Summary of Contents for Acer H7531D Series
- Page 1 Acer Projector H7531D Series User's Guide Downloaded From projector-manual.com Acer Manuals...
- Page 2 Serial number: ___________________________________ Date of purchase: ________________________________ Place of purchase: ________________________________ Acer and the Acer logo are registered trademarks of Acer Incorporated. Other companies' product names or trademarks are used herein for identification purposes only and belong to their respective companies.
- Page 3 Never push objects of any kind into this product through cabinet slots as • they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind onto or into the product. Downloaded From projector-manual.com Acer Manuals...
- Page 4 Use the product only with the supplied power supply cord set. If you need • to replace the power cord set, make sure that the new power cord meets the following requirements: detachable type, UL listed/CSA certified, VDE approved or its equivalent, 4.6 meters (15 feet) maximum length. Downloaded From projector-manual.com Acer Manuals...
- Page 5 Unplug immediately if there is something wrong with your projector. Do • not operate if smoke, strange noise or odor comes out of your projector. It might cause fire or electric shock. In this case, unplug immediately and Downloaded From projector-manual.com Acer Manuals...
- Page 6 This product is capable of displaying inverted images for ceiling mount • installation. Only use acer ceiling mount kit for mounting the projector and ensure it is securely installed. Downloaded From projector-manual.com Acer Manuals...
- Page 7 Do not throw this electronic device into the trash when discarding. To minimize pollution and ensure utmost protection of the global environment, please recycle. For more information on the Waste from Electrical and Electronics Equipment (WEEE) regulations, visit http://www.acer-group.com/public/ Sustainability/sustainability01.htm Mercury advisory For projectors or electronic products containing an LCD/CRT monitor or display: “Lamp(s) contain Mercury,...
-
Page 8: Precautions
When the lamp reaches the end of its life, it will burn out and may make a loud popping sound. If this happens, the projector will not turn back on until the lamp module has been replaced. To replace the lamp, follow the procedures listed under "Replacing the Lamp". Downloaded From projector-manual.com Acer Manuals... -
Page 9: Table Of Contents
How to optimize image size and distance How to get a preferred image size by adjusting distance and zoom User Controls Installation menu Acer Empowering Technology Onscreen Display (OSD) Menus Color Image Management Setting Audio Timer Language Appendices Downloaded From projector-manual.com Acer Manuals... - Page 10 Troubleshooting LED & Alarm Definition Listing Replacing the Lamp Ceiling Mount Installation Specifications Compatibility modes Regulations and safety notices Downloaded From projector-manual.com Acer Manuals...
-
Page 11: Introduction
• Native 1920 x 1080 1080p resolution 4:3 / 16:9 / L.Box aspect ratio supported • Acer ColorBoost technology delivers nature’s true colors for vivid, life-like images • High brightness and contrast ratio • Versatile display modes (Bright, Presentation, Standard, Movie, Dark Cinema, Game, Sports, User) enable optimum performance in any situation •... -
Page 12: Package Overview
User's Guide POWER FREEZE HIDE Acer Projector ASPECT RESYNC SOURCE RATIO ZOOM BRIGHTNESS COLOR CONTRAST PgUp PgDn COMPONENT VIDEO S-VIDEO Quick Start Guide HDMI WIRELESS MUTE Remote control Quick start guide 2 x Batteries Carrying case Downloaded From projector-manual.com Acer Manuals... -
Page 13: Projector Overview
USB connector HDMI 2 connector YPbPr/YCbCr input connector Audio input connector Composite video input connector RS232 connector S-Video input connector 12V DC output connector PC analog signal/HDTV/component Kensington™ lock port video input connector (VGA IN) Downloaded From projector-manual.com Acer Manuals... -
Page 14: Control Panel
Use to select items or make adjustments to your selection. TEMP Temp Indicator LED. Empowering key Unique Acer functions: eView, eTimer, ePower Management. Note: When PIP function is activated, zoom and keystone function is unavailable. Downloaded From projector-manual.com Acer Manuals... -
Page 15: Remote Control Layout
To choose the desired aspect ratio (Auto/4:3/16:9/L.Box) ZOOM Zooms the projector display in or out. Empowering key Unique Acer functions: eView, eTimer, ePower Management. KEYSTONE Adjusts the image to compensate for distortion caused by tilting the projector (± 15 degrees). - Page 16 Press "0~9" to input a password in the "Security settings". Four directional Use up, down, left, right buttons to select items or make select keys adjustments to your selection. Note: When PIP function is activated, zoom and keystone function is unavailable. Downloaded From projector-manual.com Acer Manuals...
