Kärcher 2400 G Operator's Manual

Hide thumbs

Advertisement

Quick Links

Model 2400 G
High Pressure Washer Operator Manual
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2
Assembly Instructions . . . . . . . . . . . . . . . . . . . . . . . . .3
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . .4
Using the Accessories . . . . . . . . . . . . . . . . . . . . . . . . .5
Working with Detergents . . . . . . . . . . . . . . . . . . . . . . .6
Shut Down and Clean-Up . . . . . . . . . . . . . . . . . . . . . .7
Taking a Break . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Winterizing and Long-Term Storage . . . . . . . . . . . . . .7
Cleaning Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-9
Optional Cleaning Accessories . . . . . . . . . . . . . . . . . .9
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . .10-11

Specifications

Operating pressure
Water volume
Engine
In USA Call:
1-800-537-4129
or visit our website:
www.karcher-usa.com
2400 PSI
2.5 GPM
5.0 HP Honda GC 160
Part No. 9.139-103

Advertisement

loading

  Related Manuals for Kärcher 2400 G

  Summary of Contents for Kärcher 2400 G

  • Page 1: Table Of Contents

    Model 2400 G Part No. 9.139-103 High Pressure Washer Operator Manual Overview ........1 Precautions .
  • Page 2: Overview

    Model K 2400 G OVERVIEW Item Description 1. High pressure outlet 2. Water inlet with garden hose connector and filter 3. Detergent suction tube 4. Knob Assembly (two each, Bolt & Knob) 5. High pressure hose 6. Detergent filter 7. Handle 8.
  • Page 3 IMPORTANT PRECAUTIONS – Read First! Safety Warnings Water Supply (Cold Water Only) When using this product, basic precau- tions should always be followed: • Water hose must be at least 3/4 inch • Read all the instructions before using in diameter. the product.
  • Page 4: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Step 1 Step 2 Step 3 Attach the Attach the Place the quick handle to the frame of the gun/hose storage handle. connect nozzles in the nozzle pressure washer. Align holder. holes, insert bolts, and tighten with knobs. Step 4 Step 5 Step 6...
  • Page 5: Operating Instructions

    OPERATING INSTRUCTIONS Step 1 Step 2 Check oil level. Oil level should be level with the Fill gas tank bottom of the oil filler neck. Be sure the machine is level when with unleaded gasoline. checking the oil level. (Refer to the engine’s operating manual Do not use leaded gasoline.
  • Page 6: Using The Accessories

    USING THE ACCESSORIES The five color-coded quick connect nozzles provide a wide array of spray widths from 0° to 65° and are easily accessible when placed in the convenient rubber nozzle holder, which is provided on the front of the machine. Red nozzle = 0°...
  • Page 7: Working With Detergents

    For Kärcher Detergents, check your retailer or call: In USA Call: 1-800-537-4129 or visit our website: www.karcher-usa.com The following Kärcher detergents Step 3 are available: Fill a container with Kärcher detergent. Place the filter end of detergent •...
  • Page 8: Shut Down And Clean-Up

    SHUTTING DOWN & CLEAN-UP Step 1 Step 2 Step 3 Step 4 Remove de- Press Turn Press tergent suction tube from the throttle down to off water supply. trigger to release container and insert into stop the engine. water pressure. one gallon of fresh water.
  • Page 9: Cleaning Tips

    CLEANING TIPS Cement Patios, Deck Cleaning Brick and Stone (with or without detergent) (with or without detergent) Pre-rinse deck and surrounding area with fresh water. If using Kärcher Deck Wash, Pre-rinse cleaning surface with fresh water. place detergent suction tube directly into If using Kärcher All Purpose Cleaner, place cleaning solution and apply to surface at low detergent suction tube directly into cleaning...
  • Page 10: Optional Cleaning Accessories

    See accessories order form for product descriptions and ordering instructions. • Dirtblaster ® nozzle • Hose Reel • Extension Wand 80” • Pipe Drain Cleaner • Rotating Wash Brush • Extension Hose 30’ • Sand Blasting Attachment • Detergent Tray In USA Call: 1-800-537-4129 or visit our website: www.karcher-usa.com...
  • Page 11: Troubleshooting

    TROUBLESHOOTING Disconnect the machine from the power source before making any repair. Symptom Cause Solution Engine will not No gasoline. Fill gas tank. start. Add oil. Low oil level sensor activated. Choke is not in correct position. Slide choke lever out to closed position. Engine throttle is not in Slide the throttle lever up about 1/3 of correct position.
  • Page 12 Oil Drip. Oil seals are damaged Call service center. or worn. If you encounter any additional In USA Call: difficulties not listed, please call 1-800-537-4129 our service center for help. or visit our website: www.karcher-usa.com Kärcher Customer Support USA...
