CM2 Sidescan Sonar User Manual
Tow Cable Specifications
Tow cable, types available
Coaxial or twisted pair; circuit resistance 200ohm max.
Tow cable diameter options
11.4, 8.2, 6.4 or 4.7mm, stainless steel armoured
8mm "soft", polyamide reinforced, PU sheathed
Custom cables also available; also suits some "legacy" cables
Tow cable terminator weak link (breakable washer)
75kgf nominal actuation tension, actuates to reverse-tow the towfish
Version 3.6 (2008)
32
15. Specifications
