- Page 1 L O V E W O N D E R A N D I T L O V E S Y O U B A C K C A R S E AT O W N E R ’ S M A N U A L Im po r t a n t in s t r u ctio ns o n s et up , m ain te n anc e an d care .
-
Page 2: Important Safety Information
User Guide: The instruction manual should be kept safely with child car seat base for its life period: There is a compartment at the rear of the Wonder child car seat for storage of the instruction manuals. Cosatto wants you to be happy with the fitting & security of your child car seat. -
Page 3: Child Car Seat
Never use the child car seat without its fabric cover because the fabric cover constitutes as an integral part of the child car seat performance. The fabric cover should not be replaced with any other than the ones recommended by Cosatto. •... - Page 4 • WARNING: Do not use the child car seat in the home. It has not been designed for home use and should only be used in your car. • Never leave raincover on indoors, in a hot atmosphere or near a heat source as your child could overheat.
-
Page 5: Part List
Visual Language Key Refer to warning XX Lock Correct action Unlock Incorrect action Press and hold Audible sound Check Repeat action x times Continue to step XX General action arrow Repeat on other side Part List (Car Seat) (Car Seat Base) 1. -
Page 8: Replacement Parts
For customer outside UK & Ireland, contact information for your local distributor can be found on http://www.cosatto.com/stockists If you require any further assistance, please contact us at cuddle@cosatto.com Headrest Cover (inc. Shoulder pad) Harness (inc. -
Page 9: Care And Maintenance
Care & Maintenance Store your child restraint system in a dry, safe place. Storing a damp child car seat base will encourage mildew to form, so after exposure to damp conditions, dry off with a soft cloth and allow to dry thoroughly before storing. Avoid leaving the child restraint system in sunlight for prolonged periods as this may cause fabrics to fade. - Page 10 IMPORTANT: The position of the vehicle belt buckle can affect the stability of the child restraint system. In an accident this could stop the child restraint system from protecting your child as well as it should. After tightening the vehicle belt, if the buckle lies in the position marked ( ) then try fitting the child restraint system in another seating position in your vehicle.
- Page 11 Satisfactory chest pad location. Child Car Seat Liner As the child grows bigger, the padding and the liner can be removed 17 18 Handle To adjust the handle position, hold both handle adjustment button and adjust handle position Handle positions: In car position Carrying position Stow position...
- Page 12 Seat liner & headrest cover removal: Open the buckle Route the shoulder straps through shoulder pads , then push the crotch strap retainer clip through from the underside of the child car seat Remove the seat liner from the seat Unfasten the headrest cover from around the headrest Seat cover removal: It is recommend to open the hood slightly to allow access to the rear fabric...
- Page 13 Fitting Preparation: Before fitting, Open the ISOFIX foot Hold the ISOFIX adjustment button and push the child car seat base away from ISOFIX leg as far as possible Fitting: To fit the child car seat base, position the base over the vehicle seat Release &...
- Page 14 Engage the car seat to the base and ensure that the child car seat security indicator is green WARNING: Do not use the child car seat when the child car seat connection indicator is showing red. Adjust the handle to “in car position” 11 12 Route the diagonal belt through the rear vehicle belt guide &...
- Page 15 Press the ISOFIX adjustment button to release the child car seat base and push the child car seat base towards the back of the vehicle seat as far as possible Hold the ISOFIX leg adjustment button and adjust ISOFIX leg ISOFIX leg MUST make full contact with the floor Fitting Child Car Seat to Car Seat Base Place child car seat on base...
- Page 43 Vehicle Fitting List for ISOFIX Anchorage Point Fitting * Positions: The Wonder Car Seat Base is only suitable if a floor storage support, approved by the vehicle manufacturer, is positioned in the floor storage compartment. Never use the child car seat on a seat where an airbag is fitted and active.
- Page 44 Alfa Romeo 2000 1997 2006 Giulietta 2010 Mito 2008 Audi 2010 2000 A3, S3 1997 A3, S3 2003 A3 sportback 2003 A3 cabrio 2008 A4, S4, RS4 1998 1,2,4 A4 avant 1996 A4, S4, RS4 2000 1,2,4 A4 avant 2000 1,2,4 A4 cabrio 2002...
- Page 45 Car manufacturer Model Year Approved seats BMW (cont’d) 7 serie 2001 7 serie 2015 2013 Mini 2006 Mini Clubman 2007 Mini Clubman 2015 1,2,4 Mini Countryman 2010 2004 2015 2004 2004 2013 2008 2015 Chrevolet Aveo 2006 Captiva 2006 Cruze 2009 Epica 2006...