-
Page 17: Getting Started
10 Audio cable Jack/RCA Audio cable jack/jack 11 12V DC Cable RS232 cable Note: To ensure the projector works well with your computer, please make sure the timing of the display mode is compatible with the projector. Downloaded From projector-manual.com Acer Manuals... -
Page 18: Turning The Projector On/Off
If you connect to multiple sources at the same time, use the "Source" button on either control panel or the remote control or direct source key on the remote control to switch between inputs. POWER FREEZE HIDE Power button ASPECT RESYNC SOURCE RATIO Lens cap Downloaded From projector-manual.com Acer Manuals... -
Page 19: Turning The Projector Off
LED temp indicator will blink. Contact your local dealer or service center. Note: Whenever the projector automatically shuts down and the LED lamp indicator turns solid red, contact your local reseller or service center. Downloaded From projector-manual.com Acer Manuals... -
Page 20: Adjusting The Projected Image
Lower the image to the desired height angle (Illustration #2) , then release the button to lock the elevator foot into position. Use Tilt adjusting wheel (Illustration #3) to fine-tune the display angle. Elevator foot release button Tilt adjusting wheel Elevator foot Tilt adjusting wheel Downloaded From projector-manual.com Acer Manuals... -
Page 21: How To Optimize Image Size And Distance
Note: Remind as below figure, the space of 130 cm height is required when located at 3m distance. Height: 130cm Form base to top of image Height: 107cm 3m Desired Distance Figure: Fixed distance with different zoom and screen size. Downloaded From projector-manual.com Acer Manuals... - Page 22 331 x 186 328 x 184 397 x 224 383 x 215 464 x 261 437 x 246 530 x 298 492 x 277 596 x 335 546 x 3 07 662 x373 Zoom Ratio: 1.2x Downloaded From projector-manual.com Acer Manuals...
-
Page 23: How To Get A Preferred Image Size By Adjusting Distance And Zoom
For example: to obtain an image size of 60" set the projector at a distance 2.0 m and 2.4 m from the screen and adjust the zoom level accordingly. Downloaded From projector-manual.com Acer Manuals... - Page 24 133 x 75 155 x 87 177 x 100 199 x 112 221 x 125 266 x 149 332 x 187 398 x 224 443 x 249 553x 311 10.1 664 x 374 10.0 Zoom Ratio: 1.2x Downloaded From projector-manual.com Acer Manuals...
-
Page 25: User Controls
The new settings will be saved automatically upon exiting the menu. Push the menu button anytime to exit the menu and return to the Acer welcome screen. Downloaded From projector-manual.com Acer Manuals... -
Page 26: Acer Empowering Technology
Acer Empowering Technology Acer Empowering Key provide three Empowering Acer unique functions, they are "Acer eView Management", "Acer eTimer Management" and "Acer ePower Management" respectively. Press " " key for more than one second to launch the Onscreen display main menu to modify its function. -
Page 27: Onscreen Display (Osd) Menus
• To exit OSD, press "MENU" on the remote control or control panel again. The OSD menu will close and the projector will automatically save the new settings. Main menu Setting Sub menu Downloaded From projector-manual.com Acer Manuals... -
Page 28: Color
Adjust the color temperature. At higher color temperatures, the screen looks colder; at lower color temperatures, the screen looks Temperature warmer. Degamma Effects the representation of dark scenery. With greater gamma value, dark scenery will look brighter. Downloaded From projector-manual.com Acer Manuals... -
Page 29: Color Management
Full Range: Prosess the input image as full color range data. Note: "Saturation" and "Tint" functions are not supported under computer mode or HDMI mode. Note: "HDMI Color Range" function is only supported under DVI mode. Downloaded From projector-manual.com Acer Manuals... -
Page 30: Image
L. Box: Keep original signal aspect ratio and zoom in by 1.333 times. Auto Keystone Automatically adjusts vertical image. Keystone Adjust image distortion caused by tilting projection. (±15 degrees) <Note> The Manual Keystone funcion is unavailable under Auto Keystone setting to "On". Downloaded From projector-manual.com Acer Manuals... - Page 31 Auto: Automatically adjust by information from player. • Underscan: Always no overscan on HDMI image. • Overscan: Always keep overscan on HDMI image. Note: "H. Position", "V. Position", "Frequency" and "Tracking" functions are not supported under HDMI or Video mode. Downloaded From projector-manual.com Acer Manuals...
