Product End-of-Life Disassembly Instructions
Product Category: Personal Computers
Marketing Name / Model
[List multiple models if applicable.]
HP Compaq Elite 8300 MT PC
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU
directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as
applicable.
Item Description
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
Batteries
Mercury-containing components
Liquid Crystal Displays (LCD) with a surface greater
than 100 sq cm
Cathode Ray Tubes (CRT)
Capacitors / condensers (Containing PCB/PCT)
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
External electrical cables and cords
Gas Discharge Lamps
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Components and waste containing asbestos
EL-MF877-00
Template Revision B
Notes
With a surface greater than 10 sq cm
All types including standard alkaline and lithium coin
or button style batteries
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries
Includes background illuminated displays with gas
discharge lamps
eg:Acbel EPA PSU,detail information refer to note
1.
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
PSG instructions for this template are available at
EL-MF877-01
Quantity
of items
included
in product
2
1
3
Page 1
Advertisement
Related Manuals for HP Compaq Elite 8300 MT PC
Summary of Contents for HP Compaq Elite 8300 MT PC
- Page 1 Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
- Page 2 Components, parts and materials containing refractory ceramic fibers Components, parts and materials containing radioactive substances 2.0 Tools Required List the type and size of the tools that would typically be used to disassemble the product to a point where components and materials requiring selective treatment can be removed.
- Page 3 Figure 1 Remove the access panel: Figure 2 Disconnect the cables from fan duct Figure 3 Disconnect the cables from the MB Figure 4 Remove front system fan from the chassis Figure 5 Disconnect CPU Power cable from the MB Figure 6 Disconnect other PSU cables from the MB EL-MF877-00 Page 3...
- Page 4 Figure 7 Disconnect SATA cable from ODD Figure 8 Disconnect SATA cable from HDD Figure 9 Remove front panel Figure 10 Remove the ODD from cage Figure 11 Loose the PSU’s screw from chassis Figure 12 Remove the PSU from Cage EL-MF877-00 Page 4 Template Revision B...
- Page 5 Figure 13 Loose the Rear fan’s screw from chassis Figure 14 Remove Rear system fan Figure 15 Loose the screws of FIO and remove it Figure 16 Remove the Power LED cable Figure 17 Loose the screws of speaker and remove it Figure 18 Remove the Memory card from the board EL-MF877-00 Page 5...
- Page 6 Figure 19 Loose the screws and remove heat sink Figure 20 Rotate the handle and open it up Figure 21 Remove the CPU from the board Figure 22 Remove the battery from the system board Figure 23 Remove the battery from the system board Figure 24 Loose the screws of MB from chassis EL-MF877-00 Page 6...
- Page 7 Figure 25 Remove M/B from chassis Figure 26 Remove the ODD lock from chassis Figure 27 Remove the HDD lock from chassis Figure 28 Remove cable clip from chassis Figure 29 Loose the screws of fan from the fan duct Figure 30 Remove the system fan from fan duct EL-MF877-00 Page 7...
- Page 8 Figure 31 Remove the fan guard from fan Figure 32 Remove the screws on the PSU chassis Figure 33 Lift the cover off the power supply Figure 34 Remove the four screws on the board Figure 35 Remove the power supply PCA from the Figure 36 Remove the Electrolytic Capacitors(For Liteon power supply chassis 320W EPA PSU )
- Page 9 Figure 37 Remove the Electrolytic Capacitors（For Figure 38 Remove the Electrolytic Capacitors（For Acbel 320W EPA） Chicony 320W STD） Figure 39 Remove the Electrolytic Capacitors（For Figure 40 Remove the Electrolytic Capacitors（For Delta Delta 320W EPA） 320W STD） Figure 41 Remove the Electrolytic Capacitors（For Figure 42 Remove the Electrolytic Capacitors（For Bestec 320W STD）...
