HP Compaq 8300 Elite Quickspecs page 10

QuickSpecs
Standard Features
STORAGE
3.5" SATA Hard Drive
250 GB, 7200 rpm, SATA 6.0 Gb/s, SMART IV
500 GB, 7200 rpm, SATA 6.0 Gb/s, SMART IV
1 TB, 7200 rpm, SATA 6.0 Gb/s, SMART IV
2.5 " SATA Hard Drive
320 GB, 7200 rpm, SATA 6.0 Gb/s, SMART IV
500 GB, 7200 rpm, SATA 6.0 Gb/s, SMART IV
2.5" Solid State Drive
120 GB, SATA, Solid State Drive
128 GB, SATA, Solid State Drive
2.5" Self-Encrypting Solid State Drive
256 GB, SATA, Self-Encrypting Solid State Drive
2.5" Self-Encrypting Drive
500 GB, SATA, Self-Encrypting Drive
Flash Cache Module
24GB mSATA SSD Flash Cache Module (Intel Smart Response Technology - Optional with Core Processors)
Optical Disc Drive
Slim Tray-load SATA DVD-ROM
Slim Tray-load SATA SuperMulti DVD Writer
No included Optical Disc Drive
Media Card Reader (optional)
6-in-1 PCIe Interface
Supports Secure Digital (SD, SDHC), MultiMedia Card (MMC), xD-Picture Card, Memory Stick, Memory Stick Pro
MEMORY
Type
Non-ECC, DDR3 SDRAM, 1600 MT/s, SODIMM
Maximum
16 GB
# of Slots
2
204-pin supporting dual-channel memory
Maximized dual-channel performance requires SODIMMs of the same size and speed in both memory slots.
NOTE: Full availability of 4 GB or more of memory requires a 64-bit operating system. With Windows 32-bit
operating systems, the amount of usable memory is dependent upon your configuration, so that above 3 GB all
memory may not be available due to system resource requirements.
Memory modules support data transfer rates up to 1600 MT/s; actual data rate is determined by the system's
configured processor. See processor specifications for supported memory data rate.
DA - 14352 Worldwide QuickSpecs — Version 24 — 3.5.2013
HP Compaq 8300 Elite All-in-One PC
Page 10