-
Page 32: Management
S-Video input signal is selected and its system format is NTSC. <Note> Set your screen aspect ratio to 4:3. This function is not available when the aspect ratio is "16:9" or "Auto" . Downloaded From projector-manual.com Acer Manuals... - Page 33 PC resolution to 1024 x 768 before you use this function. Note: For SVGA models, to get best quality for you desired image, suggest end-user set PC resolution to 800 x 600 before you use this function. Downloaded From projector-manual.com Acer Manuals...
- Page 34 PIP Location Choose the PIP secondary signal location on the display screen. PIP Size Choose the PIP secondary signal size on the display screen. Note: When PIP function is activated, zoom and keystone function is unavailable. Downloaded From projector-manual.com Acer Manuals...
-
Page 35: Audio
• Timer Volume Select this function to adjust the notification volume when the timer function is enabled and time is up. Timer Display • Press to which timer mode to display on the screen. Downloaded From projector-manual.com Acer Manuals... -
Page 36: Language
Language Language Choose the multilingual OSD menu. Use the to select your preferred menu language. • Press to confirm the selection. Downloaded From projector-manual.com Acer Manuals... -
Page 37: Appendices
Appendices Troubleshooting If you experience a problem with your Acer projector, refer to the following troubleshooting guide. If the problem persists, please contact your local reseller or service center. Image Problems and Solutions Problem Solution No image appears • Connected as described in the "Getting Started"... - Page 38 4:3 in the projector OSD. • If the image is still stretched, you will also need to adjust the aspect ratio. Set up the display format to 16:9 (wide) aspect ratio on your DVD player. Downloaded From projector-manual.com Acer Manuals...
-
Page 39: Problems With The Projector
If this happens, the projector will not turn on until the lamp module has been replaced. To replace the lamp, follow the procedures in the "Replacing the Lamp" section. Downloaded From projector-manual.com Acer Manuals... -
Page 40: Osd Messages
Projector Overheated - the projector has exceeded its recommended operating temperature and must be allowed to cool down before it may be used. Replace the lamp - the lamp is about to reach its maximum lifetime. Prepare to replace it soon. Downloaded From projector-manual.com Acer Manuals... -
Page 41: Led & Alarm Definition Listing
Power button ON Lamp retry Quick flashing Turning off Quick flashing (cooling state) Turning off (cooling completed) Error (thermal failure) Error (fan lock failure) Quick flashing Error (lamp breakdown) Error (color Wheel fail) Quick flashing Downloaded From projector-manual.com Acer Manuals... -
Page 42: Replacing The Lamp
To replace the lamp module, reverse the previous step. Warning: To reduce the risk of personal injury, do not drop the lamp module or touch the lamp bulb. The bulb may shatter and cause injury if it is dropped. Downloaded From projector-manual.com Acer Manuals... -
Page 43: Ceiling Mount Installation
Ceiling Mount Base - Attach to ceiling Short Rod Long Rod Extension Rod Long Cylinder Cap Allen Key Screw Type A - For tightening/loosening 50 mm length / 8 mm diameter - Tightening Screw Medium Rod Downloaded From projector-manual.com Acer Manuals... - Page 44 Use two washers for extra support, if deemed necessary. Attach the ceiling bracket to the ceiling rod. Large cylinder cap Allen Key - For tightening/loosening Screw Type A Tightening Screw 50 mm length - 8 mm diameter Downloaded From projector-manual.com Acer Manuals...
