interface Forum (ONVIF™) Profile S standard.
  • Page 10 A 24 VAC power source should supply 13W. Be sure that a 12VDC supply is rated at 2 amps and that a 24VDC supply is rated at 1 amp. Related information:  ioimage Thermal CT-5320F/CT-5640F User and Installation Guide  ioimage HTML Edition Units User’s Guide ...

  • Page 11: Installation And Mounting

    IP network connectivity. When finished with the physical installation, refer to the ioimage Thermal CT-5320F/CT-5640F User and Installation Guide to complete the second phase of installation, which is the setup and configuration of the unit.

  • Page 12: Preparation

    CT-5320F/CT-5640F Fixed Thermal Camera QIG 3.1. Preparation Read the instructions in this chapter thoroughly before installing the camera. Following are additional considerations for outdoor installation:  Always use weatherproof equipment, such as boxes, receptacles, connectors, etc.  For electrical wiring, use the properly rated sheathed cables for conditions to which the cable will be exposed (for example, moisture, heat, UV, physical requirements, etc.).

  • Page 13: Preparing The Cables

    Installation and Mounting  Torx T10 pin-in security bit, 3-1/2” (90mm) in length  Hex wrench  RJ45 connector  RJ45 crimping tool  Coax cable  Coax cable cutter/stripper  BNC connector  BNC crimping tool Figure 2: Recommended Tools 3.3.

  • Page 14: Inserting Ethernet And Video Cables Into The Camera

    CT-5320F/CT-5640F Fixed Thermal Camera QIG  Four-hole mount adapter, with its flat surface facing the mating standard four-hole bracket, if required  Base mount (flat side first for base-mounting bracket)  Electrical nut (convex side) of the supplied cable sealing gland ...

  • Page 15: Figure 4: Installation Step 2 Illustration

    Installation and Mounting Feed the Cat 5 Ethernet cable and video coax cable through the gland housing. The Ethernet cable goes through the center of the gland housing. The analog video cable goes through one of the five outer holes of the gland housing. Figure 4: Installation Step 2 Illustration Push the gland housing over the cables.

  • Page 16: Preparing The Ip66 Enclosure

    CT-5320F/CT-5640F Fixed Thermal Camera QIG Insert the cables and gland housing into the camera and attach them to the connectors. Figure 7: Installation Step 6 Illustration Slide the gland housing chassis nut over the cables. Tighten the gland housing chassis nut into the camera.

  • Page 17: Figure 9: Ip66 Enclosure With Poe Connection

    Installation and Mounting Attach an RJ45 connector to the Ethernet cable. Pull the cables tightly back through the camera, exposing the thread of the cable sealing gland out of the base of the camera. Attach the electrical nut back onto the gland. Tighten the nut securely until it is finger-tight.

  • Page 18: Figure 10: Ac Power Installation

    CT-5320F/CT-5640F Fixed Thermal Camera QIG To prepare the camera for AC/DC power connections Attach the male AC or DC five-pin terminal block connector to the AC or DC power cables. Figure 10: AC Power Installation Figure 11: DC Power Installation Insert the male connector into the female connector on the back of the camera housing.

  • Page 19: Attaching The Camera To An Analog Device

    Installation and Mounting 3.6. Attaching the Camera to an Analog Device In order to prevent video signal distortion, the supplied ground loop isolator must be installed between the analog out connector on each camera and an attached analog device if: ...

  • Page 20: Figure 15: Back Cover And White Desiccant

    CT-5320F/CT-5640F Fixed Thermal Camera QIG  AC/DC power: Connect the AC or DC male terminal block connectors to the camera according to the wiring in section 3.5.  If you are powering the camera with an AC supply, insert the...

  • Page 21: Mounting The Camera

    Installation and Mounting Attach the back cover to the camera using two #6 screws and two master seal washers, placing the metal side against the head of the screw and gasket side against the camera body. Figure 16: Back Cover Screws and Sealing Washer Tighten the two fasteners to approximately 10 in-lbs.

  • Page 23: Accessing The Camera

     IE 8, 9, 10, or 11 browser 4.1. Device Discovery We recommend using DVTEL’s DNA tool to discover the camera on the network. Note: Use a DHCP server to facilitate discovery of the unit’s IP Address. Confirm that Use DHCP is checked in DNA’s Assign IP dialog box.

  • Page 24: Viewing Live Video

    CT-5320F/CT-5640F Fixed Thermal Camera QIG Click the Login icon and enter login credentials for the devices. Enter the unit’s IP address in your browser (IE 8, 9 10, or 11). When the Login window opens, enter the unit’s default user name and password (“admin”...
  • Page 25 Accessing the Camera The View screen includes the following icons, buttons, controls and menus: Item Description Video Stream Select the video stream: H.264, MJPEG, or HTTP JPEG. You can select multiple video streams from a single camera, which open in separate browser windows. HTTP JPEG is recommended for: ...
  • Page 26 CT-5320F/CT-5640F Fixed Thermal Camera QIG Item Description Automatic Gain Control (AGC) adjusts the gain and level of the entire scene in real-time. From the drop- down menu, select a mode:  Freeze – Turns off/freezes AGC at its current level.

  • Page 27: Contacting Dvtel

    電郵: info.northasia@dvtel.com info.northasia@dvtel.com To request the latest versions of firmware and software or to download other product-related documents, visit http://www.dvtel.com/support. If you have obtained a login, go to our support gateway. For assistance, email us at support@dvtel.com or phone 1-888-DVTEL77.
