S e tu p
The UnitiLite MAC address is shown in the 'Factory settings
> System Status' page.
Note: The wireless passphrase/access key is created when
the wireless router is first set up and could be a word or a
series of numbers and letters. If the passphrase/access key
is not known, check on the router settings page or with the
person who initially set up the router.
Note:
If a router offers multiple security configurations,
UnitiLite will automatically offer only the most secure one.
Note:
If WEP security is used the router should be set to
"auto" or "open" authentication.
If the selected network is insecure
and requires no passphrase
or access key to join, UnitiLite
will display an alert message.
Pressing the handset ok/list
will immediately connect UnitiLite
to the network and display a
confirmation screen.
Note: Wireless connection difficulties can sometimes
be resolved by changing the wireless connection
channel in the router settings.
4.6.2 Non-DHCP (Static) Network
Connection
If DHCP is de-selected in the
Network Settings menu, five
further parameters will be
displayed.
Parameter Options
IP: User definable (numerical entry)
Default: 0.0.0.0
Mask:
User definable (numerical entry)
Default: 0.0.0.0
Gateway (Gtwy): User definable (numerical entry)
Default: 0.0.0.0
DNS1:
User definable (numerical entry)
Default: 0.0.0.0
DNS2: User definable (numerical entry)
Default: 0.0.0.0
These settings enable UnitiLite to connect to a network
using a fixed IP address. On selecting each one in turn,
numerical entry screens will be displayed that require
completion with the appropriate network IP address
settings. Consult your network router's user documentation
for help with specifying fixed IP address settings.

4.7 The Front Display Menu

The Front Display setup menu
enables the behaviour of the
UnitiLite front panel display to
be modified. The options are
tabulated and described in the
following section:
This wireless network is
insecure and requires no
passphrase or access key.
Press OK To Connect
key
Network Settings
192.168.0.80
4IP:
Mask: 255.255.255.0
Gtwy: 192.168.0.1
DNS1: 192.168.0.1
Front Display
4Off During Mute:
Auto Off: 2 mins
Clock When Off:
Parameter
Off During Mute:
Auto Off:
Clock When Off:
When Off During Mute
will switch off when mute is engaged.
length of time the display will remain switched on after
the last interface operation is carried out. Time periods of
between 10 seconds and 1 hour can be selected.
Note: If the display has been switched off using the
handset disp key this setting will take priority over the Auto
Off setting. The display will always switch on briefly when
control commands are received.
The Clock When Off
displayed when other display settings are switched off.
4 .8 The Cl ock a n d Ala r m Menu
The Clock & Alarm setup menu
enables the UnitiLite clock to be
set and alarms to be configured.
Selecting Set Weekday Alarm
or Set Weekend Alarm
menu that offers the following
1/5
parameters and options:
Parameter
Enabled:
Alarm Time:
Input:
Note: The UnitiLite radio can only be used as an alarm
signal using stored radio presets.
Volume:
Weekday alarms operate on Mondays to Fridays. Weekend
alarms operate on Saturdays and Sundays.
1/3
No
Yes
14
Options
Yes / No
Select time from list
Yes / No
is selected the front panel display
Auto Off
settings enables the clock to remain
Clock & Alarm
4Set Weekday Alarm
Set Weekend Alarm
Adjust Time Zone
Resync Time From Net
opens a
Options
Weekday Alarm
Yes / No.
4Enabled:
Yes
Selecting
Alarm Time:
primes the
Input:
alarm. Selecting
Volume:
No disables the
alarm.
07:00. Selecting the time opens a screen
that enables the alarm time to be set by
using the remote navigation (
4
) and numeric keys.
UnitiLite external inputs or radio presets
can be selected to become the alarm
audio source.
30. The alarm audio volume can be set
independently of the default UnitiLite
volume using the remote handset
and down ( 6 ) keys.
defines the
1/5
1/4
No
07:00
Fluid Radio
30
5 6 3
up ( 5 )