- Page 46 Citroën Berlingo 2008 1,2*,4* Berlingo Multispace 2012 2*,4* 2005 2014 2004 2004 C3 Picasso 2013 2004 C4 Aircross 2012 C4 Cactus 2014 C4 Picasso 2007 1,2*,3,4* C4 Picasso 2013 2,3,4 C4 Grande Picasso 2007 1,2*,3,4* C4 Grande Picasso 2013 2,3,4 2000 1,2,4 2008...
- Page 47 Fiat (cont’d) Doblò 2010 Fiorno / Qubo 2008 Freemont 2011 Grande Punto 2006 Idea 2003 Linea 2007 Multipla 2004 Panda 2007 Punto 2008 Scudo 2007 Sedici 2009 Stilo 2004 Ulysse 2003 Ford B-max 2012 2*,4* C-max 2003 2*,4* Ecosport 2014 Fiesta 2008 Focus...
- Page 48 Honda (cont’d) CR-V 2012 2,3,4 CR-Z 2010 FR-V 2005 Insight 2009 Jazz 2002 Legend 2006 Stream 2001 Hyundai Accent 2002 Coupe 2001 Elantra 2002 Getz 2002 H1/iMax/i800/H300 2008 2008 2009 2014 2007 2011 iX20 2010 iX35 2010 iX55 2009 Matrix 2002 Santa Fe 2002...
- Page 49 Kia (cont’d) Cee’d 2007 Cerato/Spectra 2004 Magentis/Optima 2002 Opirus/Amanti 2003 Picanto/Morning 2004 Rio/Pride 2002 Sorento XM 2002 Sorento UM 2014 Sportage 2010 Soul AM 2009 Soul PS 2014 Soul EV 2014 Venga 2009 Lancia Delta 2008 Musa 2004 Phedra 2002 Thema 2011 Ypsilon...
- Page 50 Mazda (cont’d) 2004 2003 2013 CX-3 2015 CX-5 2011 CX-7 2007 CX-9 2009 Premacy 1999 Mercedes A class W 168 2001 A class W/C 169 2005 A class W 176 2012 B class T 245 2005 B class W 246 2011 C class C 205 2015...
- Page 51 Mercedes (cont’d) S class W/V 221 2005 Vaneo W 414 2003 Viano W 639 2003 Vito W 639 2004 Mitsubishi 2010 Colt 2002 Grandis 2004 i-MiEV 2009 Lancer 2003 L200 2006 L200 D/cab (KK0T/KL0T) 2015 Mirage / Space star 2013 Outlander 2003 Outlander PHEV...
- Page 52 Opel/Vauxhall (cont’d) Astra 2000 Combo 2001 Corsa 2000 Insignia 2008 Karl / Viva 2015 Meriva 2003 Mokka 2012 Signum 2003 Vectra 2002 Vivaro 2001 Zafira 2003 Zafira Tourer 2013 Peugeot 2005 2014 1998 2006 2012 2012 2001 2007 1,2,4 2013 308 SW 2014 2004 2011...
- Page 53 Qoros Qoros 3 2013 Renault Avantime 2001 Captur 2013 1,2,4 Clio II 1998 Clio III 2005 Clio IV 2012 Clio Grandtour 2009 Espace III 1997 Espace IV 2002 2,3,4 Espace V 2014 2,3,4 Fluence 2010 Kadjar 2015 Kangoo I 1999 Kangoo II 2008 2*,4*...
- Page 54 Saab 9-Mar 2005 40671 2005 Seat Alhambra 1998 2,3,4 Altea 2004 Arosa 1998 Cordoba (Vario) 1999 Exeo 2009 Ibiza 2004 Leon 1999 2011 Toledo 1999 Skoda Citigo 2011 Fabia 2000 Fabia 2014 Octavia 2004 Octavia 2012 1,2,4 Rapid 2012 Roomster 2006 Roomster 2015...
- Page 55 Suzuki (cont’d) Splash 2007 Swift 2004 2006 SX4 S-Cross 2013 Vitara 2015 Wagon R+ 2002 Inica Vista 2008 Model S 2013 2,3,4 Model S 2014 Auris 2007 Auris 2013 Avensis (Verso) 2001 2*,4* Avensis Sedan 2015 Avensis Touring Sports 2015 Aygo 2005 Aygo...
- Page 56 Volkswagen (cont’d) Golf VI 2008 Golf VII 2012 Golf Sportsvan 2014 Jetta 2006 Lupo 1998 Passat 1998 Passat B8 Saloon 2014 Passat B8 Estate 2014 Phaeton 2002 Polo 1999 Scirocco 2008 Sharan 1998 2,3,4 T4 Multivan/Caravelle 1999 T5 Multivan/Caravelle 2003 Tiguan 2007 Touareg...
- Page 57 * Calls from BT landlines are free but calls from mobiles and other networks may vary. All the design and trademarks contained herein are the property of Cosatto Limited. No part of this document may be reproduced without the permission of Cosatto Limited.
