- Page 1 LED TV Installation manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register Model Serial No. [HG470_HOTEL-ZA]ENG.indd 1 2012-03-28 6:06:43...
-
Page 2: Introduction
ONLINE mode which gives full control of the TV to the SBB/STB. When the TV is in ONLINE mode, it stops accepting IR (Samsung remote) commands and acts according to the interface protocol. Stand-Alone: If you are not using an SBB/STB and the TV cannot or does not identify an SBB/STB, you should switch the TV to STAND-ALONE mode with restricted operation. -
Page 3: Table Of Contents
Contents y Introduction ................................2 y Operational Modes ..............................2 y Still image warning ..............................2 y Securing the Installation Space ..........................2 y Additional Information ............................... 2 y Accessories ................................4 y Installing the LED TV Stand ............................4 y Viewing the Control Panel ............................ -
Page 4: Accessories
Accessories ✎ Please make sure the following items are included with your LED TV. If any items are missing, contact your dealer. ✎ The items’ color and shape may vary, depending on the model. ✎ The parts for the stand are listed under Stand Components on the following page. y Remote Control (AA59-00628A) &... -
Page 5: Viewing The Control Panel
Viewing the Control Panel ✎ The product color and shape may vary depending on the model. Control Panel Remote control sensor Aim the remote control towards this spot on the TV. Power Indicator Blinks and turns off when the power is on and lights up in standby mode. SOURCEE Toggles between all the available input sources. -
Page 6: The Connection Panel
The Connection Panel R - AUDIO - L ✎ Whenever you connect an external device to your TV, make sure that power on the TV and the device is turned off. ✎ When connecting an external device, match the color of the connection terminal to the cable. USB / CLONING –... - Page 7 COMPONENT IN / AV IN Component In , and Y) – Connects to the Component video / audio out of a device with Component output jacks. – Connect Component video cables (sold separately) to the Component jacks ("P ", "P ", "Y") on the rear of your TV and the other ends to corresponding Component video out jacks on a DVD player.
-
Page 8: The Remote Control
The Remote Control ✎ This remote control has Braille points on the Power, Channel, and Volume buttons and can be used by visually impaired customers. Display and select the available video Turns the TV on and off. sources. HDMI Selects the HDMI mode directly. Press to directly access channels. -
Page 9: Connecting The Tv To An Sbb Or Stb
Connecting the TV to an SBB or STB TV Rear Panel ETH MODEM Data Cable R - AUDIO - L R - AUDIO - L 1. Connect the DATA jack of the TV to the ETH MODEM jack of the STB (SBB) with the Data cable. ✎... - Page 10 List of Vendors and Compatible Data Cables Supplied with the TV ¦ y Confirm you are using the correct data cable for your vendor. Refer to the code label on the data cables. Confirm the code on the Code Label Note the labeled end.
-
Page 11: Connecting The Rjp (Remote Jack Pack)
TV to the HDMI port of the RJP. 4. Connect the EX-LINK port of the TV to the RS/232 port of the RJP. ✎ The RJP (Remote Jack Pack) compatible with this Samsung TV is the TeleAdapt TA-7610. English [HG470_HOTEL-ZA]ENG.indd 11 2012-03-28 6:06:54... - Page 12 y RJP (Remote Jack Pack): RJP stands for Remote Jack Pack. The RJP is a hardware module that has different Audio Video inputs (A/V, Audio, PC and HDMI) and corresponding outputs. The corresponding outputs are connected from the RJP to the TV. The RJP communicates with the TV via RS232. A Hot Plug & Play function allows hotel guests to connect an external source to the RJP.
-
Page 13: Setting The Hotel Option Data
1. Highlight the Hospitality Mode menu item in the top left corner of the menu. 2. Press the left or right arrow button on the Samsung remote. Only the Hospitality Mode menu item is displayed. 3. Press the left or right arrow button to change the Hospitality Mode item from Standalone to Interactive or from Interactive to Standalone. -
Page 14: Menu Items
SI Vendor Samsung SI Vendor y Samsung / OCC / MTI / Nstreams / NXTV / Enseo / Cardinal /Guestek / SeaChange / EBL Set the default values, which will be applied when the TV is turned on. Power On... - Page 15 Menu Item initial Value Description Front panel (Local key) operation on/off. y Unlock : Unlock all panel keys Panel Button Operation Unlock y Lock : Lock all panel keys Lock y Power : Lock all panel buttons except Power y Menu/Source : Lock Menu and Source Select the way to update clock data.
- Page 16 Logo/ Logo turn on for the amount of time set in the "Logo Display Time" Message Hospitality Logo Download. (File name required: samsung.bmp/avi, Hospitality Logo DL Max file size: BMP 960 x 540 / AVI 30MB, File Type: BMP/AVI) Logo Display Hospitality Logo Display Time (3/5/7 seconds).
- Page 17 Menu Item initial Value Description SIRCH update will be executed according to the selected time. SIRCH 1hour update Time y OFF / 1hour / 2hour / 12:00 am / 2:00 am / 12:00 pm / 2:00 pm y On : Whenever the TV goes to Stand-By mode, always runs a SIRCH SIRCH Update.
