Step 11.5
- Rear Suspension -
3x6
Note:
Ensure that the Brake link
move freely
3x8
3
3x8
3
Made in Italy
24
C C C C a a a a p p p p r r r r i i i i c c c c o o o o r r r r n n n n R R R R C C C C
BAG 11
5
4
.
2
5
3x6
5
3x6
1
Carbon Plate
Zoom view
Note:
Adjust position for minimum offset
and freely rear Anti-Roll bar movement
Parts List
Rif.
n°
Code
1
1
Cap18063
2
1
Cap16068P
3
2
Cap17032
4
1
Cap16029
5
3
Cap17030
