Front Suspension - Capricorn Lab-C03 Instruction Manual

Step 13.0

- Front Suspension -

Left part
3
Code Cap14006B
4 3x12
3,5
Made in Italy
28
C C C C a a a a p p p p r r r r i i i i c c c c o o o o r r r r n n n n R R R R C C C C
BAG 13
Left part
1
Code Cap18051
6
5
10
3x3
8
3x12 Flanged
Note:
Ensure that the harm
move freely
L/R
4x6
2
Thread Lock
9
3x65 Pin
7
To adjust down stop position
+
-
To adjust Anti-roll bar position
Right Block
2x
Parts List
Rif. n° Code
1 1
Cap18050
2 1 Cap17011
3 1 Cap14005B
4 1 Cap17005
5 1 Cap16084
6 1 Cap16082
7 1 Cap16051
+
8 1 Cap17025
9 1 Cap16006-78
-
10 1 Cap17007