- Page 18 Welcome Message ¦ The Welcome Message feature displays a custom message on the TV every time it is turned on. – Welcome message settings are in the Hotel Option Menu. – Set Welcome Message to ON to display the message when the TV is powered on. Welcome Message Edit Welcome Message Hospitality Logo...
- Page 19 Logo File Format – The TV supports only the BMP and AVI format. – The file name must be samsung.bmp or samsung.avi. – The maximum resolution of the BMP format is 960 x 540. – The maximum file size of AVI format is 30MB.
- Page 20 USB Cloning ¦ The USB Cloning function lets you download user configured settings (Picture, Sound, Input, Channel, Setup, and Hotel Setup) from one TV to a USB device, and then upload these settings from the USB device to other TV sets. This lets you create a standard array of settings and distribute that standard array to all the TVs in your facility.
- Page 21 y Settings Cloned in the Hotel Menu Menu Item Cloning Support Applicable Region Hospitality Mode SI Vendor All except Brazil Power On Channel EN Power On Channel Channel Type Power On Volume EN Power On Volume Min Volume Max Volume Power On Source Power On Option Channel Setup...
- Page 22 Menu Item Cloning Support Applicable Region RJP HDMI Option HDMI Music Mode US and US Hsopital Sound Bar Out ASIA Models only Video Out USB Media Mode US and EU External Source Banner Auto Source Anynet+ Return Source All Models except Hospital Sub Amp Mode All except US Sub Amp Volume...
- Page 23 Multi Code Remocon ¦ A Multi Code Remocon is a special remote which is designed to control multiple TVs. This function is useful where there is more than one TV in a location. You can control up to 10 TVs, each with a different ID code, with one remote. ID numbers are displayed on each TV's OSD. The Initial ID code for each TV is “0”.
- Page 24 Setting Auto Initialize ¦ When you clone settings from one TV to another, you clone both guest side menu and hotel side menu settings (Picture, Sound, Input, Channel, Setup, and Hotel Setup). This lets you set nearly all the menu values on your hospitality TVs to the same, standard settings.
- Page 25 Hotel Plug & Play ¦ Hotel Plug & Play function automatically performs the Hotel mode selection, Country Setup, Clock Setup, and Picture mode Setup runs once, when power is first turned ON. Setup also runs automatically after you have executed a Service Reset. y UI Scenario If you select the Factory Reset, the TV resets all values to their factory defaults Fastory Reset...
- Page 26 – If you select Standalone from the “Select Hotel TV Mode” OSD, the “Select Menu Language” OSD appears. – Initial Highlight : English – Display time: OSD timeout and operation are the same as Samsung's consumer TV models. – If you press the Enter key, the “Select Country” OSD appears y Clock Mode OSD –...
- Page 27 ¦ Samsung may offer upgrades to the TV’s SW in the future. Please contact the Samsung Hospitality Hotline at 1-866-894-0524 to receive information about downloading upgrades and using a USB drive to update the SW by connecting the USB drive containing the upgrade to the USB port located on the TV.
-
Page 28: Installing The Wall Mount
Do not fasten the screws too firmly. This may damage the product or cause the product to fall, leading to personal injury. Samsung is not liable for these kinds of accidents. Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or the consumer fails to follow the product installation instructions. -
Page 29: Anti-Theft Kensington Lock
Refer to the manual provided with the Kensington Lock for additional information on proper use. The Kensington Lock is not supplied by Samsung. ✎ Please find a “K” icon on the rear of the TV. A Kensington slot is beside <Optional>... -
Page 30: Specifications
50°F to 104°F(10°C to 40°C) Operating Humidity 10% to 80%, non-condensing Storage Temperature -4°F to 113°F(-20°C to 45°C) Storage Humidity 5% to 95%, non-condensing Model Name HG22NA470 Display Resolution 1920 x 1080 Screen Size 22" Class (Diagonal) (22.0" measured diagonally) Sound... -
Page 31: Dimensions
Dimensions ▪ Front view / Side view (Unit: inches) 20.3 18.7 10.5 12.4 13.7 ▪ Jack panel detail / Rear view R - AUDIO - L R - AUDIO - L (Unit: inches) 10.5 English [HG470_HOTEL-ZA]ENG.indd 31 2012-03-28 6:07:06... - Page 32 NOTE: All drawings are not necessarily to scale. Some dimensions are subject to change without prior notice. Refer to the dimensions prior to performing installation of your TV. Not responsible for typographical or printed errors. © 2012 Samsung Electronics America, Inc English [HG470_HOTEL-ZA]ENG.indd 32...
- Page 33 SAMSUNG will additionally provide Warranty Repair Service in the United States on SAMSUNG products purchased in Canada, and in Canada on SAMSUNG products purchased in the United States, for the warranty period originally specified, and to the Original Purchaser only.
- Page 34 This page is intentionally left blank. [HG470_HOTEL-ZA]ENG.indd 34 2012-03-28 6:07:07...
- Page 35 Contact SAMSUNG WORLDWIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Samsung Hospitality Hotline: 866-894-0524 Web site: http://www.samsung.com/us/business [HG470_HOTEL-ZA]ENG.indd 35 2012-03-28 6:07:07...
