ViewSonic PJD6252L User Manual

Hide thumbs Also See for PJD6252L:
Table of Contents

Advertisement

Quick Links

PJD6252L/PJD6551W/PJD7326/
PJD7526W/PJD7720HD
DLP Projector

User Guide

IMPORTANT: Please read this User Guide to obtain important information on installing
and using your product in a safe manner, as well as registering your product for future
service. Warranty information contained in this User Guide will describe your limited
coverage from ViewSonic Corporation, which is also found on our web site at http://
box in the upper right corner of our website. "Antes de operar su equipo lea cu
idadosamente las instrucciones en este manual"
Model No. VS16443/VS15913/VS16444/VS16445/VS16483