- Page 45 3 mm diameter screws are enclosed in the screw pack. Models Screw Type B Washer Type Diameter (mm) Length (mm) Large Small H7531D SCREW SPEC. M3 x 25 mm 150.00 mm Downloaded From projector-manual.com Acer Manuals...
-
Page 46: Specifications
Specifications The specifications listed below are subject to change without notice. For final specs, please refer to Acer's published marketing specifications. Projection system ® Resolution Native: 1080P (1920 x 1080), Maximum: UXGA (1600 x 1200), WSXGA+ (1680x1050) Computer compatibility IBM PC and compatibles, Apple Macintosh, iMac and... - Page 47 Remote control x1 • Batteries x2 (for remote control) • User's Guide (CD-ROM) x1 • Quick start guide x1 • Security card x1 • Carrying case x1 * Design and specifications are subject to change without notice. Downloaded From projector-manual.com Acer Manuals...
-
Page 48: Compatibility Modes
1400x1050 65.3 UXGA 1600x1200 75.00 PowerBook G4 640x480 31.5 PowerBook G4 640x480 66.6(67) 34.9 PowerBook G4 800x600 37.9 PowerBook G4 1024x768 48.4 PowerBook G4 1152x870 68.7 PowerBook G4 1280x960 75.2 i Mac DV(G3) 1024x768 60.3 Downloaded From projector-manual.com Acer Manuals... - Page 49 1080p 1920x1080 56.3 B. HDMI Digital HDMI - PC Signal Modes Resolution V.Frequency [Hz] H.Frequency [KHz] 640x480 31.5 640x480 37.9 640x480 37.5 640x480 43.3 SVGA 800x600 35.1 800x600 37.9 800x600 48.1 800x600 46.9 800x600 53.7 Downloaded From projector-manual.com Acer Manuals...
- Page 50 Mac DV(G3) 1024x768 60.3 HDMI - Extended Wide timing Modes Resolution V.Frequency [Hz] H.Frequency [KHz] WXGA 1280x768 47.8 1280x768 60.3 1280x768 68.6 1280x720 44.8 1280x800 49.6 1440x900 55.9 WSXGA+ 1680x1050 65.3 1366x768 47.7 1920x1080 67.50 Downloaded From projector-manual.com Acer Manuals...
- Page 51 37.5 1080i 1920x1080 60(30) 33.8 1080i 1920x1080 50(25) 28.1 1080p 1920x1080 23.97/24 1080p 1920x1080 67.5 1080p 1920x1080 56.3 Horizontal scan Graphic source 30k-100kHz rate: monitor range limits Vertical scan rate: 50-85Hz Max. pixel rate 170MHz Downloaded From projector-manual.com Acer Manuals...
-
Page 52: Regulations And Safety Notices
(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Notice: Canadian users This Class B digital apparatus complies with Canadian ICES-003. Downloaded From projector-manual.com Acer Manuals... -
Page 53: Declaration Of Conformity For Eu Countries
Cet appareil numérique de la classe B est conforme a la norme NMB-003 du Canada. Declaration of Conformity for EU countries Acer hereby declares that this projector series is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Compliant with Russian regulatory certification... -
Page 54: Declaration Of Conformity
Taipei Hsien 221, Taiwan Declaration of Conformity Acer Incorporated 8F, 88, Sec. 1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan Contact Person: Mr. Easy Lai, e-mail:easy_lai@acer.com.tw And, Acer Europe SA Via Cantonale, Centro Galleria 2 6928 Manno Switzerland... - Page 55 Article 3.2 Spectrum Usages -. EN300 328 -. EN301 893 (Applicable to 5GHz high performance RLAN). Year to begin affixing CE marking 2010. Aug. 1, 2010 _______________________________ Easy Lai /Manager Date Regulation Center, Acer Inc. Downloaded From projector-manual.com Acer Manuals...
- Page 56 H7531D series Name of Responsible Party: Acer America Corporation Address of Responsible Party: 333 West San Carlos St. San Jose, CA 95110 U. S. A. Contact Person: Acer Representative Phone No.: 254-298-4000 Fax No.: 254-298-4147 Downloaded From projector-manual.com Acer Manuals...
