S e tu p
Select Internal Only if no external amplifier is to be used.
The preamplifier output is disabled when Internal Only is
selected.
Select External if an external power amplifier is to be
used in place of the UnitiLite internal power amplifier. The
preamplifier output is enabled when External is selected.
Select All Outputs if an external power amplifier or
subwoofer is to be used in conjunction with the UnitiLite
internal power amplifier.
The speaker Max. Volume
maximum allowed volume, and the channel balance
respectively.
4. 5 The Headpho ne s M e nu
The Headphones setup menu
enables the Max. Volume
parameter to be specified:
Parameter Options
Max. Volume: 0 to 100 (adjust
using handset
or 5 keys)

4.6 The Network Settings Menu

The Network Settings menu
enables UnitiLite network
parameters to be customised
to suit the router and network.
The options are tabulated and
described in the following sections:
Parameter Options
Name:
User definable (text entry)
Default: Lite-xxxx
Wireless: Not Used / Wireless Network Names
Status: Connected / No Signal / Login Failure /
Busy / Etc.
DHCP: Yes / No
MAC: Displays the UnitiLite MAC address
Name
The parameter enables the UnitiLite's default
network name to be changed.
The Wireless parameter enables a wireless network to be
chosen and joined. See Section 4.6.1 below for detailed
wireless set up notes.
Network Status displays the current network connection
status.
DHCP
The parameter enables the UnitiLite network settings
to be modified. In most cases, specifying
UnitiLite set to DHCP, will be the appropriate option.
See Section 4.6.2 below for notes on non-DHCP network
connection.
Note: Devices installed on a network have an IP address
through which they are identified by all the other items
on the network. DHCP is a set of rules that enable the
and Balance parameters specify
Headphones
4Max. Volume:
6
Network Settings
Lite-0131
4Name:
Wireless: Not Used
Status: Not Connected
DHCP
Yes and leaving
automatic allocation of addresses as items are connected
(or switched on while connected) to the network. UnitiLite
is set up by default to use DHCP.
Note: If UnitiLite is connected to the network both wirelessly
and via Ethernet (wired), the Ethernet connection will take
priority.
4.6.1 Wireless Network
Connection Set Up
If the Wireless parameter is
selected in the Network Settings
menu the Select Network menu
will display a list of the available
networks. An option not to use a wireless connection is
also provided. Use the handset
to scroll through the list and the
network.
1/1
100
Note:
UnitiLite is compatible with most commonly used
Wi-Fi standards. Routers that support 802.11b and 802.11g
will work, however those with 802.11n compatibility are
recommended for best results.
Note: As with any wireless network hardware, UnitiLite
connection reliability will be affected by both network
router performance and Wi-Fi signal quality. To minimise the
possibility of poor connection reliability, UnitiLite should be
connected to network audio sources by no more than one
1/5
wireless "leg". Other "legs" necessary between UnitiLite and
the network audio sources should be wired.
Note: UnitiLite cannot connect to a "hidden" wireless
Yes
network.
If the selected network is secure
and requires a passphrase or
access key to join, UnitiLite will
display an alert message. Pressing
ok/list
the handset
open a text entry screen for entry
of the passphrase or access key.
Use the handset
keys to enter the passphrase or
access key taking care to ensure
that the letter case is correct.
Press the handset
when text entry is complete. In
the illustration the passphrase is
"flatfish".
If the network is successfully
joined UnitiLite will display a
confirmation screen.
If an incorrect passphrase or
access key is entered UnitiLite will
display an alert message.
Note: As a security measure,
a router may also require the
UnitiLite's MAC address to be
entered before allowing it to join the wireless network. This
type of security feature is known as 'MAC address filtering'.
13
Select Network
<Don't Use Wireless>
LingNet
4GreenNet
TomNet
up 5 down
( ) or
ok/list
key to select a
Now enter your wireless
passphrase or access key.
Press OK to continue
key will then
flatfish
numeric/text
flatfish
Press OK to confirm
ok/list key
Connected
Press OK To Finish
Can't Login
Press OK To Re-Try
3/6
6
( ) keys
abc
|
