- Page 1 Pressure Cooker Clipso Clipso Vitamin Clipso Control User’s manual Downloaded from www.Manualslib.com manuals search engine...
-
Page 2: Important Safeguards
In particular, never open the control panel. • Replace the lid seal once a year. • Use only the appropriate TEFAL spare parts for your model. • Do not use your pressure cooker to store acidic or salty food before or after cooking. •... -
Page 3: Table Of Contents
Clipso Control Pressure Cooker Descriptive diagram Control panel Congratulations on the purchase of your Smart timer Air release system new Clipso pressure cooker. Welcome to the world of Tefal cooking. Clipso/Clipso Vitamin Pressure Cooker Descriptive diagram Control panel Characteristics Opening - Closing... -
Page 4: Descriptive Diagram
Clipso Control Descriptive diagram Timer Locking button Programme selector Lid knob Unlocking button Control module Jaws Stainless steel lid Module retaining nut Lid seal Vitamin basket* Integrated basket supports* Pot handles Stainless steel pot * except on 3L models and 25cm diameter 4.5L models Downloaded from www.Manualslib.com... - Page 5 Clipso Control Control Panel Steam release outlet Programme selector Pressure indicator + air release system Timer Safety valve seal Safety valve Control module fixing axis Operating valve seal Operating valve Steam release outlet Pressure indicator and air release system The control module has been designed to make the cleaning of your pressure cooker easier.
-
Page 6: Clipso Control Smart Timer
Clipso Control Smart timer Your pressure cooker is equipped with a timer, which automatically starts to count down the pre-programmed cooking time as soon as the correct temperature has been reached for the programme selected. Instructions for use To turn the timer on, press either + or – button. - Page 7 Press either + or – button only once to stop the beeping. The timer turns itself off automatically. Note: your Clipso pressure cooker is designed to operate with or without the timer. To remove the timer: lift the timer carefully away from the module, making sure to hold it on both sides.
- Page 8 To remove the battery from your timer, unlock the cover of the battery chamber as shown on the diagram opposite (use a coin if necessary). You can get another timer from any TEFAL Approved Service Centre. Downloaded from www.Manualslib.com...
-
Page 9: Clipso Control Air Release System
Clipso Control Air release system A unique system, patented by TEFAL which allows you to: Optimise vitamin preservation in food. Steam cook faster than with a regular pressure cooker. How does it work? The pressure cooker heats up. As soon as the locking indicator pin has risen, the air release system begins. - Page 10 Programme selector Control module Unlocking button Jaws Stainless steel lid Module retaining nut Lid seal Vitamin basket* (for Clipso Vitamin & Clipso Control models) Steam basket* (for Clipso model) Integrated basket supports* Pot handles Stainless steel pot * except on 3L models and 25cm diameter 4.5L models Downloaded from www.Manualslib.com...
- Page 11 Tighten the retaining nut, using a coin if necessary. The control module will only fit on one way. *only on Clipso Vitamin & Clipso Control Downloaded from www.Manualslib.com manuals search engine...
-
Page 12: Characteristics
20 cm 4157 4169 4147 Clipso and Clipso Vitamin: maximum operating pressure: 85kPa/12.3 PSI. Clipso Control: maximum operating pressure: 90kPa/13.1 PSI. Clipso, Clipso Vitamin & Clipso Control: maximum safety pressure: 160kPa/23.2 PSI. Compatible heat sources SEALED CERAMIC HALOGEN INDUCTION ELECTRIC SOLID Stainless steel models are suitable for all hob types. - Page 13 Opening Whenever opening and closing the lid, the control module must always be fixed onto the lid. To open: press the unlocking button on the side of the lid knob; the jaws will release. Lift the lid off. Closing Place the lid over the pressure cooker, ensuring that it is sitting correctly on the pot.
- Page 14 If your pressure cooker has been heated without any liquid in it: Have it checked at any TEFAL Approved Service Centre. Downloaded from www.Manualslib.com manuals search engine...
-
Page 15: Using The Steam/Vitamin Basket
Using the Steam/Vitamin basket Food placed in the steam/vitamin basket must not touch the inside of the pressure cooker lid when closed. For steam cooking: You will have 1 or 2 steam baskets according to your model. Pour 750 ml of water into the pressure cooker. Place the steam basket onto the integrated basket supports. -
Page 16: Using The Programme Selector
To cook meat and fish fast: Turn the selector so that it is on To cook frozen food fast: Turn the selector so that it is on (Clipso Control model only) CLIPSO PRESSURE COOKER To cook vegetables: Turn the selector so that it is on... - Page 17 When no more steam escapes from the steam outlet and the pressure indicator is down, open the pressure cooker. For Clipso Control, make sure you now remove the timer from its holder. Rinse out the pressure cooker under water and dry it.
-
Page 18: Before Cooking
Close the lid. Set the programme selector to the position indicated in your recipe. If you have a Clipso Control, set the timer for the required cooking time. Put the pressure cooker on the heat source at the highest temperature. -
Page 19: During Cooking
As soon as the cooking time is up, turn off the heat source. If you have a Clipso Control, the timer will tell you when cooking time is up with a series of beeps. Turn off the heat source and press either the + or –... -
Page 20: End Of Cooking
End of cooking To release pressure After the heat has been turned off you have two alternatives: Slow pressure release: gradually turn the programme selector to the steam position This is used for stews, vegetables, joints of meat and fish dishes. Beware of the steam jet during steam release. -
Page 21: Cleaning And Maintenance
Cleaning and Maintenance Do not leave food standing in your pressure cooker. Never use bleach or chlorine based products to clean your pressure cooker as these damage the quality of stainless steel. Remove the timer (according to the model) before cleaning. Wash your cooker after each use. - Page 22 Change the lid seal once a year. Have your pressure cooked checked at a TEFAL Approved Service Centre after 10 years of use. Storing your pressure cooker Turn the lid upside down on the pot and adjust so...
- Page 23 The shape of the seals has been specially designed for easy removal and re-fitting. Seals can be purchased from TEFAL Approved Service Centres. Cleaning the timer Clean it with a soft, dry cloth.
- Page 24 TEFAL Safety Your Clipso pressure cooker is equipped with several safety devices, which guarantee operating security. Closing Security The jaws must be in contact with the edge of the pot. If this does not happen, steam will be released from the pressure indicator and the pressure cooker will not reach pressure.
-
Page 25: Frequently Asked Questions
The pressure indicator has lifted up and some steam still escapes from it: If you have a Clipso Control model or Clipso Vitamin (model with air release system) once the pressure indicator has moved up, air and steam are normally released during a certain time period (a few seconds to a few minutes). - Page 26 Guarantee Your new TEFAL pressure cooker has a 10 year guarantee against: - Any defect related to the metal pot, - Any premature damage of the metal base, provided the product is used according to the recommended instructions. This guarantee does not include:...
- Page 27 Downloaded from www.Manualslib.com manuals search engine...
- Page 28 September 2002 Ref. : 4132081 Conception et réalisation : ADHOC’S Downloaded from www.Manualslib.com manuals search engine...
