Description of each menu

Function
Screen Color
Aspect Ratio
Keystone
Corner Adj.
(PJD7831HDL/
PJD 36HDL)
Position
Phase
H. Size
Zoom
Color Mode
Brightness
Contrast
Color Temp.
OverScan
HDMI Settings
See "Using Screen Color" on page 33
This function is only available when a PC input signal is
selected.
See "Selecting the aspect ratio" on page 31
See "Correcting keystone" on page 29
See "Adjusting 4 corners (PJD7831HDL/PJD7836HDL)" on
page 30 for details.
Displays the position adjustment page. To move the projected
image, use the directional arrow keys. The values shown on the
lower position of the page change with every key press you made
until they reach their maximum or minimum.
This function is only available when a PC input signal is
selected.
The adjustment range may vary under different timings.
Adjusts the clock phase to reduce image
distortion.
This function is only available when
a PC input signal is selected.
Adjusts the horizontal width of the image.
This function is only available when a PC input signal is
selected.
See "Magnifying and searching for details" on page 30
details.
See "Selecting a picture mode" on page 32
See "Adjusting Brightness" on page 33
See "Adjusting Contrast" on page 33
See "Selecting a Color Temperature" on page 34
preferred color temperature" on page 34
Adjusts the overscan rate from 0% to 5%.
This function is only available when a Composite Video,
S-Video or HDMI input signal is selected.
See "Changing HDMI input settings" on page 27
45
Description
for details.
for details.
for details.
for details.
for details.
for details.
for details.
for
and "Setting a
for details.
